- Page 1 Instruction Manual G-SERIES Backup Camera System with Navigation and Bluetooth RVS-218627 RVS Systems, Inc. © 2017 Reverse With Confidence ™...
- Page 2 Introduction....... 03 Safety Information......04-06 Before Beginning Installation .
- Page 3 NOTE! Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System! With this manual you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle.
- Page 4 Please read the entire manual and follow the instructions and warnings carefully. Failure to do so can cause serious damage and/or injury, including loss of life. Be sure to obey all applicable local traffic and motor vehicle regulations as it pertains to this product. Improper installation will void manufacturer’s warranty.
-
Page 5: Installation
INSTALLATION: • Electric shock or product or disconnected wire may cause a malfunction may occur if this fire. product is installed incorrectly. • While installing the Rear View System be careful with the wire • Use this product within positioning in order to avoid wire the voltage range specified. - Page 6 If you have questions about this product, contact: RVS Systems 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
- Page 7 Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly.
- Page 8 Replacement Monitor The mirror monitor replaces the existing car mirror. Carefully remove the mirror off the “pin”. Slide the replacement mirror on to the pin and secure it with the screw provided (already in the screw hole).Differ- ent cars have different brackets. Depending on your vehicle make and manufacturer.
- Page 9 Wiring After connecting the camera to the “camera cable” the camera should be plugged into AV2 input. Connect the RED 12V power wire to a an ignition power source and the BLACK 12V ground wire to a chassis ground. The GREEN wire is the REVERSE trigger wire. Connect this wire to the vehicle’s backup light circuit to activate the rear-view image whenever the vehicle shifts into reverse.
- Page 10 Grid Lines Generally, to help drivers estimate the distance from obstacles, there are three lines for reference- red, yellow, and green. Those three lines are dis- played on the monitor when car is reversing. The green line is 3M from the back of the car and the yellow line is 6.5 ft.
- Page 11 FIGURE 1.1 FIGURE 1.2 Reverse With Confidence ™...
- Page 12 FIGURE 2.1 1. RED- Power (+) 2. YELLOW- Video 3. GREEN- Mirror / Normal Imaging 4. WHITE- Audio 5. BLACK- Ground (-) RVS Systems...
- Page 13 FIGURE 2.2 Reverse With Confidence ™...
-
Page 14: Navigation Functions And Features
MAIN MENU NAVIGATION FUNCTIONS AND FEATURES The GPS Navigation system uses a satellite signal to display your position on the naviga- tion map. Set your destination, and the system will program the quickest, safest route. Enjoy your trip with navigation features that include realistic onscreen animations, as well as both voice and text indication. -
Page 15: Volume Adjust
1. Map information: The navigation data may not be completely accurate because of changing real time road conditions and construction. Please check road status before your trip and always obey all traffic rules. 2. Navigation: The navigation system should be only used as a reference, as the driver may be more familar with the route than the GPS navigator in some situations. -
Page 16: Navigation Path
NAVIGATION PATH In the setting menu, click the icon to enter navigation path menu. Use this menu to set a navigation path, or to change the auto start option on/off. RVS Systems... -
Page 17: Language Setting
LANGUAGE SETTING In the setting menu, click the icon to enter the language menu. Twelve languages are available. GPS INFORMATION Single click the button to enter GPS menu. In this menu you can reset the GPS, or check GPS information. Reverse With Confidence ™... -
Page 18: System Information
SYSTEM INFORMATION Single click the button to access the system information menu. DEFAULT SET Single click to enter the default settings menu. In this menu you can restore your system to default settings. RVS Systems... -
Page 19: Screen Calibration
SCREEN CALIBRATION Single click the button to enter the screen calibration menu. Click “ok” to start the screen calibration. Follow the instructions, pressing the screen until the calibration succeeds. Click anywhere on the screen to save the calibration and exit to the main interface. - Page 20 ADJUST THE BRIGHTNESS OF MONITOR SCREEN AT NIGHT At night, the monitor brightness adjusts automatically, depending on driving condi- tions. If this is too bright or too dark for the driver, the brightness can be changed man- ually with the remote control. Choose “MENU”, then scroll “SEL/ REC” to choose “NIGHT BRIGHTNESS”, and adjust the brightness of the screen with “UP/DOWN.”...
