Clas Ohlson 98203 Manual

Doorbell transmitter
Art.no 36-7335 Model 98203
Please read the entire instruction manual before use and
then save it for future reference. We reserve the right for any
errors in text or images and any necessary changes made
to technical data. In the event of technical problems or other
queries, please contact our Customer Services.
Safety
• Never subject the product to high temperatures, damp or
dusty environments, heavy vibrations or impacts.
• Never try to repair the product, dismantle or modify it in
any way.
Installation
Battery/pairing the units
1. Open the transmitter
carefully by pressing
the latch with
a screwdriver.
2. Remove the plastic tab
from the battery holder
to activate the battery in
the remote control.
3. Depending on the type of doorbell that you are connecting:
Insert batteries in the doorbell's battery compartment or
alternatively connect it to a 230 V wall socket.
4. Within 30 seconds,
press the transmitter
that you want to
connect the doorbell to.
The doorbell will sound
when the pairing has been
successful. If you wish to
pair additional transmitters:
Cut off the power supply
to the doorbell, then repeat
steps 3–4.
GREAT BRITAIN • customer service tel: 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk postal 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ
Selecting the ring signal
Once the pairing has been
successful, choose the ring signal
by pressing repeatedly on the button
inside the transmitter. You can
choose between a total of 16
different melodies and sounds.
Handy tip: If you are connecting
several transmitters to the doorbell,
set different signals for each
transmitter so you know at which
door the signal is coming from.
Assembly
Information
• Avoid placing the transmitter next to metal objects such as metal
window frames as this may cause interference with reception.
• Test the doorbell's functionality/location before final mounting.
Transmitter
1. Screw on or glue (with 2. Fit the transmitter onto
double-sided adhesive the backplate, making
tape) the backplate sure that the gasket is
of the transmitter to in place. Press the latch on
the wall. the transmitter until it clicks
into place.
Remove the paired transmitters
Information
If you follow the following steps, it will remove all the paired
transmitters from the doorbell's memory.
1. Dismantle one of the transmitters.
2. Remove the power supply to the doorbell by removing
the batteries or disconnecting it from the wall socket.
Wait a few seconds and insert the batteries again (or
connect it to the wall socket) so that the doorbell is in
pairing mode. The doorbell will sound twice.
3. While the doorbell is in pairing mode, press the button
inside the transmitter. The doorbell will sound to confirm that
all the transmitters have been removed from the doorbell's
memory.
Care and maintenance
Clean the product using a damp cloth. Use only mild cleaning
agents, never solvents or corrosive chemicals.
Troubleshooting
No sound when • Check that the batteries are inserted
the push button correctly and that they are not flat.
is pressed. • Excessive distance between
the transmitter and the doorbell.
Responsible disposal
This symbol indicates that this product
should not be disposed of with general
household waste. This applies throughout
the entire EU. In order to prevent any harm to
the environment or health hazards caused by
incorrect waste disposal, the product must
be handed in for recycling so that the material
can be disposed of in a responsible manner.
When recycling the product, take it to your
local collection facility or contact the place of
purchase. They will ensure that the product
is disposed of in an environmentally sound
manner.
Specifications
Transmission frequency 433.92 MHz
Battery CR2032 lithium (3 V)
Size 35 × 17 × 85 mm
