ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
product (with 1 being easy and 5 being
difficult). For most products, two
persons are recommended.
EASY
YNJ-1460
DIFFICULT
Page 1
E-commerce-Enitial Lab
Tools Required for Assembly
Phillips Screwdriver
Allen Wrench
2 PERSON RECOMMENDED
(Not Included)
( Included)
17.01.18
Advertisement
Related Manuals for Furniture of America YNJ-1460
Summary of Contents for Furniture of America YNJ-1460
- Page 1 E-commerce-Enitial Lab ASSEMBLY INSTRUCTIONS YNJ-1460 Tools Required for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point system that shows the degree of effort Phillips Screwdriver needed in assembling a specific (Not Included) product (with 1 being easy and 5 being difficult).
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 5...
- Page 6 WINE RACK ASSEMBLY INSTRUCTIONS MODEL # YNJ-1460 Please keep for future reference PARTS LIST Before you begin, please read "Assembly and Care Advice","Pre- Assembly Introduction" and "Cam Lock Fastener Assembly Instructions" DIMENSIONS 47.24" (W) X15.75" (D) X35.04" (H) 2PCS 2PCS...
- Page 7 ASSEMBLY INSTRUCTIONS STEP1 Hardware #1=8pcs Hardware #9=2pcs Hardware #11=4pcs Hardware #17=12pcs 2) Align part (#S) to the holes of part (#R), then secure by using screws (#17). 1) Align part (#R) to the holes of panel Secure cam bolts (#1) to the holes of (#A), then secure by using screws (#17).
- Page 8 ASSEMBLY INSTRUCTIONS STEP3 Hardware #1=10pcs Attach cam bolts (#1) Hardware #3=12pcs Hardware #5=2sets to panel (#D). Hardware #7=3pcs Hardware #8=6pcs Hardware #10=2pcs Hardware #16=2pcs Attach door pins (#5) and handle (#7) with bolts (#8) to panel (#G,H). Align metal plate (#10), then secure by using screws (#16).
- Page 9 ASSEMBLY INSTRUCTIONS STEP4 Hardware #4=16pcs front 1) Align panels (#U,N) to the holes of panel (#I), then 2) Align panel (#I) to the holes of panel secure by using screws (#4). (#E,F), then secure by using screws (#4). STEP5 Hardware #4=8pcs Align panel (#D) to the holes of panels (#B,C,E,F), then secure by using screws (#4).
- Page 10 ASSEMBLY INSTRUCTIONS STEP6 Please refer to page 5 on Hardware #2=8pcs how to fasten cam locks(#2) to cam bolts (#1). front Align panels (#P) to panels (#Q), then secure by using cam locks (#2). STEP7 Hardware #2=8pcs Hardware #12=8pcs Hardware #13=8pcs Align panels (#P) to the cam bolts of panel (#D), then secure by using cam locks (#2).
- Page 11 ASSEMBLY INSTRUCTIONS STEP8 Hardware #2=2pcs Hardware #15=2pcs Hardware #17=4pcs Rest the shelves (#O) to the shelf pins of the cabinet. Align panels (#K,L) to panel (#M), then secure by using screws (#17). Slide bottom panel (#X) through the thin lined gaps of panels (#K,L,M). Align front panel (#J) to panels (#K,L,X), then secure by using cam locks (#2).
- Page 12 ASSEMBLY INSTRUCTIONS STEP9 Hardware #18=1pc Hardware #19=1pc Hardware #20=1pc Wall For safety,please use the strap to secure the uniton the wall Make sure the product is rested on a flat surface and does not feel loose or wobbly. If it does, double check that the bolts/screws are secured and properly tightened.
- Page 13 Page 13...
