- Page 1 Instruction Manual G-Series Rear View Replacement Mirror Monitor with Built-in Dash Camera RVS-M632 RVS Systems, Inc. © 2015 Reverse With Confidence ™...
- Page 2 Introduction....... 03 Safety Information......04-06 Before Beginning Installation .
- Page 3 NOTE! Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System! With this manual you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle.
- Page 4 Please read the entire manual and follow the instructions and warnings carefully. Failure to do so can cause serious damage and/or injury, including loss of life. Be sure to obey all applicable local traffic and motor vehicle regulations as it pertains to this product. Improper installation will void manufacturer’s warranty.
-
Page 5: Installation
INSTALLATION: • Electric shock or product or disconnected wire may cause a malfunction may occur if this fire. product is installed incorrectly. • While installing the Rear View System be careful with the wire • Use this product within positioning in order to avoid wire the voltage range specified. - Page 6 If you have questions about this product, contact: RVS Systems 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
- Page 7 Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly.
- Page 8 Replacement Monitor The mirror monitor replaces the existing car mirror. Carefully remove the mirror off the “pin”. Slide the replacement mirror on to the pin and secure it with the screw provided (already in the screw hole).Differ- ent cars have different brackets. Depending on your vehicle make and manufacturer.
- Page 9 Wiring After connecting the camera to the “camera cable” connect the camera cable to the input on the wiring harness using the RCA adapter. Connect the RED 12V power wire to an ignition power source and the BLACK 12V ground wire to a chassis ground. The GREEN wire is the REVERSE trigger wire.
- Page 10 FIGURE 1.1 Different cars have different brackets. It depends on your vehicle maker and manufacturer. There are many methods to remove the original rear-view mirror, however, please don’t force the mirror off the bracket. The manufacturer will not be responsible for any damage caused to your car by an incorrect installation of the mirror.
- Page 11 FIGURE 1.2 When a camera is to be installed at the rear of vehicle, a good position is usually at the top of the license plate where there is an under ledge. Reverse With Confidence ™...
- Page 12 FIGURE 2.2 RVS Systems...
- Page 13 Reverse With Confidence ™...
- Page 14 Grid Lines Generally, to help drivers estimate the distance from obstacles, there are three lines for reference- red, yellow, and green. Those three lines are dis- played on the monitor when car is reversing. The green line is 3M from the back of the car and the yellow line is 6.5 ft.
- Page 15 Long press settings button (middle button) to enter into “guide line adjustment” mode.The settings on top are for the left grid line and the bottom are for the right. Press the “Settings” button (middle button) to toggle between the the two. The up, down , left and right buttons are to adjust the location of guide lines.
-
Page 16: Specifications
About Our Monitor 10.25” 3” SPECIFICATIONS: Screen Size: 4.3” Display Screen: TFT-LCD Display Resolution: 400(H)x234(V) Aspect Ratio: 16:9 Color Depth: 16.7M dithering Pixel Pitch (mm) 0.219x0.219 Power Consumption: Working Voltage: DC12V VIDEO-IN to GPS/DVD Video Input: (Default) Camera to backup camera Signal System: PAL/Auto/NTSC RVS Systems... -
Page 17: Glass And Bracket
Glass and bracket The thickness of our mirror’s glass is 4mm. It is strong enough to bear impact and reach every country’s safety standards on rear view mirrors. OEM bracket for special rearview mirror monitor with 21mm- thickness pipe. FIGURE 2.1 RED- Power (+) YELLOW- Video GREEN- Mirror / Normal Imaging... -
Page 18: System Time
Language There are 10 languages available. To enter the settings menu you need to first stop recording. Press “MENU” button twice to enter system setting menu. Scroll to “Language” with “UP” and “DOWN” buttons. Press “REC” to choose a different language. System time Each video file will be marked with a date and time. -
Page 19: Video Size
Video size The full HD DVR mirror can record video in four kinds of video quality. They are HDR 1920*1080 30FPS - 1920*1080 30FPS - 1280*720 60FPS and 1280*720 30FPS. To adjust this, first stop the recording. Press “MENU” button to enter system setting menu. - Page 20 Record recycle This full HD DVR mirror captures every moment in high quality. The high performance compression chip-set ensures seamless record. To ensure that it is always recording, new recorded video will auto overwrite the pre-re- corded video. When record recycle is on, you can set the length of the video files (1,3,5 min).
- Page 21 G sensor and event recording With the G-sensor function, when the system detects a strong acceleration, deceleration or excessive shaking, the mirror will automatically save the video as an “event file”. The event file will be locked and cannot be overwritten in re- cord cycle mode.
