Clas Ohlson AT-1900 User Manual

Wireless FM transmitter for iPhone
Art.no 38-4070 Model AT-1900
Please read the entire instruction manual before use and save it for future
reference. We reserve the right for any errors in text or images and for making any
necessary technical changes to this document. If you should have any questions
concerning technical problems please contact our Customer Services.

Product description

• Wireless FM transmitter for iPhone/iPod.
• Transmits music wirelessly to an FM radio.
• Can even charge your iPhone/iPod via the micro-USB port.
Compatible with the following types of iPhone or iPod
• iPod touch (3rd generation) • iPod nano (3rd generation)
• iPod touch (2nd generation) • iPod nano (2nd generation)
• iPod touch (1st generation) • iPhone 4
• iPod classic • iPhone 3GS
• iPod nano (5th generation) • iPhone 3G
• iPod nano (4th generation) • iPhone
Buttons and functions
1. Docking port
1
2. Touch control V (down)
3. Display
4. Touch control Λ (up)
5. Micro-USB port
2
• Press V once: The frequency will decrease by 0.1 MHz for every press.
Press Λ once: The frequency will increase by 0.1 MHz for every press.
•
• Press and hold in V: The frequency will decrease in steps of 1 MHz.
Press and hold in Λ: The frequency will increase in steps of 1 MHz.
•
• Press V and Λ simultaneously: A vacant frequency will be tuned in automatically.
Manual tuning
1. Set the radio to a vacant frequency
that is not too close to one that is
already used.
2. Turn on your iPhone/iPod and
connect the FM transmitter which
will start automatically.
3. Use the touch controls on the FM
transmitter to tune into the same
frequency as the radio.
4. Set your iPhone/iPod to play mode.
5. Any music played on the iPhone/
iPod will now be transmitted
to the radio.
GREAT BRITAIN • customer service tel: 08545 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk
Automatic tuning
1. Press in both touch controls simultaneously
and the FM transmitter will scan for a vacant
radio station.
2. Set the radio to the frequency shown
on the display of the FM transmitter.
3. If there is any interference in the transmission,
repeat steps 1 and 2 until an interference-free
frequency is found.
Standby mode
If your iPhone/ iPod is switched off for more than a minute, the FM transmitter will
switch to standby mode to save battery power.
As soon as one of the touch controls on your iPhone/iPod or
FM transmitter is pressed, the transmitter will switch back on again.
N.B.
There might be a delay of a few seconds before the transmitter restarts.
Charging
Connect a USB cable (art. no: 38-4118
or 38-4119) to the USB port (5) and to
your iPhone/iPod charger. The USB port
enables you to charge your iPhone/iPod
whilst the FM transmitter is connected.
3
Care and maintenance
• Do not expose the product to moisture or immerse it in water or
4
any other liquid.
• Do not use chemicals or corrosive cleaning agents on the product.
• Do not expose the product to extremely high or low temperatures.
• Do not dispose of the product in fire, it will explode.
5
• Do not expose the product to impacts, sharp objects or rough handling.
• Do not try to dismantle the product.
• If the product is not to be used for a long time: store it in a dry and
dust-free environment at normal room temperature.

Troubleshooting guide

The FM trans- • Make sure that the transmitter is properly connected
mitter will not to your iPhone/iPod.
switch on. • Is your iPhone/iPod battery charged?
Interference • Select a vacant frequency.
in the form • Make sure that there are no other
of noise or electrical devices in the vicinity.
other music.
No music is • Make sure that your iPhone/iPod is in play mode.
heard from • Make sure that the transmitter is properly connected
the radio. to your iPhone/iPod.
• Make sure that the radio frequency is
the same as that of the transmitter.
• Adjust the volume of your radio.
Disposal
Follow local ordinances when disposing of this product. If you are unsure of how
to dispose of this product, please contact your local authority.

Specifications

Frequency range 88.1–107.9 MHz
Rated power 5 V DC, 1 A
Operating temp −10 to +45 °C
Size 45 × 32 × 9 mm
Weight 10.6 g

Declaration of Conformity

Hereby, Clas Ohlson AB, declares that this wireless FM-transmitter,
38-4070
AT-1900
is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC.
Article 3.1a (Safety): EN 60950-1
EMF/SAR 99/519/EC Council
Recommendation
Article 3.1b (EMC): EN 301489-1
EN 301489-9
Article 3.2 (Radio): EN 301357-1
EN 301357-2
0197
!
Insjön, Sweden, April 2011
Klas Balkow
President
This product intended usage is within the countries of Sweden, Norway, Finland, the United Kingdom and Germany
