Clas Ohlson LHF-200 Instruction Manual

Wireless FM Transmitter
Article number 38-2153 • Model LHF-200
Please read the entire instruction manual before using and save it for
future use.We apologise for any text or photo errors and any changes
of technical data. If you have any questions concerning technical
problems please contact our Customer Service Department.
Product Description
- FM Transmitter for connecting, for example, a MP3 Player
to a car stereo, etc.
- Adjustable Frequency (87,6 –107,9 Mhz)
- 3 Memory Channels
- Backlit LCD Display
- Powered by 2x LR03/AAA batteries
- Temperature Display
- Low-battery warning
Buttons and Functions
4
1
2
3
1. LCD Display
2. On/Off Button Turns the unit on and off
3. SET
Set/display the clock
4. Battery Indicator Low-battery warning
5. Temperature Indicator Displays temperature
6. 3.5 mm Stereo Plug Connection for music source
7. Channel Up/Down Changes the frequency up or down
8. M1, M2, M3
Programmable buttons for memory slots
GREAT BRITAIN For consumer contact, please visit www.clasohlson.co.uk and click on customer service.
Getting Started
1. Open the battery cover and install the 2x LR03/AAA batteries
according to the markings in the battery compartment. The clock
appears on the display.
2. Connect the 3.5 mm plug [ 6 ] to your music source, for
example, a MP3 Player.
3. Press ON/OFF once. The FM Transmitter will start and the
display will show the current transmitter frequency. (To turn off
the transmitter, press once again ON/OFF).
4. Set desired transmitter frequency with the
5. Store the frequency in one of the 3 memory channels by
pressing and holding one of the M1, M2, or M3 buttons for 3
seconds.
6. Set the same frequency as in step 4 in the receiving radio, for
example, a car stereo.
Setting the Clock
1. When the unit displays time, press and hold SET for 3 seconds
until the last minute digit is blinking.
2. Adjust the time with the buttons
5
3. Press SET once. The first minute digit blinks.
6
4. Adjust the time with the buttons
5. Repeat steps 1 through 4 to set the hours.
7
6. Wait 3 seconds to save and return to normal time display.
8
Display the Clock
When the transmitter is activated, press SET once to display the
time. The display shows the time for about 3 seconds before retur-
ning to showing frequency or memory channel again.
Disposal
Follow local ordinances when disposing of this product. If you are
unsure about how to dispose of this product contact your municipality.
ENGLISH
▼ ▲
and buttons.
▼ ▲
and .
▼ ▲
and .
Specifications
Power supply 2 x LR03/AAA batteries
Operating current 38 mA
Battery life about 10-15 hours
Frequency range transmitter 87.6 – 107.9 MHz
Operating range Max 5 m
Frequency response 20 Hz – 20 KHz
Distortion < 3% (F=75KHz, f=1KHz)
Signal-to-noise ratio > 45 dB
Declaration of Conformity
Hereby, Clas Ohlson AB, declares that this wireless FM transmitter
38-2153
LHF-200
is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC.
(Safety): EN 60065
EMF/SAR 99/519/EC Council
Recommendation
(EMC): EN 301489-1, EN 301489-9
(Radio): EN 301357-1, EN 301357-2
0678
Insjön, Sweden, November 2007
Klas Balkow
President
Clas Ohlson, 793 85 Insjön, Sweden
This product's intended usage is within the countries of United Kingdom, Sweden, Norway and Finland.
,
