Page 2
Remove the spreader and com- ponents from the carton. Turn spreader upside down. Insert (2) 1/4-20 x 1 1/2” hex bolts through the flattened end of handle brace, frame and leg as shown. Install hex nuts but do not tighten. Repeat on opposite side.
Page 3
Wire Clip Wire Install gear cover assembly over gears and secure with (2) #6-32 screws. The 41RS spreader should now be com- pletely assembled and ready for use. Slide handle grips onto handle. Soapy water will ease installation. (Do not use petroleum based products.)
HOW TO DETERMINE SPREADER SETTINGS AND SPREAD WIDTH Two major factors should be considered when determining correct spreader settings of any product: The product application rate, or the amount of material applied per 1,000 square feet. The effective pattern width, or the actual width in which material is applied. Label set- tings are a guide and can be affected by numerous factors.
Page 6
RATE SETTING CONVERSION The following provides approximate Shindaiwa 41RSSetting Scott Speedy Green Setting Prizelawn BF1 / BF1SS Setting Lesco #029600 — Scotts R8A/ SR-1 Setting Earthway 2200/2400 — Setting Spyker 76/78-2 Setting — The following provides approximate square foot coverage, and visual inspection of the material is available.
OWNER’S RESPONSIBILITIES The owner of the unit must demonstrate reasonable care in the use, maintenance, and storage of this Shindaiwa product. If a warrant- able failure should occur, the owner must deliver the product to an authorized Shindaiwa servicing dealer for correction. All residual chem- icals must be flushed from the tank prior to delivery.
Page 8
Parts List for SHINDAIWA MODEL 41RS PART OF OUR SERVICE IS PRO- VIDING REPLACEMENT PARTS. Parts may be obtained through your local distributor. be sure to give: SPREADER MODEL NUMBER SPREADER NAME PART NUMBER NAME OF PART AS SHOWN Description Hopper Ass’y-includes #2 &...
