VERSION # 21-08-27
1 / 17
MODEL #
YNJ-2072C34
YNJ-2072C35
Questions?
GIVE US A CALL: 1-888-980-5122
MON－FRI 8:30AM－5:30PM (PST)
TOOLS REQUIRED
Phillips
Screwdriver
(Not Included)
Hammer
(Not Included)
2 - People
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America YNJ-2072C34
Summary of Contents for Furniture of America YNJ-2072C34
- Page 1 MODEL # YNJ-2072C34 YNJ-2072C35 Questions? GIVE US A CALL: 1-888-980-5122 MON－FRI 8:30AM－5:30PM (PST) TOOLS REQUIRED Phillips Screwdriver (Not Included) Hammer (Not Included) 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 are all accounted for. 2 / 17...
- Page 3 3 / 17...
-
Page 4: Care Advice
ASSEMBLY CARE ADVICE FAILURE TO FOLLOW THE GUIDELINES BELOW MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. Position each part correctly Turn clockwise to tighten and and insert screws or bolts into only tighten when step is their respective holes. completed or when instructed to do so. - Page 5 5 / 17...
- Page 6 BUFFET YNJ-2072C34&C35 PARTS 3PCS 2PCS 3PCS 2PCS 2PCS 2PCS 2PCS 2PCS HARDWARE ACCESSORIES 17PCS 17PCS 10PCS 20PCS 4PCS 4PCS 1.25" 1SET 6PCS 8PCS 4PCS 4PCS 1" 0.63" 0.75" 1.97" 6 / 17...
-
Page 7: Get Ready
GET READY Please group boards as below. 2PCS 2PCS 2PCS Body 2PCS 3PCS 3PCS 2PCS 2PCS Door /Shelf 7 / 17... - Page 8 Hardware x11PCS Hardware x3PCS Accessory x1PC OPTIONAL Apply a dab of glue into dowel holes of panels before inserting dowels (#3). 8 / 17...
- Page 9 Hardware x6PCS Hardware x7PCS Accessory x1PC OPTIONAL Apply a dab of glue into dowel holes of panels before inserting dowels (#3). 9 / 17...
- Page 10 Part x1PC Part x1PC Part x1PC Hardware x4PCS Front Narrow thin lined gap. Please refer to page 5 for detailed instructions on how to fasten cam locks Part x1PC (#2) to cam bolts (#1). Hardware x1PC Front 10 / 17...
- Page 11 Part x1PC Part x2PCS Hardware x6PCS Front Accessory x1PC RECOMMEND Recommend using a power tool to only tighten hardware (#5) faster. Accessory (#A2) could also work for hardware (#5) if a power tool is not present. Part x2PCS Part x2PCS Hardware x4PCS Front...
- Page 12 Front Hardware x4PCS Accessory x4PCS Part x1PC Front Part x1PC Hardware x4PCS Accessory x4PCS Use the provided stickers (#A3) to cover exposed locks. 12 / 17...
- Page 13 Part x2PCS Front Hardware x8PCS Insert shelf pins (#6) to the holes of the desired shelf height. Part x1PC Front Insert panel (#H) to the buffet. 13 / 17...
- Page 14 Part x3PCS Part x3PCS Part x2PCS Front Part x2PCS Hardware x20PCS 1) Align and attach panels (#J) to panels (#I). 2)Secure panel (#I) to panel (#J) by using screws (#4). 3)Align panel (#L) to panel (#I), then align panel (#K) to panels (#L,J). Secure panel (#K) by using screws (#4).
- Page 15 Front Hardware x4PCS Front Hardware x4PCS Insert fixative plates (#7) through the thin lined gaps between back and side panels, then secure by using screws (#8). [ No pre-drilled holes ] 15 / 17...
- Page 16 Accessory x1PC Accessory x1PC Accessory x1SET Front For safety, please secure unit onto wall by using wall mounted straps provided. Refer to page 7 on wall mounting guide. ASSEMBLY COMPLETED Please ensure the furniture rests on an even and flat surface. If the produst wobbles or feels loose,double-check all bolts and/or screws are...
- Page 17 17 / 17...
