- Page 1 TOOLS REQUIRED Phillips Screwdriver (Not Included) Hammer (Not Included) 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product. 1 / 16...
- Page 2 3 / 16...
-
Page 3: Care Advice
ASSEMBLY CARE ADVICE FAILURE TO FOLLOW THE GUIDELINES BELOW MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. Position each part correctly Turn clockwise to tighten and and insert screws or bolts into only tighten when step is their respective holes. completed or when instructed to do so. - Page 4 5 / 16...
-
Page 5: Coffee Table
COFFEE TABLE YNJ-1996C25 PARTS 2PCS 2PCS 4PCS 4PCS 4PCS 8PCS 2PCS HARDWARE ACCESSORIES 10PCS 10PCS 11PCS 8PCS 4PCS 6PCS 10PCS 1.25" 11PCS 4PCS 26PCS 0.53" 1.97" 0.59" 6 / 16... -
Page 6: Get Ready
GET READY Please group boards as below. 4PCS 2PCS 2PCS 4PCS 4PCS 8PCS 2PCS Body 7 / 16... - Page 7 Hardware x10PCS Hardware x11PCS Accessory x1PC OPTIONAL Apply a dab of glue into dowel holes of panels before inserting dowels (#3). 8 / 16...
- Page 8 Part x1PC Part x1PC Part x1PC Hardware x4PCS Accessory x1PC RECOMMEND Recommend using a power tool to only tighten hardware (#5) faster. Accessory (#A3) could also work for hardware (#5) if a power tool is not present. Front Part x4PCS Hardware x8PCS short...
- Page 9 Part x1PC Part x2PCS Hardware x4PCS Accessory x4PCS Front Please refer to page 5 for detailed instructions on how to fasten cam locks (#2) to cam bolts (#1). Use the provided stickers (#A4) to cover exposed locks. Hardware x6PCS Accessory x6PCS Front 10 / 16...
- Page 10 Front Part x1PC Hardware x7PCS Accessory x1PC RECOMMEND Recommend using a power tool to only tighten hardware (#5) faster. Accessory (#A3) could also work for hardware (#5) if a power tool is not present. 11 / 16...
- Page 11 Part x2PCS Front Part x4PCS Part x8PCS Front 12 / 16...
- Page 12 Part x4PCS Front Accessory x4PCS Attach the cap (#A1) to the bolt (#K), then secure bolt onto side framing. Part x1PC Part x1PC Part x2PCS Align and hook the springs to the hinges. 13 / 16...
- Page 13 Part x1PC Hardware x4PCS Accessory x1PC Front Front Hardware x16PCS Align hinges to the unit, then secure by using screws (#7). 14 / 16...
- Page 14 Part x1PC Front Hardware x10PCS Accessory x6PCS short long Long and short is determined by the distance of the farthest holes to the end of the panel (#A). Align hinges to the holes of the top panel (#A), then secure by using screws (#7). 15 / 16...
- Page 15 ASSEMBLY COMPLETED Please ensure the furniture rests on an even and flat surface. If the produst wobbles or feels loose,double-check all bolts and/or screws are properly tightened and secured. Keep this handy! Please retain this instruction manual and any order-related information for future reference.
