Operator's
Manual
RS600
Broadcast
Spreader
X7507840102
© 7/21 ECHO Incorporated

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS600 and is the answer not in the manual?

Questions and answers

Related Manuals for Shindaiwa RS600

Summary of Contents for Shindaiwa RS600

  • Page 1 Operator’s Manual RS600 Broadcast Spreader X7507840102 © 7/21 ECHO Incorporated...

  • Page 2: Servicing Information

    SERVICING INFORMATION Parts and Serial Number Genuine SHINDAIWA Parts and Assemblies for your SHINDAIWA products are available only from an Authorized SHINDAIWA Dealer. When you do need to buy parts...

  • Page 3: Consumer Product Support

    Service Service of this product during the warranty period must be performed by an Authorized SHINDAIWA Service Dealer. For the name and address of the Authorized SHINDAIWA Service Dealer nearest you, ask your retailer or call: 1-877-986-7783. Dealer information is also available on WWW.SHINDAIWA-USA.COM.

  • Page 4: Safety Information

    SAFETY RS600 SAFETY Safety Information Carefully read these instructions before use. Improper use or failure to follow instructions can result in product failure or injuries. For safe use of this product you must read and follow all instructions before using.
  • Page 5 RS600 DESCRIPTION DESCRIPTION Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and that you understand and follow the instructions on it. If a decal cannot be read, a new one can be ordered from your dealer. The safety decal is for example only.
  • Page 6 CONTENTS RS600 CONTENTS The product you purchased has been partially factory pre-assembled for your convenience. Due to packaging restrictions, some assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or Dealer of damaged or missing parts. Use the contents list to check for missing parts.

  • Page 7: Check Tire Pressure

    RS600 ASSEMBLY Secure handle brackets with wing nuts (C) and carriage bolts (D) on each side. Note: Attach each side loosely before tightening brackets securely. Assure control cable is routed behind handle brackets. Check Tire Pressure Tires should be inflated to 15 psi. Assure tire pressure does not exceed 30 psi.

  • Page 8: Operation

    OPERATION RS600 OPERATION Application Instructions TIP HAZARD. Unit can tip on uneven ground. Always fill hopper on flat ground, and keep bystanders away. Otherwise personal injury can result. Fill Hopper Release actuator handle (A) to close gate. Fill hopper. Note: Fill hopper in an area that won’t be damaged by...

  • Page 9: Maintenance

    RS600 MAINTENANCE Setting comparison chart / Cuadro comparativo / Régler selon la charte de comparaison Setting by granular size / Ajuste por tamaño granular / Régler selon la taille des granules Setting 2 - 2.5 3 - 3.5 4 - 5.5...
  • Page 10 MAINTENANCE RS600 Wash spreader with a garden hose after each use. Check Tire Pressure Tires should be inflated to 15 psi. Assure tire pressure does not exceed 30 psi. Replacing Control Cable Remove Shield (A). Turn gate (B) clockwise to relieve tension on cable.
  • Page 11 RS600 MAINTENANCE Remove cable S hook (C) from gate. Remove upper handle bracket from lower handle bracket. Remove bolts (D) and separate handle halves. Install new handle half with control cable assembly. Re assemble spreader components. X7507840102 © 7/21 ECHO Incorporated...

  • Page 12: Specifications

    SPECIFICATIONS RS600 Assure control cable is routed behind handle brackets. SPECIFICATIONS MODEL RS600 Length 959 mm (37.75 in.) Width 584 mm23 in.) ( Height 794 mm (31.25 in.) Weight 10.2 kg (22.4 lb.) Capacity Weight 27.2 kg (60lb.) Volume 36.8 L (1.3 ft Loading Height 584 mm (23 in.)
  • Page 13 PRODUCT REGISTRATION Thank you for choosing Shindaiwa Power Equipment Please go to http://www.shindaiwa-usa.com to register your new product on-line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO, Incorporated. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.

  • Page 14: Product Registration

    PRODUCT REGISTRATION RS600 X7507840102 © 7/21 ECHO Incorporated...
  • Page 15 N2950001001 - N29500999999 ECHO INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 -usa www.shindaiwa .com...
