- Page 1 PD-062710-AHD P&D Compliant Fleet Solution 9” Kit 9” Monitor - HD Cameras with 6 Sensors Instruction Manual © Rear View Safety 2021...
-
Page 2: In The Box
IN THE BOX 1 x 9" 3-Channel Split Screen Monitor 6 x Weatherproof Backup Sensor Reversing System 2 x HD 120° Side Cameras 1 x HD 130° Backup Camera 1 x 50 ft Cable 1 x 16 ft Cable 1 x 10 ft Cable 1 x U Bracket 1 x Fan Bracket ©... -
Page 3: Table Of Contents
TABLE OF CONTENTS In The Box....... . . 2 Safety Information ......5-6 Overview. - Page 4 If you have questions about this product, please contact us at: Phone: 888-544-0260 Email: fedex@rearviewsafety.com New York 1797 Atlantic Ave Brooklyn, NY 11233 Indiana 319 Roske Dr. Elkhart, Indiana 46516 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
-
Page 5: Safety Information
SAFETY INFORMATION Please read the entire manual and follow the instructions and warnings carefully. Failure to do so can cause serious damage and/or injury, including loss of life. Be sure to obey all applicable local traffic and motor vehicle regulations as it pertains to this product. -
Page 6: Installation
SAFETY INFORMATION INSTALLATION Electric shock or product malfunction may occur if this product is installed incorrectly. Use this product within the voltage range specified. Failure to do so • can cause electronic shock or product malfunction. Take special care when cleaning the monitor. •... -
Page 7: Overview
OVERVIEW The installed system will consist of: 9 inch split screen monitor which: • - Allows viewing multiple cameras at the same time. - Shows full screen display of camera view when a particular camera is in use. - Issues audible alerts from the rear sensors when an obstacle is detected while vehicle is in reverse. -
Page 8: Required Tools And Supplies
REQUIRED TOOLS & SUPPLIES - Tall ladder and step ladder. - Cordless drill and 1/4” accessories. - Various drill bits. - 3/4”, 7/8” and 1” hole saws. - Various hand tools: wrenches, sockets, screwdrivers, etc. - Wire crimper, wire stripper. - Measuring tape. -
Page 9: Wiring Connections And Component Mounting
WIRING CONNECTIONS AND COMPONENT MOUNTING Component mounting: Rear camera will be mounted with machine screws, nuts, and washers. If there • is no access to the backside of camera location, then self-drilling screws can be used to mount the camera bracket. Side cameras must be mounted with the supplied machine screws, nuts, and •... - Page 10 MONITOR MOUNTING OVERHEAD IN STEP VAN In most cases, the monitor will be mounted on the underside of overhead package shelf of the step van. Mount with machine screws/bolts, nuts and washers. Never use self taping/ • drilling screws for mounting overhead. Sit in driver’s seat to determine the best viewing angle.
-
Page 11: Monitor Mounting Overhead In Step Van
SIDE CAMERAS – STEP VAN Flush Mounting – All Step Vans Note: All step vans should have access on the backside of the fender for flush mounting. Always double check on both sides to verify before drilling any holes. Be sure to check both sides for air vent. Mount the camera below the air vent. If there is no vent on the passenger side, mount the camera at the same height as the driver’s side camera. -
Page 12: Rear Camera Installation - Step Van
REAR CAMERA INSTALLATION - STEP VAN The backup camera will mount above the rear door, in the center if possible, but may need to be offset due to the location of existing running lights. If this is the case, mount between the center light and either left or right center light. Make sure the camera does not block any of the existing lights. - Page 13 CAMERA AND SENSORS PLACEMENT Rear View Safety, 1797 Atlantic Ave., Brooklyn NY 11233 800.764.1028 sales@rearviewsafety.com www.rearviewsafety.com...
