- Page 1 Assembly Instructions Headline Plush Electric Heater Overhang KLEH104-0100-C IMPORTANT PLEASE KEEP THIS BOOKLET FOR FUTURE REFERENCE. THIS IS IMPORTANT INFORMATION REGARDING THE USE AND CARE OF YOUR OUTDOOR HEATER. ASSEMBLY PERSONS TIME REQUIRED Feb 2022...
- Page 2 Important Information Unpack the outdoor heater making sure that all of the items are present and that there are no components left in the box and the heater head is free from any packaging material. Extra packaging is added to some models for transportation protection which must be removed before assembly.
-
Page 3: For Your Safety
For Your Safety Warning Caution • This heater is not equipped with a device • Some parts of this product can become DO NOT to control the room temperature. very hot and cause burns. Particular use this heater in small rooms when they attention must be given where children, are occupied by persons not capable of vulnerable people and animals are... - Page 4 For Your Safety 11. The marking concerning covering should DO NOT attempt to repair or adjust any be visible after the heater has been electrical or mechanical functions on this installed. It shall not be placed on the unit. Doing so will void your warranty. back of portable heaters.
- Page 5 For Your Safety DO NOT 38. One dark point may exist on the surface insert or allow foreign objects to enter any ventilation or exhaust of the heating elements during the opening as this may cause an electric first few minutes after it is turned on. shock or fire, or damage the heater.
- Page 6 Assembly • Step 1: Fill the base with fine sand then cover it with the four lids. • Step 2: Place the bottom tube through base, Then connect them together using the large screw nut.
- Page 7 Assembly • Step 3: Place the power • Step 4: Place the power cord plug through base, cord plug through bottom tube. the middle tube,Then Connect them together by screwing.
- Page 8 Assembly • Step 5: Place the power cord plug through the bent tube,Then Connect them together by screwing. Finished...
- Page 9 Assembly • Step 6: Place the heater on the bent tube,Then connect the power cord plug to the socket in the heater head.
- Page 10 Assembly • Step 7: Place the socket into the bent tube and cover it with a lid. Finished...
-
Page 11: Installation
Installation The heater is built with the best quality components in accordance to the prevailing legal regulations and certified for safety in use. For best results, please ensure that the installation is done by a qualified electrician in accordance with the following instructions and taking full account of current regulations. -
Page 12: Remote Control Operation
Operating Instructions WARNING: The heater must be properly installed before it is used. This unit is equipped with two heat settings. Connect the power cable to a 13 amp supply that is located in a safe, dry area. A. Plug the Patio Heater into a grounded 230V, 50-60 Hz power outlet B. -
Page 13: Troubleshooting
Headline Trouble Shooting Technical specification • Ratings: 220-240V 50Hz If the heater will not operate, please check the following before seeking repair or service: • Power consumption: 800/1800W • Check if the power cord is plugged into an • Height: 230CM electrical outlet, if not plug in. - Page 14 Maintenance and Care Instructions Headline • Unplug the unit and let it cool completely. • To keep the heater clean, the outer shell may be cleaned with a soft, damp cloth. You may use a mild detergent if necessary. After cleaning, dry the unit with a soft cloth. •...
