VW-1404ZH-C
4K 1x4 Video Wall Processor
User Manual

TABLE OF CONTENTS

INTRODUCTION ................................................................................................................. 1
FEATURES ......................................................................................................................... 1
SPECIFICATIONS .............................................................................................................. 2
PACKAGE CONTENTS ...................................................................................................... 2
HARDWARE INSTALLATION ............................................................................................. 3
CONNECTION DIAGRAM ................................................................................................... 3
PANEL DESCRIPTIONS ..................................................................................................... 4
SUPPORTED RESOLUTION .............................................................................................. 5
OPERATION APPROACH .................................................................................................. 6
EDID LEARNING .............................................................................................................. 24
WARRANTY ...................................................................................................................... 25
rev: 210119
Made in Taiwan
