Self-Contained Flaker
Model
F-300BAF
PARTS LIST
®
Number: 71126
Issued: 3-15-1999
Revised: 9-8-2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F-300BAF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hoshizaki F-300BAF

Summary of Contents for Hoshizaki F-300BAF

  • Page 1 Hoshizaki America, Inc. “A Superior Degree of Reliability” www.hoshizaki.com Self-Contained Flaker Model F-300BAF PARTS LIST ® Number: 71126 Issued: 3-15-1999 Revised: 9-8-2008...

  • Page 2: Table Of Contents

    CONTENTS Auxiliary Codes ... 3 Note About Ordering Parts ... 3 Material Abbreviations ... 4 A. Ice Flaker Assembly ... 5 B. Evaporator Assembly ... 9 C. Refrigeration Unit ... 1 D. Water Circuit Assembly ... 15 E. Cover Assembly - Bin Top ... 19 F.

  • Page 3: Auxiliary Codes

    Auxiliary Codes F-300BAF August 1998 January 1999 June 1999 December 1999 April 000 May 000 December 000 May 001 December 001 October 00 December 00 December 003 Auxiliary Code Breakdown Designates the year. "K" indicates the year 000. Years progress or regress in alphabetical order.

  • Page 4: Material Abbreviations

    Material Abbreviations ALUMINUM Aluminum COPPER Copper PLASTIC Acrylonitrile -butadiene-styrene Polyacetal Ethylene vinyl acetate Polyamide = Nylon Polycarbonate Polyethylene Polyester PETP Polyethylene terephthalate = Tetlon Polypropylene Polystyrene PTFE Polytetrafluoroethylene = Teflon Polyurethane Polyvinyl chloride RUBBER Vinyl Nitrile EPDM EP rubber Nitrile butadiene rubber Natural rubber Neoprene SI.R...

  • Page 5: Ice Flaker Assembly

    A. Ice Flaker Assembly F-300BAF H-0 to M-0...
  • Page 6 A. Ice Flaker Assembly F-300BAF M-1 to P-0 see pages 37-38 for all parts in K assembly...

  • Page 7: H. Label Location

    Title: A. Ice Flaker Assembly Model: F-300BAF Index Description EVAP. ASSEMBLY REFRIGERATION UNIT WATER CIRCUIT ASSEMBLY - COVER ASSY - BIN TOP TRUSS HEAD SCREW CONTROL BOX ASSEMBLY TRUSS HEAD SCREW SLIDING DOOR LABEL LOCATION SPOUT ASSEMBLY (replaces BOTTOM PANEL...
  • Page 8 Title: A. Ice Flaker Assembly Model: F-300BAF Index Description REAR PANEL (A) T SCREW SIDE PANEL (R) T SCREW TRUSS HEAD SCREW SIDE PANEL (L) T SCREW TRUSS HEAD SCREW TOOTH WASHER RAIL EDGING TRUSS HEAD SCREW BRACKET - FRONT PANEL...

  • Page 9: Evaporator Assembly

    B. Evaporator Assembly F-300BAF H-0 to K-...
  • Page 10 B. Evaporator Assembly F-300BAF L-0 to P-0...
  • Page 11 SOCKET HEAD CAP SCREW SS, M8x14 Material or Model Number Part Number SA0103 Use kit SA0103 for all F-300BAF gear motor replacements. Kit includes Gear Motor U0147-01 and Capacitor 41691-05. For auxiliary codes K1 and earlier, you must also order Fuse Holder 4A089-0, Fuse 4A0893-04, and Fuse Holder Adapter 4A1880-01.

  • Page 12: Refrigeration Unit

    C. Refrigeration Unit F-300BAF H-0 to L-0...
  • Page 13 C. Refrigeration Unit F-300BAF L-1 to P-0...
  • Page 14 Title: C. Refrigeration Unit Model: F-300BAF Index Description FAN MOTOR ASSEMBLY HEX HEAD BOLT W/WASHER (LF) COMPRESSOR GROMMET SPACER PROTECTOR PROTECTOR HOLDER STARTER BOLT CONDENSER FT SCREW SHROUD T SCREW DRIER DRIER BRACKET FT SCREW EXPANSION VALVE EXPANSION VALVE COVER...

