INSTALLATION MANUAL, USE AND CARE AND WARRANTY FOR
CUISINE
SEALED
TOWER BURNERS
(Model Numbers
on page 7)
Available in sizes:
24", 30", 36", 48" and 60"
DESIGN
BEFORE USING YOUR APPLIANCE, PLEASE READ THIS MANUAL, PAYING SPECIAL ATTENTION TO THE
IMPORTANT SAFETY INSTRUCTIONS LOCATED IN THE NEXT SEVERAL PAGES
This manual is divided into several sections: (Model numbers for Cuisine Burner Ranges page 13 and Performer Burner Ranges page 14)
Important Safety Instructions informs you about significant safety precautions when installing and operating your new appliance.
2
THIS IS A MUST READ SECTION OF THE MANUAL.
Installation Section describes how to unpack the unit, what to save and what to discard, installation dimensions, gas and electrical
7
connections and how to identify the primary parts of the product so you can better understand what's going on "under the hood. "
How to Operate Your Rangetop Section shows you how to light the burners, set the range for broil or bake and how to
16
use convection to speed cooking times and improve the quality of your baked and roasted dishes.
Care and Cleaning discusses how to keep your product in good operating condition, how to identify what might be going wrong
20
with the unit, and how to communicate your observations with authorized field service technicians.
20
Troubleshooting describes how to troubleshoot common issues.
21
Legend Model and Parts Identification shows available parts for your range.
22
Warranty
WARNING
!
» Failure to follow this warning statement could result
in fire, explosion, or burn hazard that could cause
property damage, personal injury or death.
DO NOT ATTEMPT TO EXTINGUISH AN OIL/GREASE FIRE WITH WATER.
1
4580 N. Walnut Rd., N. Las Vegas, NV 89081
LEGEND RANGETOP
PERFORMER
AROBSCT304
ABOUT THIS MANUAL
RETAIN THIS MANUAL FOR FUTURE REFERENCE
NEVER OPERATE THE TOP SURFACE COOKING SECTION
OF THIS APPLIANCE UNATTENDED.
|
13592 Desmond St., Pacoima, CA 91331
CLASS
» If a fire should occur, keep away from the
appliance and immediately call your fire
department.
|
tel: 818.897.0808
CUISINE
ARSCT486GD
PERFORMER
OPEN BURNERS
(Model Numbers
on page 7)
FUNCTION
|
|
888.753.9898
www.AmericanRangeHome.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for American Range CUISINE ARSCT244
Summary of Contents for American Range CUISINE ARSCT244
- Page 1 INSTALLATION MANUAL, USE AND CARE AND WARRANTY FOR LEGEND RANGETOP CUISINE SEALED TOWER BURNERS (Model Numbers on page 7) CUISINE ARSCT486GD PERFORMER Available in sizes: OPEN BURNERS 24", 30", 36", 48" and 60" (Model Numbers on page 7) PERFORMER AROBSCT304 DESIGN CLASS FUNCTION...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS FOR YOUR SAFETY! Do not store or use gasoline or other flammable vapors or YOUR YOUR liquids in the vicinity of this or any other appliance. SAFETY SAFETY WARNING! Improper installation, adjustment, alteration, service or WARNING WARNING maintenance can cause property damage, injury or death. - Page 3 » The required use of a GFI is normally related to the location of the receptacle to its proximity to significant sources of water or moisture. » American Range will not warranty any problems resulting from GFI outlets which are not installed properly or do not meet the requirements below.
-
Page 4: What To Do If You Smell Gas
IMPORTANT SAFETY INSTRUCTIONS WARNING IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING DAMAGE, PERSONAL INJURY OR DEATH INSTALLATION AND SERVICE MUST BE PERFORMED BY A CERTIFIED / LICENSED INSTALLER, SERVICE AGENCY OR THE GAS SUPPLIER »... - Page 5 » This range can tip causing personal injury » See Installation Instructions supplied with the range and install the anti-tip device packaged with the range » If the anti-tip device cannot be located, contact American Range Customer Service by calling 818.897.0808 or by contacting us at www.AmericanRange.com 4580 N.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS CAUTION Purchase a kitchen fire extinguisher for your home and store it in close proximity to your appliance. Should an uncontrolled fire occur, never use water on grease fires. Never pick up a flaming pan. The oven door interior and exterior, especially the glass can get hot during operation.
