Front Panel Diagnostic Messages; Front-Panel Read-Only Settings Using Mode - ADC HiGain H2TU-C-202 Quick Installation

Message Description
A=xx The loop attenuation of the longest (maximum loss) span, measured in dB.
ACQ The multiplexers of the HLU and H2TU-R are trying to establish synchronization.
ARM Armed to respond to Intelligent Repeater Loop (ILR) codes.
BAD RT? The H2TU-C is not receiving a response from the H2TU-R.
FERR A framing bit error occurred at H2TU-C DSX-1 input.
FLDL Flash download of firmware updates. (Contact Customer Service for update
procedures.)
HES H2TU-C HDSL2 loop cyclical redundancy check (CRC) error.
LBPV A local bipolar violation has been received at the DSX-1 input to the H2TU-C.
M=xx Indicates the power of the received HDSL2 signal relative to noise (S/N with respect to 21.5
dB). Any value of 6 dB or greater is adequate for reliable system operation.
MNGD The H2TU-C is under control of the HMU-319 network management unit.
PWR FEED OFF HDSL2 span power is turned off.
PWR FEED ON Indicates that the HDSL2 loop is not grounded or shorted.
SIG The transceivers of the H2TU-C and H2TU-R (or the H2TU-C and first regenerator) are
trying to establish contact with each other on Span 1 of the HDSL2 loop.
Description (Default selections in bold. To scroll, press the MODE button for 3
Message
seconds.)
VER x.xx Software version number x.xx.
LIST xx List number of the H2TU-C-231.
FRM xxxx Frame (SF, ESF, UNFR).
CODE xxxx Line code setting (AMI or B8ZS).
LATT xx Loop Attenuation threshold setting (38).
MARG xx Margin threshold setting (4).
EQL Sets the DSX-1 Equalizer to: EXT (replaces internal equalizer with external equalizer), 0 (0
to 132 ft.), 133 (133 to 265 ft.), 266 (266 to 398 ft.), 399 (399 to 532 ft.), 533 (533 to 655
ft.).
RLBO Sets the H2TU-R line buildout to 0 dB, -7.5 dB, or -15 dB.
LPBK Enables (ENA) or disables (DIS) SmartJack loopback commands.
SPLB xxxx Configures system for generic (GNLB) or special inband loopback commands (A1LB, A2LB, A3LB,
A4LB, A5LB).
PWRF OFF = disables HDSL2 powering; ON = HDSL2 line voltage is -185 Vdc maximum.
HBER 1E-6 or 1E-7 = alarm activates when the HDSL2 BER alarm threshold exceeds 10
NONE = prevents generation of a system alarm due to BER.
DBER Enables (ENA) or disables (DIS) fixed 24-hour DSX-1 BER alarm threshold.
LBTO Loopback timeout = NONE, 20, 60, 120 minutes.
ALM Enables (ENA) or disables (DIS) alarm indications on pins 20 and 21.
DS1 DSX-1 line code = Bipolar with 8-Zero Substitution (B8ZS), Alternate Mark Inversion (AMI).
CONV H2TU-R frame format conversion = OFF (framing determined by the DS1 FRMG option),
ACON (autodetection of framing and potential frame conversion at the H2TU-R), or
FCON (autodetection of framing and forced frame format conversion at the H2TU-R).
FRMG DS1 frame formatting = AUTO (auto framing mode) or UNFR (unframed mode),
RDA Enables (ENA) or disables (DIS) alarm indications due to remote DS1 LOS at H2TU-R input.
ALMP Enables system to output an alarm pattern: Alarm Indication Signal (AIS) or Loss of Signal
(LOS).
BPVT Enables (ENA) or disables (DIS) Bipolar Violation Transparency (BPVT).
NLBP Enables the H2TU-R to transmit either AIS or LOS towards CI for any network loopback.
TLOS Enables (ENA) or disables (DIS) a logic loopback at the H2TU-R when an LOS occurs at its
DS1 input.
PRM OFF = no enhanced Performance Report Messaging; SPRM = Supplemental PRM;
NPRM = Network PRM; S + N = SPRM + NPRM.
NAIS If ALMP is set to AIS, this option specifies which pattern is sent to the network when a
remote LOS or AIS occurs. CI = AIS-CI sent to the network; AIS = AIS sent to the network.
ROVR Enables (ENA) or disables (DIS) conversion of an ESF DS1 payload from the network with
an embedded RAI pattern to an SF-RAI pattern toward the CI at the H2TU-R. CONV option
must be set to FCON or ACON.
RACI Enables (ENA) or disables (DIS) conversion of a DS1 RAI (yellow alarm) signal received by
the H2TU-R to be converted to an RAI-CI signal toward the network.
PBON Configures the power output levels of the HLU network unit toward the network.
PBOC Configures the power output levels of the H2TU-R customer unit toward the customer.
