Reliability is a
beautiful thing
TM
SELF-CONTAINED FLAKER
F-300BAF
INSTRUCTION MANUAL
ISSUED:
May 11, 1998
REVISED: December 30, 2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F-300BAF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hoshizaki F-300BAF

Summary of Contents for Hoshizaki F-300BAF

  • Page 1 Reliability is a beautiful thing SELF-CONTAINED FLAKER F-300BAF INSTRUCTION MANUAL ISSUED: May 11, 1998 REVISED: December 30, 2004...
  • Page 2 HOSHIZAKI provides this manual primarily to assist qualified service technicians in the installation, maintenance and service of the icemaker. Should the reader have any questions or concerns which have not been satisfactorily addressed, please call or write to the HOSHIZAKI Technical Support Department for assistance.

  • Page 3: Table Of Contents

    • Please review this manual. It should be read carefully before the icemaker is installed and operated. Only qualified service technicians should install, service and maintain the icemaker. This manual should be made available to the technician prior to installation, maintenance or service.

  • Page 4: Specifications

    I. Specifications 1. Nameplate Rating [a] F-300BAF (air-cooled) MODEL NUMBER SERIAL NUMBER AC SUPPLY VOLTAGE AMPERES DESIGN PRESSURE REFRIGERANT 404A MOTOR-COMPRESSOR THERMALLY PROTECTED See the nameplate for electrical and refrigeration specifications. This nameplate is located on the upper right hand side of rear panel.

  • Page 5: Dimensions/Connections

    2. Dimensions/Connections Unit = inches [mm.] F-300BAF...

  • Page 6: Installation And Operating Instructions

    II. Installation and Operating Instructions 1. Checks Before Installation Remove shipping carton, tape(s) and packing. If packing material is left in the icemaker, it will not work properly. Ensure all components, fasteners and thumbscrews are securely in place. 1) Remove the front panel to prevent damage when installing the icemaker. See Fig. 1. 2) Remove the package containing the accessories from inside the icemaker.

  • Page 7: Location

    3. Location This icemaker is not intended for outdoor use. Normal operating ambient temperature should be within +45°F to +100°F; Normal operating water temperature should be within +45°F to +90°F. Operation of the icemaker, for extended periods, outside of these normal temperature ranges may affect production capacity.

  • Page 8: Water Supply And Drain Connections

    6. Water Supply and Drain Connections - See Fig. 2 • External filters, strainers or softeners may be required depending on the water quality. • Water supply inlet is 1/2" female pipe thread (FPT). • A water supply line shut-off valve and drain valve should be installed. A minimum of 3/8"...

  • Page 9: Final Checklist

    7. Final Checklist 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within +45°F to +100°F and the water temperature within +45°F to +90°F all year around? 3) Is there at least 6" clearance at rear and sides and 24" at top for maintenance or service? 4) Have all shipping carton, tape(s) and packing been removed from the icemaker? 5) Are all components, fasteners and thumbscrews securely in place?

  • Page 10: Startup

    15) Has the safety switch been checked for correct operation? Activate the safety switch on top of the spout. The ice machine should shut down immediately. Turn the ice machine off, then back on, to reset. 8. Startup 1. All parts are factory-adjusted. Improper adjustments may result in failure. 2.

  • Page 11: Preparing The Icemaker For Long Storage

    9. Preparing the Icemaker for Long Storage - See Fig. 3 When shutting off the icemaker for an extended time, drain out all water from the water line and remove the ice from the storage bin. The storage bin should be cleaned and dried.

  • Page 12: Cleaning And Maintenance

    [a] Cleaning Solution Dilute 4.8 fl. oz. (142 ml) of recommended cleaner Hoshizaki “Scale Away” or “LIME-A-WAY” (Economics Laboratory, Inc.) with 0.8 gallons (3 l) of warm water. This is a minimum amount. Make more solution if necessary.

  • Page 13: [C] Sanitizing Solution

    8) Remove the thumbscrews attaching spout (A) to the evaporator assembly and lift off spout (A) and spout packing (A). 9) Pour the cleaning solution over the extruding head until the evaporator assembly and the reservoir are filled and the solution starts to overflow into the drain pan. Note: If there is excess scale on the extruding head, fill the evaporator assembly and reservoir as described above, then use a clamp on the reservoir hose between the reservoir and evaporator assembly to block flow.

  • Page 14: [D] Sanitizing Procedure - Initial

    [d] Sanitizing Procedure - Initial 1) Close the water supply line shut-off valve. 2) In the storage bin, remove the thumbscrews attaching spout (B), then remove spout (B) and spout packing (B). 3) Remove the thumbscrews attaching spout (A) to the evaporator assembly and lift off spout (A) and spout packing (A), and the cylinder packing.
  • Page 15 6) Remove the thumbscrews attaching spout (A) to the evaporator assembly and lift off spout (A) and spout packing (A). 7) Pour the sanitizing solution over the extruding head until the evaporator assembly and the reservoir are filled and the solution starts to overflow into the drain pan. 8) Using the thumbscrews, replace spouts (A) and (B) and spout packings (A) and (B) in their correct positions.

  • Page 16: Maintenance

    Their service life, however, depends on water quality and environment. More frequent inspection and maintenance are recommended. Consult with your local distributor about inspection and maintenance service. To obtain the name and phone number of your local distributor, call Hoshizaki Technical Support Department at 1-800-233-1940. 1) Exterior Panels Wipe the exterior occasionally with a clean, soft cloth.
  • Page 17 3) Air Filter A plastic mesh air filter removes dirt or dust from the air, and keeps the condenser from getting clogged. As the filter gets clogged, the icemaker’s performance will be reduced. Check the filter at least twice a month. 1) Remove the screw, push down the lock and take off the louver.
  • Page 18 HOSHIZAKI HOSHIZAKI AMERICA, INC. 618 HIGHWAY 74 SOUTH PEACHTREE CITY, GA 30269 U.S.A. PHONE: 770-487-2331 www.hoshizakiamerica.com 91A2JA10E...
