MODULAR ICEMAKER
MODEL
(FINAL) PARTS LIST
HOSHIZAKI
F-2000MRF(-C)
F-2000MRF3(-C)
NO:
71136
ISSUED:
DEC. 13, 1999
REVISED:
AUG. 8, 2006

Advertisement

Table of Contents
loading

Related Manuals for Hoshizaki F-2000MRF

Summary of Contents for Hoshizaki F-2000MRF

  • Page 1 HOSHIZAKI MODULAR ICEMAKER F-2000MRF(-C) MODEL F-2000MRF3(-C) (FINAL) PARTS LIST 71136 ISSUED: DEC. 13, 1999 REVISED: AUG. 8, 2006...

  • Page 3: Material Abbreviations

    ALUMINUM Aluminum COPPER Copper PLASTIC Acrylonitritrile -butadiene - styrene Polyacetal Ethylene vinyl acetate Polyamide = Nylon Polycarbonate Polyethylene Polyester PETP Polyethylene terephthalate = Tetlon Polypropylene Polystyrene PTFE Polytetrafluoroethylene = Teflon Polyurethane Polyvinyl chloride RUBBER Vinyl Nitrile EPDM EP rubber Nitrile butadiene rubber Natural rubber Neoprene SI.R...

  • Page 4: Ice Flaker Assembly

    F-2000MRF(-C), MRF3(-C) A. ICE FLAKER ASSEMBLY H-0, J-0...
  • Page 5 F-2000MRF(-C), MRF3(-C) A. ICE FLAKER ASSEMBLY K-0, K-1, L-0...

  • Page 6: Required Number

    F-2000MRF(-C), MRF3(-C) MODEL INDEX MATERIAL OR DESCRIPTION MODEL NUMBER EVAPORATOR ASSY (F-2000MRF) (F-2000MRF3) EVAPORATOR ASSY (F-2000MRF-C) (F-2000MRF3-C) REFRIGERATION UNIT (F-2000MRF) (F-2000MRF-C) REFRIGERATION UNIT (F-2000MRF3) (F-2000MRF3-C) WATER CIRCUIT ASSY (HS-0115) CHUTE ASSY (HS-0116) (HS-0116) SPOUT ASSY (HS-0117) CONTROL BOX ASSY (F-2000MRF)
  • Page 7 F-2000MRF(-C), MRF3(-C) MODEL MATERIAL OR INDEX DESCRIPTION MODEL NUMBER CHASSIS REAR PANEL ASSY FT SCREW HEX HEAD BOLT 5X12, SS W/WASHER JUNCTION BOX COVER T2 SCREW WASHER BRASS SCREW - GROUNDING BRASS SIDE FRAME (R) FT SCREW TRUSS HEAD SCREW...
  • Page 8 F-2000MRF(-C), MRF3(-C) MODEL INDEX DESCRIPTION MATERIAL OR MODEL NUMBER STRAP T3 SCREW 5X12 RING "O" RING THUMBSCREW SS, ABS PACKING EPDM STRAP STRAP DRIP GUIDE WING NUT M6, SS SIDE PANEL (L) TRUSS HEAD SCREW SS, 4X8 SIDE PANEL (R)

  • Page 9: Evaporator Assembly

    F-2000MRF(-C), MRF3(-C) B. EVAPORATOR ASSEMBLY H-0, J-0, K-0, K-1, L-0...
  • Page 10 F-2000MRF(-C), MRF3(-C) MODEL MATERIAL OR INDEX DESCRIPTION MODEL NUMBER GEAR MOTOR MGZ2400UL- 150E COUPLING HOUSING HEX HEAD BOLT SS, 8X25 WASHER SS, M8 SPLIT LOCK WASHER SS, M8 "O" RING MECHANICAL SEAL HK9A-MN AUGER EVAPORATOR SOCKET HEAD CAP SS, 10X20...
  • Page 11 F-2000MRF(-C), MRF3(-C) C. REFRIGERATION UNIT H-0, J-0, K-0, K-1, L-0...
  • Page 12 F-2000MRF(-C), MRF3(-C) MODEL INDEX MATERIAL OR DESCRIPTION MODEL NUMBER COMPRESSOR (F-2000MRF) CS20K6E-PFV (F-2000MRF-C) COMPRESSOR (F-2000MRF3) CS20K6E-TF5 (F-2000MRF3-C) TERMINAL COVER (F-2000MRF) (F-2000MRF-C) TERMINAL COVER (F-2000MRF3) (F-2000MRF3-C) GROMMET SPACER BOLT PRESSURE SWITCH ACB-2UB04 PRESSURE SWITCH BRACKET T2 SCREW RECEIVER TANK RR MN WP450...
  • Page 13 F-2000MRF(-C), MRF3(-C) MODEL INDEX DESCRIPTION MATERIAL OR MODEL NUMBER COPPER TUBE (B) - HIGH COPPER SIDE COPPER TUBE (C) - HIGH COPPER SIDE COPPER TUBE (D) - HIGH COPPER SIDE HEAT EXCHANGER COPPER INDICATOR AMI-1TT3 INSULATION TUBE L=30 INSULATION TUBE...