  • Page 15: Water Circuit Assembly

    D. Water Circuit Assembly F-300BAF H-0, J-0...
  • Page 16 D. Water Circuit Assembly F-300BAF J-1 to L-1...
  • Page 17 D. Water Circuit Assembly F-300BAF M-0 to P-0...
  • Page 18 Title: D. Water Circuit Assembly Model: F-300BAF Index Description WATER VALVE BRACKET (A) GS TRUSS HEAD SCREW WATER VALVE (INLET) T SCREW WATER SUPPLY PIPE TRUSS HEAD SCREW ELBOW INLET - RESERVOIR RESERVOIR RESERVOIR COVER SEPARATOR - RESERVOIR FLOAT SWITCH...

  • Page 19: Cover Assembly - Bin Top

    E. Cover Assembly - Bin Top F-300BAF H-0 to K-1...
  • Page 20 Index Description COVER - BIN TOP PROXIMITY SWITCH BRACKET - SWITCH TRUSS HEAD SCREW BUSHING HINGE THUMBSCREW ACTUATOR SHAFT SNAP PIN Model: F-300BAF Material or Model Number Part Number 317057G01 3A1545G01 RS-601 473-01 4A033-01 47158-01 4X8, SS 7C3-0408 SB-437-5 40470-07...

  • Page 21: Control Box Assembly

    F. Control Box Assembly F-300BAF H-0 to K-1...
  • Page 22 F. Control Box Assembly F-300BAF K-, L-0...
  • Page 23 F. Control Box Assembly F-300BAF L-1, M-0...
  • Page 24 F. Control Box Assembly F-300BAF M-1 to P-0...
  • Page 25 Title: F. Control Box Assembly Model: F-300BAF Index Description CONTROL BOX CONTROL BOX COVER TRUSS HEAD SCREW TIMER BOARD BOARD SUPPORT RELAY TAPPING SCREW RELAY RELAY RELAY CAPACITOR - STARTING STRAP T SCREW CAPACITOR TRANSFORMER 1P PLUG HOUSING 06P PLUG HOUSING...

  • Page 26: Sliding Door

    G. Sliding Door F-300BAF H-0 to P-0 Title: G. Sliding Door Model: F-300BAF Index Description SLIDING DOOR (A) SLIDING PLATE SLIDING COLLAR POP RIVET KNOB Material or Model Number Part Number 454860-01 454861-01 45486-01 7170-003 AD(45)ABS 444301-0 Required Number...
  • Page 27 H. Label Location F-300BAF H-0 to K-1...
  • Page 28 H. Label Location F-300BAF K- to P-0 out at M-1...
  • Page 29 Title: H. Label Location Model: F-300BAF Index Description INSTRUCTION SHEET EMBLEM MODEL NUMBER LABEL LABEL - PENGUIN - HA CAUTION LABEL (D) LABEL - AIR FILTER MAINTENANCE LABEL LABEL - CLEANING LABEL - SLIDE DOOR NAMEPLATE CONTROL LABEL CAUTION LABEL (G)

  • Page 30: Fan Motor Assembly

    J. Fan Motor Assembly F-300BAF H-0 to P-0 Title: J. Fan Motor Assembly Model: F-300BAF Index Description BLADE - FAN (PULLER) MOTOR - 16W HEX NUT FAN MOTOR BRACKET SCREW WASHER Material or Model Number Part Number AD9CW38UBA 3A0608-01 SP-B16EM1...

  • Page 31: Spout Assembly

    K. Spout Assembly F-300BAF M-1 to P-0 Title: K. Spout Assembly Model: F-300BAF Index Description SWITCH BRACKET LEVER – A TRUSS HEAD SCREW MICROSWITCH (SAFETY SWITCH) PAN HEAD SCREW SPRING TRUSS HEAD SCREW SPOUT Material or Model Number Part Number...

  • Page 32: Accessories & Packaging

    L. Accessories & Packaging F-300BAF H-0 to P-0 Title: L. Accessories & Packaging Index Description INSTRUCTION MANUAL SCOOP ADJUSTABLE LEG PACKAGING Model: F-300BAF Material or Model Number Part Number PAPER 91AJA10B 43765-01 4A46-01 434043-01 1A0531A05 Required Number...