-
Page 14: Backup Sensor Overview
BACKUP SENSORS OVERVIEW This system is designed to use 6 backup sensors. Each sensor will be labeled for the corresponding mounting location. Upper sensors: DU = Driver Upper PU = Passenger Upper vehicle width Lower sensors: DO = Driver Outer 1/8L 1/8L DI = Driver Inner... -
Page 15: Sensors And Ecu Placement
ECU PLACEMENT Rear View Safety, 1797 Atlantic Ave., Brooklyn NY 11233 800.764.1028 sales@rearviewsafety.com www.rearviewsafety.com... -
Page 16: Sensor Installation Guidelines
SENSOR INSTALLATION GUIDELINES • Carefully drill a 25mm hole and insert the Rubber Jacket, properly orientated “UP”, in the hole first. Then insert the Sensor, again properly orientated “UP.” • Depending on the thickness and construction of the bumper, the hole diameter may need to be varied. -
Page 17: Sensors Range
SENSORS RANGE Rear View Safety, 1797 Atlantic Ave., Brooklyn NY 11233 800.764.1028 sales@rearviewsafety.com www.rearviewsafety.com... -
Page 18: Cable Routing - Step Van
CABLE ROUTING – STEP VAN Route the upper sensor cable across to the passenger side upper backup sensor. Be sure to secure the cable so that it cannot come in contact with the door spring, cables or door. If using sticky tabs to attach zip ties, add screw in center or add silicone to the perimeter of the sticky tab. - Page 19 Rear View Safety, 1797 Atlantic Ave., Brooklyn NY 11233 800.764.1028 sales@rearviewsafety.com www.rearviewsafety.com...
-
Page 20: Completing The Installation
COMPLETING THE INSTALLATION Verify all cameras function properly: Rear camera displays when the vehicle is put in reverse. • The left side camera displays with the left turn signal. • The right side camera displays with the right turn signal. •... -
Page 21: Connection Diagram
CONNECTION DIAGRAM Filter Red - POWER 3-CHANNEL Yellow - Driver Side Brown - Passenger Side SPLIT SCREEN Blue - BACK Power Harness Black - GROUND MONITOR Passenger Y Cable Side Camera Driver Side Camera Yellow - Reverse Backup Camera 6 Sensors Sensor Sensor Cables... -
Page 22: Monitor Operations
MONITOR OPERATIONS TWO SPLIT THREE SPLIT DOWN ARROW SWITCH VOLUME DOWN CAMERA UP ARROW SELECTION VOLUME UP MENU/ SELECTION ROTATE BUTTON IMAGE EXIT when in FUNCTION Menu mode) NAVIGATING MENU MENU Contrast > Brightness > Saturation > Language > Volume >... -
Page 23: Menu Descriptions
MENU DESCRIPTIONS Brightness, Contrast, Saturation: adjust image properties • Language: choose your language • Volume: adjust volume • Turn: Toggle between mirror/normal image on each individual channel • Distance Grid: Toggle which channel distance grid lines will display on • Grid Position: Adjust grid lines •... -
Page 24: Warranty
THE WARRANTY REAR VIEW SAFETY LLC (“RVS” OR “WARRANTOR”), A SUBSIDIARY OF SAFE FLEET ACQUISITION CORP. (“SAFE FLEET”), WARRANTS TO THE ORIGINAL PURCHASER (“CUSTOMER”) OF THE NEW (NOT USED) EQUIPMENT AND PARTS MANUFACTURED AND SOLD BY RVS TO SUCH CUSTOMER (COLLECTIVELY, THE “PRODUCTS”) THAT EACH OF SUCH PRODUCTS WILL BE FREE FROM MANUFACTURING DEFECTS... -
Page 25: Disclaimer
WARRANTY DISCLAIMERS NO WARRANTY, ORAL OR WRITTEN, EXPRESSED OR IMPLIED, OTHER THE ABOVE WARRANTY IS MADE WITH REGARD TO THIS REAR VIEW SAFETY, INC. REAR VIEW SAFETY, INC. DISCLAIMS ANY IMPLIED WARRANTY OR MERCHANT-ABILITY OR FITNESS FOR A PARTICULAR USE OR PURPOSE AND ALL OTHER WARRANTIES IN NO EVENT SHALL REAR VIEW SAFETY. - Page 26 Engineered For Vehicle Safety If you have questions about this product, please contact us at: Phone: 888-544-0260 Email: fedex@rearviewsafety.com New York 1797 Atlantic Ave Brooklyn, NY 11233 Indiana 319 Roske Dr. Elkhart, Indiana 46516...
