Page 2
INTRODUCTION RS850/S INTRODUCTION Specifications, descriptions, and illustrative material in this literature are as accurate as possible. Specifications are subject to change without notice. Illustrations might include optional equipment and accessories, and might not include all standard equipment. Your equipment might appear slightly different than pictured equipment.
Page 3
Service Service of this product during the warranty period must be performed by an Authorized Shindaiwa Service Dealer. For the name and address of the Authorized Shindaiwa Service Dealer nearest you, ask your retailer or call: 1-877-986-7783. Dealer information is also available on www.shindaiwa- usa.com.
Page 4
SAFETY RS850/S SAFETY Safety Information Carefully read these instructions before use. Improper use or failure to follow instructions can result in product failure or injuries. For safe use of this product you must read and follow all instructions before using.
Page 5
RS850/S DESCRIPTION DESCRIPTION Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and that you understand and follow the instructions on it. If a decal cannot be read, a new one can be ordered from your dealer. The safety decal is for example only.
Page 6
CONTENTS RS850/S Handles Hopper Wheels Adjustable Deflector Upper Control Rod Gate Control Lever Gate Adjustment Limiter CONTENTS The product you purchased has been partially factory pre-assembled for your convenience. Due to packaging restrictions, some assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or Dealer of damaged or missing parts.
Page 8
ASSEMBLY RS850/S Install upper handle assembly (E) into lower handle bracket (F). Attach hinge (G) oriented as shown, and secure with two 6 x 60 mm bolts (H) and two 6 mm flange nuts (I). Install Control Rods Insert tab end of upper...
Page 9
RS850/S ASSEMBLY Thread 6 mm nut (C) onto end of upper control rod to a distance of 25.4 mm (1 in) from bottom of rod. Insert threaded end of rod into hole in hinge arm (D). Then thread 6 mm flange nut (E) onto rod.
Page 12
ASSEMBLY RS850/S Change Auger Note: Refer to operation section for information on selecting correct auger. Remove grate. Remove flange nut (A) and bar auger (B) from gear shaft. Install spiked auger (C) onto gear shaft and secure with flange nut (B).
Page 13
RS850/S OPERATION Check Tire Pressure Tires should be inflated to 15 psi. Assure tire pressure does not exceed 30 psi. OPERATION Application Instructions TIP HAZARD. Unit can tip on uneven ground. Always fill hopper on flat ground, and keep bystanders away. Otherwise personal injury can result.
Page 14
OPERATION RS850/S Push gate control lever (A) fully forward to close gate. Fill hopper with product. Fill hopper in an area that won’t be damaged by spilled product. Start spreader in motion, and pull gate control lever back to begin the flow of product.
Page 15
RS850/S MAINTENANCE Sample Spread Pattern Muestra del patrón de disribución Modèle d’épandage typ SHUT OFF HERE SHUT OFF HERE Apague aquí Apague aquí Arrêt ici Arrêt ici START RESTART RESTART Inicio Reinicie Reinicie Mise en Remise en Remise en marche...
Page 17
RS850/S SPECIFICATIONS SPECIFICATIONS MODEL RS850 Length 1,194 mm (47 in) Width 654 mm (25.75 in) Height 952 mm (37.50 in) Weight 16.20 kg (35.80 lb) Capacity Weight 38.50 kg (85lb.) Volume 43.90 L (1.55 ft Loading Height 641 mm (25.25 in)
Page 18
PRODUCT REGISTRATION Thank you for choosing Shindaiwa Power Equipment Please go to http://www.shindaiwa-usa.com to register your new product on-line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO Incorporated. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.