- Page 21 Note: Avoid storing the card high in temperatures, humidities, or in direct sunlight. Keep the card away from all liquid and corrosive material. BLUETOOTH SETTING AND INSTRUCTIONS This chapter will explain how to connect a cell phone to your system with Bluetooth. OPERATION METHOD Single click the button in main menu to open the Bluetooth menu as shown...
- Page 22 Play music with Bluetooth through your radio Single click button to open the pair/connect menu as shown below. RVS Systems...
- Page 23 Search for Bluetooth devices Reverse With Confidence ™...
- Page 24 Single click the button to modify the name of the device. Single click the button to enter the modify PIN menu. Choose your new pin and choose when you are finished. RVS Systems...
- Page 25 Single click the “Pairing history” button to display the pairing history. Single click the “Search” button to search for Bluetooth devices. Reverse With Confidence ™...
- Page 26 Select your phone, click “Connect”, and input your PIN to connect Bluetooth. The menu shown below will appear if the connection was successful. Notice that icons are now in color and selectable. RVS Systems...
- Page 27 Single click the button to open the dial pad. Reverse With Confidence ™...
- Page 28 Single click the button to make a call. Use the numbers to dial. When you receive a call, it will display “Calls” and show the phone number. RVS Systems...
- Page 29 Single click “HANG UP” to refuse the call or click “ANSWER” to answer. When you answer a call, you will be able to hear the other person through the GPS navi- gator, and talk with them through the GPS navigator microphone. Single click the button to switch between the GPS navigator and your phone.
- Page 30 Single click the button to open the call history. Single click the button to open the A2DP. Use this menu to play music. RVS Systems...
- Page 31 Reverse With Confidence ™...
-
Page 32: Specifications
About Our Monitor 10.25” 3” SPECIFICATIONS: Screen Size: 4.3” Display Screen: TFT-LCD Display Resolution: 400(H)x234(V) Aspect Ratio: 16:9 Color Depth: 16.7M dithering Pixel Pitch (mm) 0.219x0.219 Power Consumption: Working Voltage: DC12V VIDEO-IN to GPS/DVD Video Input: (Default) Camera to backup camera Signal System: PAL/Auto/NTSC RVS Systems... - Page 33 About Camera SPECIFICATIONS: Reverse With Confidence ™...
- Page 34 Camera Installation Mounting Position view angle installation position º RVS Systems...
- Page 35 No Image On Screen • Do a hard reset, unplug all cables • Verify camera is on correct camera and power cables, leave out for 1 input minute and then re-connect them • Verify cable is connected to • Check to ensure that the monitor connection to the camera is tight •...
-
Page 36: One Year Warranty
ONE YEAR WARRANTY RVS SYSTEMS, INC. WARRANTS THIS PRODUCT AGAINST MATERIAL DEFECTS FOR A PERIOD OF ONE YEAR FROM DATE OF PURCHASE. WE RESERVE THE RIGHT TO REPAIR OR REPLACE ANY SUCH DEFECTIVE UNIT AT OUR SOLE DISCRETION. RVS SYSTEMS, INC. IS NOT RESPON- SIBLE FOR A DEFECT IN THE SYSTEM AS A RESULT OF MISUSE, IMPROPER INSTALLATION, DAMAGE OR MISHANDLING OF THE ELECTRONIC COMPONENTS. - Page 37 DISCLAIMER RVS SYSTEMS AND/OR ITS AFFILIATES DOES NOT GUARANTEE OR PROMISE THAT THE USER OF OUR SYSTEMS WILL NOT BE IN/PART OF AN ACCIDENT OR OTHERWISE NOT COLLIDE WITH AN OBJECT AND/OR PERSON. OUR SYSTEMS ARE NOT A SUBSTITUTE FOR CAREFUL AND CAU- TIOUS DRIVING OR FOR THE CONSISTENT ADHERENCE TO ALL APPLICABLE TRAFFIC LAWS AND MOTOR VEHICLE SAFETY REGULATIONS.
- Page 38 If you have any questions about this product, contact: RVS Systems, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. RVS Systems...
