Eaton 570 Installation, Operation & Maintenance Manual

Read all the following information and instructions prior to installing and operating the equipment.
Failure to comply with these instructions could result in bodily injury or property damage.
IOM 570 06/2011
Eaton Hydraulics LLC, Filtration Division, 44 Apple Street, Tinton Falls, NJ 07724, www.eaton.com/filtration, Phone 732-212-4700
Installation, Operation & Maintenance Manual
Introduction ...................................................................... 1
Receiving, Handling, and Inspection ................................. 2
Installation ......................................................................... 2
Operation .......................................................................... 3
Start Up ............................................................................. 3
Basket Removal and Replacement .................................... 4
Basket Cleaning ................................................................. 5
Maintenance ..................................................................... 5
Exploded Parts Illustration ................................................ 6
Recommended Spare Parts ............................................... 7
A duplex strainer is a device installed in a pipeline to
remove dirt and other unwanted debris from fluids.
Straining is accomplished by directing the fluid through
sized openings in a basket. Duplex strainers are installed
where fluid flow cannot be interrupted while the basket
is removed for cleaning. Duplex strainers are designed to
withstand the rated pressure of the piping system.
For additional information on Duplex Basket Strainers,
visit our website at filtration.eaton.com.
REV A.
Model 570 Duplex Basket Strainer

TABLE OF CONTENTS

INTRODUCTION

Page 1 of 8
