Springdale Lighting FTR10003 Assembly Instructions

ASSEMBLY INSTRUCTIONS:
Item No: FTR10003
1. Carefully unpack and lay out the parts as shown in the illustration.
2. Pull cord through base to tighten column connections.
3. Screw lower column into lamp base.
4. Screw center column into lower column.
5. Screw upper column into center column.
6. Pull balance of cord from base to tighten excess.
7. Unscrew the shade nut from the socket, and place the shade
into the lamp holder. Replace the shade nut onto
threaded socket to secure the shade.
8. Insert 100Watt light bulb into bulb socket.
To connect the Reading Light
9. Remove the shade nut from the socket.
10. Place the shade over the socket assembly and
replace the shade nut to tighten the shade.
11. Insert 40 Watt light bulb into the socket.
Uses (1) 100Watt Maximum Type "A" and
(1) 40Watt Maximum Type "B" Bulbs
(Bulbs not included)

Cleaning of your lamp.

Unplug lamp, wipe with a damp cloth. Do not use abrasives.
*SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Made in China
FOR RETURN SHIPPING PURPOSES:
PLEASE RETAIN ORIGINAL PACKAGING
TO MINIMIZE DAMAGE.
Revision – 03/21/11
Base
Cord
