Summary of Contents for Safe Fleet RVS-218629
- Page 1 Instruction Manual G-SERIES Backup Camera System with 5” Android Operated Display RVS-218629 RVS Systems, Inc. © 2017 Reverse With Confidence ™...
- Page 2 Introduction....... 03-05 Safety Information......06-08 Before Beginning Installation .
- Page 3 NOTE! Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System! With this manual you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle.
- Page 4 Function of Buttons GPS Antenna and Cable RVS Systems...
- Page 5 Reverse With Confidence ™...
- Page 6 Please read the entire manual and follow the instructions and warnings carefully. Failure to do so can cause serious damage and/or injury, including loss of life. Be sure to obey all applicable local traffic and motor vehicle regulations as it pertains to this product. Improper installation will void manufacturer’s warranty.
-
Page 7: Installation
INSTALLATION: • Electric shock or product or disconnected wire may cause a malfunction may occur if this fire. product is installed incorrectly. • While installing the Rear View System be careful with the wire • Use this product within positioning in order to avoid wire the voltage range specified. - Page 8 If you have questions about this product, contact: RVS Systems 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
- Page 9 Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly.
- Page 10 Replacement Monitor The mirror monitor replaces the existing car mirror. Carefully remove the mirror off the “pin”. Slide the replacement mirror on to the pin and secure it with the screw provided (already in the screw hole).Differ- ent cars have different brackets. Depending on your vehicle make and manufacturer.
- Page 11 Wiring After connecting the camera to the “camera cable” the camera should be plugged into AV2 input. Connect the RED 12V power wire to an ignition power source, and the BLACK 12V ground wire to a chassis ground. The GREEN wire is the REVERSE trigger wire. Connect this wire to the vehicle’s backup light circuit to activate the rear-view image whenever the vehicle shifts into reverse.
- Page 12 Grid Lines Generally, to help drivers estimate the distance from obstacles, there are three lines for reference- red, yellow, and green. Those three lines are dis- played on the monitor when car is reversing. The green line is 3M from the back of the car and the yellow line is 6.5 ft.
- Page 13 FIGURE 1.1 FIGURE 1.2 Reverse With Confidence ™...
- Page 14 How to Wire FIGURE 2.1 RVS Systems...
- Page 15 Reverse With Confidence ™...
- Page 16 FIGURE 2.2 RVS Systems...
-
Page 17: Highly Reflective Mirror
Highly Reflective Mirror In addition to being a monitor, the system is also a highly reflective mirror. Normal mirror Highly reflective mirror Back up Camera Display When the car is put into reverse, the monitor will automatically display the backup camera. Reverse With Confidence ™... - Page 18 Main Menu There are 6 icons on the main menu interface. They are easy to use and can be changed based on preference. The icons are the same as those on an Android cellphone. Booting APP Setting Applications can be set to automatically boot up when the mirror is turned Press to enter the app list, and press for auto-boot menu.
- Page 19 Up to five applications can be set to automatically start. The user can also control how long the app will remain on if inactive after startup, as well as if the app will start running in the foreground or background. Applications can also be deleted from the auto-boot list in this display.
- Page 20 Mapping Data Though mapping data is not included with this system, users may down- load or buy navigation software. RVS Systems...
-
Page 21: Specifications
About Our Monitor 10.25” 3” SPECIFICATIONS: Screen Size: 4.3” Display Screen: TFT-LCD Display Resolution: 400(H)x234(V) Aspect Ratio: 16:9 Color Depth: 16.7M dithering Pixel Pitch (mm) 0.219x0.219 Power Consumption: Working Voltage: DC12V VIDEO-IN to GPS/DVD Video Input: (Default) Camera to backup camera Signal System: PAL/Auto/NTSC Reverse With Confidence ™... - Page 22 About Camera SPECIFICATIONS: RVS Systems...
-
Page 23: Camera Installation
Camera Installation Mounting Position view angle installation position º Reverse With Confidence ™... - Page 24 No Image On Screen • Do a hard reset, unplug all cables • Verify camera is on correct camera and power cables, leave out for 1 input minute and then re-connect them • Verify cable is connected to • Check to ensure that the monitor connection to the camera is tight •...
- Page 25 ONE YEAR WARRANTY RVS SYSTEMS, INC. WARRANTS THIS PRODUCT AGAINST MATERIAL DEFECTS FOR A PERIOD OF ONE YEAR FROM DATE OF PURCHASE. WE RESERVE THE RIGHT TO REPAIR OR REPLACE ANY SUCH DEFECTIVE UNIT AT OUR SOLE DISCRETION. RVS SYSTEMS, INC. IS NOT RESPON- SIBLE FOR A DEFECT IN THE SYSTEM AS A RESULT OF MISUSE, IMPROPER INSTALLATION, DAMAGE OR MISHANDLING OF THE ELECTRONIC COMPONENTS.
- Page 26 DISCLAIMER RVS SYSTEMS AND/OR ITS AFFILIATES DOES NOT GUARANTEE OR PROMISE THAT THE USER OF OUR SYSTEMS WILL NOT BE IN/PART OF AN ACCIDENT OR OTHERWISE NOT COLLIDE WITH AN OBJECT AND/OR PERSON. OUR SYSTEMS ARE NOT A SUBSTITUTE FOR CAREFUL AND CAU- TIOUS DRIVING OR FOR THE CONSISTENT ADHERENCE TO ALL APPLICABLE TRAFFIC LAWS AND MOTOR VEHICLE SAFETY REGULATIONS.
- Page 27 Notes Reverse With Confidence ™...
- Page 28 If you have any questions about this product, contact: RVS Systems, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. RVS Systems...
