ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
show the degree of effort needed in assem-
bling a specific product (with 1 being easy and
5 being difficult). For most products, two per-
sons are recommended.
EASY
YNJ-321-5
TOOLS REQUIRED FOR ASSEMBLY
Allen Wrench
Phillips Screwdriver
Hammer
DIFFICULT
Page 1
2 PERSONS RECOMMENDED
(Included)
(Not Included)
(Not Included)
15-01-07
Advertisement
Related Manuals for Furniture of America YNJ-321-5
Summary of Contents for Furniture of America YNJ-321-5
- Page 1 ASSEMBLY INSTRUCTIONS YNJ-321-5 ASSEMBLY RATING TOOLS REQUIRED FOR ASSEMBLY Allen Wrench The Assembly Rating is a 5-point system that (Included) Phillips Screwdriver show the degree of effort needed in assem- bling a specific product (with 1 being easy and Hammer (Not Included) 5 being difficult).
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 5...
- Page 6 SHOE CABINET ASSEMBLY INSTRUCTIONS MODEL # YNJ-321-5 Please keep for future reference PARTS LIST 2PCS 2PCS 2PCS 4PCS DIMENSIONS 31.5”(W) X 15.75”(D) X 41.97”(H) Before you begin, please read “Assembly and Care Advice”, “Pre- Assembly Introduction” and “Cam Lock Fastener Assembly Instructions”.
- Page 7 ASSEMBLY INSTRUCTIONS Assembling Drawer’s Runners (a.k.a. Rails, Glides, Slides or Guides) An assembly of ONE drawer requires two sets of runners. The runner is composed of an inner rail and outer slide. Please read completely first before assembling. Mounting the Inner Rail (Fixed) of the Runner: Before mounting, please determine which side of the panel is the front and rear.
- Page 8 ASSEMBLY INSTRUCTIONS STEP2 Hardware #1 = 4pcs Hardware #2 = 4pcs Hardware #3 = 14pcs Hardware #11 = 4pcs Hardware #13 = 4pcs Page 8...
- Page 9 ASSEMBLY INSTRUCTIONS STEP3 Hardware #1 = 12pcs Hardware #3 = 8pcs Hardware #10 = 1 set STEP4 Hardware #2 = 8pcs Hardware #13 = 8pcs Page 9...
- Page 10 ASSEMBLY INSTRUCTIONS STEP5 Hardware #5 = 16pcs Hardware #13 = 4pcs STEP6 Hardware #1 = 2pcs Hardware #2 = 2pcs Hardware #8 = 4pcs Hardware #9 = 1set Hardware #13 = 2pcs Page 10...
- Page 11 ASSEMBLY INSTRUCTIONS STEP7 Hardware #4 = 2sets Hardware #15 = 2sets push spring down to insert doors STEP8 Hardware #7 = 2pcs Hardware #14 = 6sets Extend the two outer slides of the runners so that they are align with the sides of the drawer. Make sure the pre-drilled holes from the drawer align with the screw holes of the outer slides.
