Summary of Contents for Safe Fleet RVS-218622
- Page 1 Instruction Manual G-SERIES Backup Camera System with Bluetooth RVS-218622 RVS Systems, Inc. © 2017 Reverse With Confidence ™...
- Page 2 NOTE! Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System! With this manual you will be able to properly install and operate the unit. Introduction.
- Page 3 INSTALLATION: Please read the entire manual and follow the instructions and warnings carefully. Failure to do so can cause serious damage and/or • Electric shock or product or disconnected wire may cause a injury, including loss of life. Be sure to obey all applicable local malfunction may occur if this fire.
- Page 4 If you have questions about this product, contact: Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility RVS Systems of them being damaged while vehicle is in use. Keep all cables away 1797 Atlantic Avenue from hot or moving parts and electrical noisy components.
- Page 5 Wiring Replacement Monitor The mirror monitor replaces the existing car mirror. Carefully remove After connecting the camera to the “camera cable” the camera should be plugged into AV2 input. Connect the RED 12V power wire to an igni- the mirror off the “pin”. Slide the replacement mirror on to the pin and tion power source and the BLACK 12V ground wire to a chassis ground.
- Page 6 FIGURE 1.1 FIGURE 2.2 FIGURE 1.2 RVS Systems Reverse With Confidence ™...
- Page 7 About Our Monitor FIGURE 2.1 10.25” 3” SPECIFICATIONS: Screen Size: 4.3” Display Screen: TFT-LCD Display Resolution: 400(H)x272(V) Aspect Ratio: 16:9 Color Depth: 16.7M dithering 1. RED- Power (+) Pixel Pitch (mm) 0.219x0.219 2. YELLOW- Video Power Consumption: 3. GREEN- Mirror / Normal Imaging Working Voltage: DC 9V-32V 4.
- Page 8 About Camera Camera Installation SPECIFICATIONS: Mounting Position view angle installation position º RVS Systems Reverse With Confidence ™...
- Page 9 Grid Lines Generally, to help drivers estimate the distance from obstacles, there are three lines for reference- red, yellow, and green. Those three lines are dis- played on the monitor when car is reversing. The green line is 3M from the back of the car and the yellow line is 6.5ft.
- Page 10 Start Up Manual Bluetooth Connection The first time you use the rear view mirror, Bluetooth will automati- If your phone is not connected to the rear view mirror and the screen cally turn on when the car is started. Wait for 1 minute to connect your is off, long press the center button to manually reconnect Bluetooth.
- Page 11 Backup Camera Display And Manual Brightness Adjustment No Image On Screen After installation, place the vehicle in reverse and the backup camera image will automatically display on the monitor. Once this image is • Do a hard reset, unplug all cables •...
- Page 12 ONE YEAR WARRANTY RVS SYSTEMS, INC. WARRANTS THIS PRODUCT AGAINST MATERIAL DEFECTS FOR A PERIOD OF ONE YEAR FROM DATE OF PURCHASE. WE RESERVE THE RIGHT TO REPAIR OR REPLACE DISCLAIMER ANY SUCH DEFECTIVE UNIT AT OUR SOLE DISCRETION. RVS SYSTEMS, INC. IS NOT RESPON- RVS SYSTEMS AND/OR ITS AFFILIATES DOES NOT GUARANTEE OR PROMISE THAT THE USER SIBLE FOR A DEFECT IN THE SYSTEM AS A RESULT OF MISUSE, IMPROPER INSTALLATION, OF OUR SYSTEMS WILL NOT BE IN/PART OF AN ACCIDENT OR OTHERWISE NOT COLLIDE WITH...
- Page 13 If you have any questions about this product, contact: RVS Systems, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. RVS Systems...
