Nano Tech UV-C
DISINFECTION SYSTEM
A NON-CHEMICAL APPRORACH TO WATER SANITIZATION
For above-ground and residential pools water disinfection
USER MANUAL
Model: NT-UV Series
EMUV21081846
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for emaux NT-UV Series
Summary of Contents for emaux NT-UV Series
- Page 1 Nano Tech UV-C DISINFECTION SYSTEM A NON-CHEMICAL APPRORACH TO WATER SANITIZATION For above-ground and residential pools water disinfection EMAUX WATER TECHNOLOGY CO., LTD ADDRESS FLAT A-D, 20/F., KAI BO 22, 22 WING KIN ROAD, USER MANUAL KWAI CHUNG, HONG KONG...
-
Page 2: Table Of Contents
TABLE OF CONTENT SAFETY WARNINGS ..1. ２ ..2. INTRODUCTION ３ 2.1. HOW ULTRAVIOLET DISINFECTION WORK? 2.2. HOW OZONE DISINFECTION WORK? ..3. MAIN ADVANTAGES ４ ..4. TECHNICAL SPECIFICATIONS ５ 4.1 WATER CHEMISTRY 4.2 DIMENSIONS ..5. INSTALLATION ６ 5.1 PLUMBING INSTALLATION 5.2 TYPICAL INSTALLATION 5.3 INSTALLATION OPTIONS 5.4 NT-UV130F AND NT-UV130-TF WITH FLOW SWITCH INSTALLATION 5.5 NANO-TECH UV-C OZONE SYSTEM... -
Page 3: Safety Warnings
During the warranty period, Emaux authorized reseller will repair or replace defective parts with new parts or, at the option of Emaux, serviceable used parts that are equivalent or superior to new parts in performance. IMPORTANT: The instruction manual you are holding includes essential information on the This Limited Warranty extends only to products purchased from Emaux authorized reseller. -
Page 4: Introduction
Stainless steel body 620145462 E130404 Closed pipe clips Emaux has developed a special model which combines the ozone and UV-C technology in one unique equipment E130413 UV130-F ballast (see technical specifications for NT-UV87-TO). Nano-Tech UV-C & Ozone (NT-UV87-TO model) contains a high intensity Ultraviolet lamp different from the... -
Page 5: Main Advantages
NT-UV87-TO The ozone produced is introduced into the water stream by Venturi effect. Finally, the Ozone and the ultraviolet radiation will work together to destroy micro-organism such as moulds, Legionella bacteria, parasites, algae or viruses, and also breaks down urine, transpiration, cosmetics and sun cream particles without leaving any by-products (Figure 1). -
Page 6: Technical Specifications
NT-UV40T & NT-UV75T Ozone advantages (only NT-UV87-TO) 1. Protects your pool against pathogenic organism and algae 2. Environmentally friendly 3. No risk of allergies 4. Non-irritating to skin 5. Corrosion and Odour-free 6. Reduce chlorine consumption up to 90% 7. Ozone lamp life of 10000 hours 8. -
Page 7: Dimensions
4.2 DIMENSIONS NT-UV40 & NT-UV75 9 8 1011 Way 1 Way 2 UV-16 UV40-T / UV75-T UV130-TF Key No. Part No. Description E130423 End Cap for Cable Hole With Epoxy 111040015 Lamp connector O'ring E130426 40W UV lamp E130427 75W UV lamp Way 1 Way 2 UV87-TO... -
Page 8: Typical Installation
To achieve the correct installation, please follow the recommendations listed below: 13. SPARE PART LIST 1. Never install the UV-C system in an area exposed to full sunlight. This equipment must be in stalled in a dry and ventilated area. 2. -
Page 9: Installation Options
5.3 INSTALLATION OPTIONS 12. TROUBLE SHOOTING The dark blue transparent end cap and union set is inter changeable for all models, it can be place on either side. It is necessary to place and tighter the O-ring properly to prevent water leakage when doing relocation. There are two sets of 1.5”... -
Page 10: Nt-Uv130F And Nt-Uv130-Tf With Flow Switch Installation
5.4 NT-UV130F and NT-UV130-TF with Flow Switch installation Yellow color output connect T5 lamp socket blue and brown wire with crimp The flow switch version’s flow switch location is flexible to fit into the actual environment water flow direction. It can be placed from left side or right side, and top to bottom or bottom to top flow direction. Red color output connect T5 lamp socket black and yellow green wires with crimp Flow Switch 11.4 GROUNDING... - Page 11 VENTURI INSTALLATION GUIDE NT-UV130TF Timer version, remove the white color jumper and connect the flow switch red and black cable. Follow the instructions procedure below for installing the Nano-Tech UV Ozone System: From Power Cord 1. Fit the manometer (A) onto the Venturi circuit using Teflon tape. Hand-tighten the manometer. 2.
-
Page 12: Start Up
6. START UP NEMA GFCI Receptacle Before starting up the UV-C system, perform the following actions: 1. Back wash the filter and make sure it is completely clean. 2. Make sure the pool does not contain copper, iron nor algae. 3. -
Page 13: Uv Lamp Lifetime Meter
7.2 UV LAMP LIFETIME METER 10. STAINLESS STEEL HOUSING MAINTENANCE As soon as the above mentioned model with Timer is switched on, the program will carry out a self-test. The display will automatically show the following code: 8888 (display test); software version number; 50Hz or 60Hz The stainless steel interior can be cleaned with a soft brush. -
Page 14: Schedule Timer Setting
7.4 SCHEDULE TIMER SETTING 9. LAMP AND QUARTZ GLASS MAINTENANCE AND REPLACEMENT This function allows you to schedule the working hours desired for the proper disinfection of the pool. It must be set in every hour. The device must be cleaned twice a year. If there is an increase in algae and / or scale, the quartz glass tube in 1.