  • Page 14: Water Circuit

    F-2000MRF(-C), MRF3(-C) D. WATER CIRCUIT H-0, J-0...
  • Page 15 F-2000MRF(-C), MRF3(-C) D. WATER CIRCUIT J-0, K-0, K-1, L-0...
  • Page 16 F-2000MRF(-C), MRF3(-C) MODEL INDEX DESCRIPTION W ATER SUPPLY PIPE T2 SCREW W ATER VALVE BRACKET (A) TRUSS HEAD SCREW W ATER VALVE W ASHER INLET - RESERVOIR RESERVOIR COVER - RESERVOIR FLOAT SW ITCH SEPARATOR - RESERVOIR FITTING T2 SCREW...
  • Page 17 F-2000MRF(-C), MRF3(-C) MODEL INDEX DESCRIPTION CLAMP HOSE CLAMP CLAMP HOSE CLAMP CABLE TIE HOSE CLAMP HOSE CLAMP COLLAR THUMBSCREW TITLE MATERIAL PART OR MODEL NUMBER NUMBER MH-30N 421642-04 4A2017-08 SK-18.3 435934-06 4A2017-05 CV-150 7920-0003 4A2017-01 4A2017-02 423416-03 415949G04 D. WATER CIRCUIT...

  • Page 18: Chute Assembly

    F-2000MRF(-C), MRF3(-C) E. CHUTE ASSEMBLY H-0, J-0, K-0...
  • Page 19 F-2000MRF(-C), MRF3(-C) E. CHUTE ASSEMBLY K-1, L-0...
  • Page 20 F-2000MRF(-C), MRF3(-C) MODEL INDEX DESCRIPTION CHUTE INSULATION - CHUTE BAFFLE (A) - CHUTE BAFFLE (B) - CHUTE W ING NUT BIN CONTROL BIN CONTROL ASSEMBLY ACTUATOR SHAFT SNAP PIN PLATE THUMBSCREW THUMBSCREW PROXIMITY SW ITCH COVER - SW ITCH TRUSS HEAD SCREW PACKING E.

  • Page 21: Spout Assembly

    F-2000MRF(-C), MRF3(-C) F. SPOUT ASSEMBLY H-0, J-0, K-0, K-1, L-0...
  • Page 22 F-2000MRF(-C), MRF3(-C) MODEL INDEX DESCRIPTION SPOUT ACTUATOR BELT SWITCH SWITCH COVER THUMBSCREW LABEL - DIRECTION F. SPOUT ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER NUMBER 105378G01 327038-01 BS500 440973-01 327037-01 SS, ABS 415949G04 PVC FILM 442816-01 REQUIRED NUMBER K-0 K-1...

  • Page 23: Control Box Assembly

    F-2000MRF(-C) G. CONTROL BOX ASSEMBLY H-0, J-0, K-0, K-1, L-0...
  • Page 24 F-2000MRF(-C) MODEL MATERIAL INDEX DESCRIPTION OR MODEL NUMBER CONTROL BOX COVER - CONTROL BOX TRUSS HEAD SCREW TIMER SCREW #6-32x3/8 CONNECTOR TRANSFORMER BE141625GEK T2 SCREW RELAY LY2ZF, AC24V RELAY LY1F-HSD, AC220/240V RELAY LY3F, AC120V TAPPING SCREW MAGNETIC CONTACTOR A77-309040A- TRUSS HEAD SCREW...
  • Page 25 F-2000MRF(-C) MODEL DESCRIPTION INDEX FUSE ROCKER SWITCH LAMP PROTECTOR 12P PLUG HOUSING 6P PLUG HOUSING 02P PLUG HOUSING G. CONTROL BOX ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER NUMBER 4A0893-01 4A0558-01 62111929-0-0- 621T-2 446400-01 4A1821-01 W28xQ1A10, 440972-01 412832-04 3191-12P 412832-03...
  • Page 26 F-2000MRF3(-C) G. CONTROL BOX ASSEMBLY H-0, J-0, K-0, K-1, L-0...
  • Page 27 F-2000MRF3(-C) MODEL INDEX DESCRIPTION CONTROL BOX COVER - CONTROL BOX TRUSS HEAD SCREW TIMER SCREW CONNECTOR TRANSFORMER T2 SCREW RELAY RELAY TAPPING SCREW MAGNETIC CONTACTOR TRUSS HEAD SCREW TIMER BOARD BOARD SUPPORT CAPACITOR STRAP T2 SCREW FUSE HOLDER G. CONTROL BOX ASSEMBLY TITLE MATERIAL PART...

