Ingersoll-Rand ARO PM0450L2 Series Operator's Manual

OPERATOR'S MANUAL
INCLUDING: OPERATION, INSTALLATION AND MAINTENANCE.
INCLUDE MANUALS: AF0450LXXXXXX-XX-X Basic Grease Pump (pn 97999-1502), 651900 Follower Assembly (pn
97999-1748) & S-636 General Information (pn 97999-636).
4 " AIR MOTOR
1/4
50:1 RATIO
4" STROKE
READ THIS MANUAL CAREFULLY BEFORE INSTALING,
It is the responsibility of the employer to place this information in the hands of the operator. Keep for future reference.
Service KITS
Use only genuine ARO® replacement parts to assure com-

patible pressure rating and longest service life.
637489 for repair of AF04XX-XX air motor.

637485 for repair of lower pump section packing.

MODEL DESCRIPTION CHART
Package
PM - Pail Mounted
Air Motor Size
04 - 4 "
1/4
Pump Ratio
50 - 50:1
Check Type / Wetted Materials
L - Primer Piston (inlet), Ball (outlet) /
Carbon Steel
Mount Style
2 - 5 gallon (35 lbs)
Lower Pump End Options
Refer to pump model operator's manual
Follower Assembly
C1 - 651900
Package Option
0 - None
INGERSOLL RAND COMPANY LTD
209 NORTH MAIN STREET -BRYAN, OHIO 43506

(800) 495-0276  FAX (800) 892-6276
arozone.com
PAIL MOUNTED PACKAGE
OPERATING OR SERVICING THIS EQUIPMENT.
PM 04 50 L 2 X X X X X
© 2015 CCN 47534343001
PM0450L2XXXXXXXX
5 GALLON
PM0450L2XXXXXXXX PAIL MOUNTED PACKAGE
X X X
GENERAL DESCRIPTION
By delivering a smooth, continuous bead of the proper size,
an ARO system helps the operator maintain both production
rate and produce high quality standards. Maintained quality
standards assures that the material benefits are realized. To
further maximize operator production time, the ARO system
has a built-in pail mounted feature for quick and easy drum
changeover and easy lifting of the pump assembly from the
container.
ARO systems are totally enclosed, sealing the material in
the system from air and moisture, preventing premature
cure-out of the material. This allows for either continuous or
intermittent use of the system and allows the need for daily
system clean-up.
RELEASED:
(REV: B)
Figure 1
10-6-15
