  • Page 1 User Manual Please read the instructions carefully before use...

  • Page 2: Safety Instructions

    TABLE OF CONTENTS 1. Safety Instructions..................... 2 2. Technical Specifications...................4 3. How To Control The Unit..................5 4. Trouble shooting......................9 5. Fixture Cleaning...................... 10 statement product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included guarantee,...

  • Page 4: Fixture Cleaning

    5. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics. ...
  • Page 5  The unit is for indoor use only. Use only in a dry location.  The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surfaces. Be sure that no ventilation slots are blocked. ...

  • Page 6: Technical Specifications

     The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged. Caution: There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact your nearest dealer.
  • Page 7 some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2. Measure the mains voltage on the main connector. 3. Check the power on LED. B.

  • Page 8: Troubleshooting

    to fast Pan/Tilt motor From fast to slow 0----255 speed Dimmer 0-100% 0----255 Null 0----15 Strobe Strobe from slow to fast 16----255 0-100% 0----255 0-100% 0----255 0-100% 0----255 0-100% 0----255 0-100% 0----255 0-100% 0----255 0-100% 0----255 0-100% 0----255 Effect 0----255 Effect speed From fast to slow 0----255...

  • Page 9: How To Control The Unit

    Pan/Tilt Pan/Tilt: 540°/ Infinite rotation Pan/Tilt Resolution: 8bit Construction Display: LED Display Data In/Out socket: 3-pin XLR sockets Protection Rating: IP20 3. How To Control The Unit 1. Detailed function: [dXXX] Setting DMX address DMX channel set Setting channel mode among 19CHS/15CHS [SLoU]...
  • Page 10 [rPAn] Setting Pan reverse [tiL] Setting Tilt [rtiL] Setting Tilt reverse [diS] Display forward setting menu [rdiS] Display reverse setting menu Reset [Reset] Restore factory setting [LoAd] DMX 15 channel Pan rotation 0----255 Pan fine Pan fine adjustment 0----255 Tilt Tilt rotation 0----255 Tilt fine...
  • Page 11 to fast Pan/Tilt motor From slow to fast 0----255 speed Dimmer 0-100% 0----255 Null 0----15 Strobe Strobe from slow to fast 16----255 Red Dimmer 0-100% 0----255 Green Dimmer 0-100% Blue Dimmer 0-100% 0----255 White Dimmer 0-100% 0----255 Effect 0----255 Effect speed From fast to slow 0----255 Null...
