Aqua Flo AQUV-12R2 Owner's Manual

Ultraviolet disinfection system

Advertisement

Quick Links

Ultraviolet Disinfection System
Models: AQUV-12R2, AQUV-20R2
1. This manual contains important safety and operating instructions. Read all instructions and follow
them when using this product. Failure to consider this information and follow these instructions,
including those concerning maintenance, may result in property damage, injury and or death.
2. We recommend installation only be completed by a competent installer or plumbing professional to insure this
product is installed in accordance with local plumbing codes.
3. Test the water periodically to verify that the system is performing satisfactorily.
4. Discard small parts remaining after the installation.
5. Failure to install the system correctly voids the warranty.
6. Handle all components of the system with care. Do not drop, drag or turn components upside down.
7. Save these instructions and keep track of your product's serial number.
NOTICE: THIS MANUAL CONTAINS A LIMITED WARRANTY. BY INSTALLING AND OR USING THIS PRODUCT, YOU WAIVE
CERTAIN LEGAL RIGHTS INCLUDING THE RIGHT TO SUE OR CLAIM COMPENSATION IN THE EVENT OF PROPERTY
DAMAGE, INJURY, AND OR DEATH.
BRAND: AQUA FLO.
MODELS: AQUV-12R2, AQUV-20R2
Canature WaterGroup Canada Inc.
855 Park St.
Regina, SK, S4N 6M1
CANADA
Toll Free: (877) 288-9888
Canature WaterGroup U.S.A. Inc.
6353 Commerce Drive
Whitestown, IN, 46075
USA
Toll Free: (877) 288-9888

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUV-12R2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aqua Flo AQUV-12R2

  • Page 1 Ultraviolet Disinfection System Models: AQUV-12R2, AQUV-20R2 1. This manual contains important safety and operating instructions. Read all instructions and follow them when using this product. Failure to consider this information and follow these instructions, including those concerning maintenance, may result in property damage, injury and or death.
  • Page 3: Table Of Contents

    Congratulations on purchasing this ultraviolet disinfection system. By purchasing an AQUA FLO UV Disinfection system you are receiving not only a high quality product but also peace of mind. Pro- tecting your water supply with a UV system gives you reassurance that your family will have access to safe drinking water throughout your entire home.
  • Page 4: Introduction

    (A) INTRODUCTION Mounting UV Ballast Bracket Your AQUV-12R2 and AQUV-20R2 units feature a two-stage design. The first stage is a five (5) micron sediment filter that reduces dirt, rust, sand and other fine particulate WATER IN WATER OUT matter. Stage two is a UV system that instantly destroys pathogenic bacteria (such as coliform, E.
  • Page 5: Water Quality Requirements

    USE ONLY GENUINE AQUA FLO AQUV LAMPS. Use of non- REPLACED ANNUALLY. After 1 year of use, it will no Aqua Flo AQUV UV lamps can result in unsafe drinking water, longer provide effective disinfection even though it stays lit.
  • Page 6: Installation

    INSTALLATION NOTES AND CAUTIONS: — The Aqua Flo AQUV Water Disinfection System is designed for installation on the cold water line only at the point of entry (POE). The system must be installed in accordance with all local, state or provincial regulations.
  • Page 7 Fittings required for a typical install on 3/4” copper pipe are 3/4” FNPT female adapters, 3/4” Tee, 3/4” Elbows, 3/4” copper pipe, 3/4” union couplings and 3/4” ball valves. You may need different fittings if your pipe size or material is different. If you are unsure of what fittings to use, please call Aqua Flo. CAUTION UV light can degrade plastics over time.
  • Page 8 Sediment Pre-Filter Drain Port (Recommended) Installing the AQUV Rack System SIDE VIEW 1. There are two mounting holes on the mounting bracket. Both of them should be mounted directly on to a Dome O-Ring wall stud with appropriate screws to carry the weight of the unit.
  • Page 9: Disinfection Procedure

    12. Connect the ballast power cable to the AC supply (with surge protector). The green lamp-on LED will light up and the display will show “365”. This number indicates the number of days left until lamp life expires and must be replaced. Follow Step (E) before consuming water. YOUR AQUA FLO AQUV UV DISINFECTION SYSTEM IS NOW READY FOR SERVICE. (E) DISINFECTION PROCEDURE Before service begins, all household plumbing lines should be disinfected to prevent the possibility of re-contamination after UV disinfection.
  • Page 10: Ballast For Aquv Uv Systems

    (F) BALLAST FOR AQUV UV SYSTEMS Aqua Flo AQUV advanced micro-processor controlled electronic UV ballast is for use with Aqua Flo AQUV-8, AQUV-12 & AQUV-20 Systems. It features both audio and visual alarm indicators to indicate the lamp operation and an integral annual lamp change reminder timer.
  • Page 11: Operation And Maintenance

    WARNING USE ONLY GENUINE AQUA FLO AQUV LAMPS Use only GENUINE AQUA FLO AQUV UV Lamps with your UV system. Aqua Flo UV lamps are designed with extensive product research and engineering to provide reliable and consistent UV output and performance that ensures the safety of your drinking water.
  • Page 12: Troubleshooting

    How to replace the UV Lamp and clean Quartz Dome: 1. Unplug UV unit from electrical outlet and turn off supply valve before the unit. Open a faucet to depressurize the UV system and turn off the valve at the UV outlet to isolate UV unit. CAUTION: The lamp end can be very hot. Wait several minutes for the lamp to cool down. 2.
  • Page 13: Technical Specifications

    (I) TECHNICAL SPECIFICATIONS Category AQUV-12R2 AQUV-20R2 Maximum flow rate @ 30 mJ/cm 12 gpm / 45 lpm 20 gpm / 75 lpm 6 10 Maximum flow rate @ 40 mJ/cm 8 gpm / 30 lpm 12 gpm / 45 lpm...
  • Page 16: Warranty

    (K) LIMITED WARRANTY The Ultraviolet Water Disinfection Systems stainless steel housing is warranted to the original purchaser for a period of seven (7) years, from the date of purchase, against defects in materials and workmanship. The Ultraviolet Water Disinfection Systems miscellaneous hardware, seals and electrical system are warranted to the original purchaser for a period of one (1) year, from the date of purchase, against defects in materials and workmanship.