  • Page 28: Rocker Switch

    F-2000MRF3(-C) MODEL INDEX DESCRIPTION FUSE ROCKER SWITCH LAMP PROTECTOR 12P PLUG HOUSING 6P PLUG HOUSING 02P PLUG HOUSING 03P PLUG HOUSING SLIDE SWITCH G. CONTROL BOX ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER NUMBER 4A0893-01 4A0558-01 62111929-0-0-N 621T-2 446400-01 4A1821-01 440972-01 W28xQ1A10, 10A 412832-04...

  • Page 29: Fan Motor Assembly

    F-2000MRF(-C), MRF3(-C) H. FAN MOTOR ASSEMBLY H-0, J-0, K-0, K-1, L-0...
  • Page 30 F-2000MRF(-C), MRF3(-C) MODEL INDEX DESCRIPTION BRACKET - FAN MOTOR FAN MOTOR SCREW BUSHING FAN BLADE HEX NUT WASHER H. FAN MOTOR ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER NUMBER 227639-01 440917-02 B8HBER16 436863-01 SB-625-8 420470-01 434959-01 4A1345-01 435983-01 REQUIRED NUMBER...

  • Page 31: Transformer Assembly

    F-2000MRF3(-C) J. TRANSFORMER ASSEMBLY H-0, J-0, K-0, K-1, L-0...
  • Page 32 F-2000MRF3(-C) MODEL INDEX DESCRIPTION TRANSFORMER BASE TRANSFORMER TRUSS HEAD SCREW TRANSFORMER COVER T2 SCREW J. TRANSFORMER ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER NUMBER 340326-01 2U0128-01 7C31-0508 327035-01 7P31-0408 REQUIRED NUMBER...

  • Page 33: Label Location

    F-2000MRF(-C), MRF3(-C) K. LABEL LOCATION...
  • Page 34 F-2000MRF(-C), MRF3(-C) K. LABEL LOCATION J-0, K-0, K-1, L-0...
  • Page 35 F-2000MRF(-C), MRF3(-C) MODEL INDEX MATERIAL DESCRIPTION OR MODEL NUMBER INSTRUCTION SHEET PAPER EMBLEM MODEL NUMBER (F-2000MRF) LABEL MODEL NUMBER (F-2000MRF-C) LABEL MODEL NUMBER (F-2000MRF3) LABEL MODEL NUMBER (F-2000MRF3-C) LABEL LABEL - PENGUIN - HA- INSTRUCTION LABEL PVC FILM LABEL - CLEANING...
  • Page 36 F-2000MRF(-C), MRF3(-C) MODEL INDEX MATERIAL DESCRIPTION OR MODEL NUMBER W IRING LABEL (F-2000MRF) (F-2000MRF-C) (F-2000MRF3) (F-2000MRF3-C) TAG - FAN MOTOR LEADS CAUTION LABEL CAUTION REMOTE LABEL LABEL - CHARGE MANUAL LABEL - TAP SW ITCH CAUTION TAPE – 404A L=250...
  • Page 37 F-2000MRF(-C), MRF3(-C) K. ACCESSORIES H-0, J-0, K-0, K-1, L-0...
  • Page 38 F-2000MRF(-C), MRF3(-C) MODEL INDEX DESCRIPTION INSTRUCTION MANUAL UNIVERSAL BRACE HEX HEAD BOLT LABEL – FASTENER TITLE MATERIAL PART OR MODEL NUMBER NUMBER PAPER 91U2CS10 4A0363-01 SS, 5X12 7B02-0512 PAPER 427122-01 K. ACCESSORIES REQUIRED NUMBER K-0 K-1...