-
Page 22: Motion Detect
When recording is stopped, press “MODE” twice to enter playback menu. Use the“UP” and “DOWN” buttons to switch between normal video file list and event video file list. Motion Detect Functions of Motion Detect As memory of the SD card is limited, some may want to only record the most rel- evant video. - Page 23 Diagram of Sensitivity Level Parking Mode Safety Concerns of Parking Mode WARNING: Due to the system being on and drawing power even when the vehicle is off, parking mode will drain the battery on your vehicle. Please be sure not to use this function if you do not have a power regulator or backup power.
- Page 24 How To Set Parking Mode Stop recording and press the “MENU” button to enter the video setting menu. Find and choose “Parking Mode” using the “UP” and “DOWN” buttons. Press “REC” to set the working length of parking mode or turn it off. You can choose from 30 mins/1 hour/6 hours/12 hours/Off.
- Page 25 Video Watermark - Turn On/Turn Off/ Set Drive ID Stop recording and press “MENU” button to enter video setting menu. Find and choose “Driver ID Setting” with the “UP” and “DOWN” buttons. Press “UP”/ “Down” buttons to choose the right number and press “REC” button to switch the number to another. After setting the Driver ID number, press “DOWN”...
-
Page 26: Auto Power Off
Customized set user’s name Stop recording and press the “Menu” button to enter the video setting menu. Using the “UP” and “DOWN” buttons, choose “Custom name setting”. Press the “UP” and “DOWN” buttons to choose the desired name and press “REC” to make your selection. “Driver ID”, “Speed”... -
Page 27: Auto Screen Off
Auto Screen Off Why do you need auto screen off function? A bright screen can be distracting when driving at night. This function also uses less power. The mirror continues to record even if the screen is off. Set Auto Screen Off The screen can be set to automatically turn off after a set period of inactivity. -
Page 28: Video Recording
Video recording Press the “REC” button to turn video recording on or off. Press “MENU” while recording to save the current video as an “event file”. Event files are locked and cannot be overwritten in record cycle mode. Press “MODE” to switch the volume on or off. Press “DOWN” to save the current frame image if the system is not recording in HDR 1920*1080 30FPS mode. -
Page 29: File Browsing
File browsing When not recording, press “MODE” twice to enter the file browsing interface. Scroll “UP” and “DOWN” to switch between G-Sensor files, normal files, and photos. Press “REC” to enter a file list. Scroll “UP” or “DOWN” to switch between videos, press “REC” to select a video, and press “REC”... - Page 30 Built-in Dash Cam SPECIFICATIONS: CPU: AmbarellaA7LA30 Memory/Flash: 32MB/ 1GB Image Sensor: CMOSOV04689-H67A Video Resolution: HDR1920X1080 30f/ 1920x1080 30f/ 1280x720 60f/ 1280x720 30f Display: 4.3” 16:9 TFT Display Memory: SD card (MAX32GB) Focus: 12cm-infinite Photo Format: JPEG Video Format: Audio: Built in microphone and speaker Temperature: -30c°...
- Page 31 Problems Diagnoses Solutions Recording frequently stops 1. Motion detection is on 1. Turn off motion detection 2. The SD card is too small to read and store information 2. Use a larger higher class SD card Camera input is working but no 1.
- Page 32 ONE YEAR WARRANTY RVS SYSTEMS, INC. WARRANTS THIS PRODUCT AGAINST MATERIAL DEFECTS FOR A PERIOD OF ONE YEAR FROM DATE OF PURCHASE. WE RESERVE THE RIGHT TO REPAIR OR REPLACE ANY SUCH DEFECTIVE UNIT AT OUR SOLE DISCRETION. RVS SYSTEMS, INC. IS NOT RESPON- SIBLE FOR A DEFECT IN THE SYSTEM AS A RESULT OF MISUSE, IMPROPER INSTALLATION, DAMAGE OR MISHANDLING OF THE ELECTRONIC COMPONENTS.
- Page 33 DISCLAIMER RVS SYSTEMS AND/OR ITS AFFILIATES DOES NOT GUARANTEE OR PROMISE THAT THE USER OF OUR SYSTEMS WILL NOT BE IN/PART OF AN ACCIDENT OR OTHERWISE NOT COLLIDE WITH AN OBJECT AND/OR PERSON. OUR SYSTEMS ARE NOT A SUBSTITUTE FOR CAREFUL AND CAU- TIOUS DRIVING OR FOR THE CONSISTENT ADHERENCE TO ALL APPLICABLE TRAFFIC LAWS AND MOTOR VEHICLE SAFETY REGULATIONS.
- Page 34 If you have any questions about this product, contact: RVS Systems, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. RVS Systems...
