Installation Instructions

Installation Instructions
The following sections contain procedures for installing the antenna on a suspended ceiling.
Mounting on Suspended Ceilings with Flush Mounted Tiles
The antenna is configured to mount to a suspended ceiling track with flush mounted tiles. Suspended
ceiling mounting clips are provided on the rear panel of the antenna. (See
Figure 7
Side view
1
After you have selected a suitable location, follow these steps to mount the antenna:
Make two small slots in the ceiling tile for the cables to pass through.
Step 1
Line up the antenna mounting clips with the ceiling track.
Step 2
Grasp the antenna with one hand and the track with the other while gently pushing the antenna until the
Step 3
clips are securely attached to the track.
Route the antenna cables into the space above the ceiling grid and connect them to the device or extender
Step 4
cables.
Replace the ceiling tiles.
Step 5
Note
Cisco Multiband Diversity Omnidirectional Ceiling-Mount Antenna (AIR-ANTM4050V-R)
10
Suspended Ceiling with Flush Mounted Tiles
Ceiling track
You may have to trim some material from one of the tiles to accommodate the antenna cables.
Top view
1
2
Suspended ceiling mounting clips
Figure 7.)
