Hoshizaki F-2000MLH Instruction Manual

Modular flaker
Hide thumbs Also See for F-2000MLH:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
Reliability is a
beautiful thing
TM
INSTRUCTION MANUAL
MODULAR FLAKER
F-2000MLH(-C)
ISSUED:
February 22, 2002
REVISED: December 30, 2004

Advertisement

Table of Contents
loading

Related Manuals for Hoshizaki F-2000MLH

Summary of Contents for Hoshizaki F-2000MLH

  • Page 1 Reliability is a beautiful thing MODULAR FLAKER INSTRUCTION MANUAL F-2000MLH(-C) ISSUED: REVISED: December 30, 2004 February 22, 2002...
  • Page 2 HOSHIZAKI provides this manual primarily to assist qualified service technicians in the installation, maintenance and service of the icemaker. Should the reader have any questions or concerns which have not been satisfactorily addressed, please call or write to the HOSHIZAKI Technical Support Department for assistance.

  • Page 3: Table Of Contents

    • Keep this manual with the icemaker for later reference. I. Specifications ... 4 1. Nameplate Rating ... 4 2. Dimensions/Connections ... 5 [a] F-2000MLH, F-2000MLH-C ... 5 [b] With Storage Bin ... 6 II. Installation and Operating Instructions ... 7 1. Checks Before Installation ... 7 2.

  • Page 4: Specifications

    This nameplate is located on the right hand side of rear panel. We reserve the right to make changes in specifications and design without prior notice. NOTE: Only the “MODEL NUMBER” is replaced for F-2000MLH-C. HOSHIZAKI ICE MAKER 120V 5.6FLA 0.54HP 115V 0.51FLA...

  • Page 5: Dimensions/Connections

    2. Dimensions/Connections Unit = inches [mm.] [a] F-2000MLH, F-2000MLH-C...

  • Page 6: [B] With Storage Bin

    [b] With Storage Bin Unit = inches [mm.]...

  • Page 7: Installation And Operating Instructions

    5) See the nameplate on the rear panel, and check that your voltage supplied corresponds with the voltage specified on the nameplate. 6) This icemaker needs a storage bin. The recommended storage bin is HOSHIZAKI ICE STORAGE BIN, Model B-500 series.

  • Page 8: Location

    7) The flake size is adjustable to small (fine flakes) or large (coarse flakes). The unit is shipped from the factory to produce fine flakes. To produce coarse flakes, the upper cutter head must be removed. If adjustment is desired, please contact an authorized Hoshizaki service company. WARNING Fig. 2...
  • Page 9 8) Replace the top panel and the front panel in their correct positions, and secure the front panel with the screw. 9) Install enough length of two copper tubings provided with Aeroquip couplings between the icemaker and the condensing unit. The liquid line should be 3/8” OD and the suction line should be 5/8”...

  • Page 10: Electrical Connection

    5. Electrical Connection 1. Electrical connection must be made in accordance with the instructions on a “WARNING” tag provided with the pig tail leads in the junction box. 2. This icemaker requires a ground that meets the national and local electrical code requirements.

  • Page 11: Water Supply And Drain Connections

    6. Water Supply and Drain Connections - See Fig. 5 • External filters, strainers or softeners may be required depending on the water quality. • Water supply inlet is 1/2" female pipe thread (FPT). Note: On water-cooled model, two water supply inlets are provided. One is for ice making water, and the other is for cooling water.

  • Page 12: Final Checklist

    7. Final Checklist 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within +45°F to +100°F and the water temperature within +45°F to +90°F all year around? 3) Is there at least 6" clearance at rear and sides and 24" at top for maintenance or service? 4) Have all shipping carton, tape(s) and packing been removed from the icemaker? 5) Are all components, fasteners and thumbscrews securely in place?

  • Page 13: Startup

    8. Startup 1. The evaporator pressure regulator should be adjusted. (See “II. 4. Setup.”) The other parts are factory-adjusted. Improper adjustments may result in failure. 2. If the unit is turned off, wait for at least 3 minutes before restarting the icemaker to prevent damage to the evaporator.

  • Page 14: Preparing The Icemaker For Long Storage

    9. Preparing the Icemaker for Long Storage - See Fig. 6 When shutting off the icemaker for an extended time, drain out all water from the water line and remove the ice from the storage bin. The storage bin should be cleaned and dried.

  • Page 15: Cleaning And Maintenance

    [a] Cleaning Solution Dilute 4.8 fl. oz. (142 ml) of recommended cleaner Hoshizaki “Scale Away” or “LIME-A-WAY” (Economics Laboratory, Inc.) with 0.8 gallons (3 l) of warm water. This is a minimum amount. Make more solution if necessary.

  • Page 16: [C] Sanitizing Solution

    9) Pour the cleaning solution over the extruding head until the evaporator assembly and the reservoir are filled and the solution starts to overflow into the drain pan. Note: If there is excess scale on the extruding head, fill the evaporator assembly and reservoir as described above, then use a clamp on the reservoir hose between the reservoir and evaporator assembly to block flow.

  • Page 17: [E] Sanitizing Procedure - Final

    4) Pour the sanitizing solution over the extruding head until the evaporator assembly and the reservoir are filled and the solution starts to overflow into the drain pan. 5) Remove the thumbscrews securing the proximity switch to the chute assembly. 6) Remove the chute assembly from the icemaker.
  • Page 18 5) Remove the strap connecting the spout to the chute assembly. 6) Remove the thumbscrews securing the spout and lift it off. 7) Pour the sanitizing solution over the extruding head until the evaporator assembly and the reservoir are filled and the solution starts to overflow into the drain pan. 8) Replace the spout and strap in their correct positions.

  • Page 19: Maintenance Instructions

    More frequent inspection and maintenance are recommended. Consult with your local distributor about inspection and maintenance service. To obtain the name and phone number of your local distributor, call Hoshizaki Technical Support at 1-800-233-1940 in the USA. 1) Stainless Steel Exterior To prevent corrosion, wipe the exterior occasionally with a clean and soft cloth.
  • Page 20 HOSHIZAKI HOSHIZAKI AMERICA, INC. 618 HIGHWAY 74 SOUTH PEACHTREE CITY, GA 30269 U.S.A. PHONE: 770-487-2331 www.hoshizakiamerica.com 91A2MD10D...