-
Page 7: Installation
INSTALLATION CUISINE BURNER CONFIGURATIONS and MODEL NUMBERS ARSCT244 ARSCT242GD ARSCT242GR ARSCT305 ARSCT366 ARSCT364GD ARSCT364GR DOUBLE GRIDDLE DOUBLE GRILL Grill Griddle 18 13 12 25 ARSCT488 ARSCT486GD ARSCT486GR ARSCT4842GD ARSCT4842GR ARSCT484GDGR Griddle Grill Double Griddle Double Grill Grill Griddle 18 13 18 13 ARSCT606GDGR ARSCT6062GD... -
Page 8: Rating Plate
BTU ratings. Keep this information for future reference. It is essential for proper identification of the unit when requesting additional information or factory support. AMERICAN AMERICAN American Range (www.americanrange.com) American Range (www.americanrange.com) 13592 DESMOND ST., PACOIMA, CA 91331 13592 DESMOND ST., PACOIMA, CA 91331... - Page 9 INSTALLATION INSTALLATION The location selected for the rangetop must meet the following PRESSURE REGULATOR criteria. If any of these criteria are not met, select another location. » The regulator installed in the rangetop is adjusted at the factory for 5" WC (natural gas) or 10" WC (L.P.) depending on the CABINET PREPARATION customer’s request.
- Page 10 INSTALLATION INSTALLATION Overall Dimensions OVERALL DEPTH RANGETOP 29" OVERALL DEPTH 29" 28" SIZE "A" "B" 28" 27" 24" 24" (610 mm) 23 7/8" (607 mm) 30" 30" (762 mm) 29 7/8" (759 mm) 11 3 4 " 27" With 20" riser 36"...
- Page 11 INSTALLATION INSTALLATION OVERALL DIMENSIONS LEGEND RANGETOP 1 3 " 3 0 " M I N 1 8 " M I N RANGETOP "A" DIMENSION WIDTH 23 7/8" (607 mm) 24" (610 mm) 29 7/8" (759 mm) 30" (762 mm) 35 7/8" (911 mm) 36"...
- Page 12 INSTALLATION INSTALLATION VENT HOOD CLEARANCE DIMENSIONS MPORTANT MPORTANT W ARNING WARNING This is a vented appliance. The 24" MIN. appliance should not be installed with a ventilation system that blows air downward towards the rangetop. This type of ventilation system may cause ignition and combustion 66"...
-
Page 13: Installation Checklist
TO VALIDATE YOUR WARRANTY, YOU MUST MAIL, EMAIL OR FAX THIS FORM WITH A COPY OF YOUR RECEIPT TO: AMERICAN RANGE CUSTOMER SERVICE, 13592 DESMOND STREET, PACOIMA, CA 91331 EMAIL: info@americanrange.com FAX: 818.897.8839 This checklist has been developed to assure proper installation of your appliance. - Page 14 LEGEND MODEL AND PARTS IDENTIFICATION CUISINE SEALED AND PERFORMER OPEN BURNERS Cuisine Sealed Burners Performer Open Burners Griddle Backyard Grill Burner Grates Center Grate Control Knobs Island Back Registration Card Page15 Use and Care Manual BEFORE USING THE NEW COOKTOP »...
- Page 15 OPERATING YOUR RANGETOP COOKWARE RECOMMENDATIONS OPERATION OF THE BURNERS 1. Press in on the knob that corresponds to the burner that you To avoid the risk of serious injury, damage to the range or would like to light. Use the front panel graphic to confirm your cookware, please observe the following guidelines.
-
Page 16: Operating Your Range
OPERATING YOUR RANGE RANGETOP-BURNER OPERATION (Sealed and Open Burners) Make sure there is nothing on the burners and/or grates prior to igniting the burners. Push the knob in, and turn it counter-clockwise to the HIGH position. Adjust the flame to the desired height. The burners are equipped with a flame-sensing ignition system that automatically detects the presence of flame on the burners, and relights in the event the flame goes out. -
Page 17: Griddle Chart
OPERATING YOUR RANGETOP GRIDDLE OPERATION (GD Models Only) TO START COOKING: The built-in griddle is made of polished steel to » Push knob in and turn the knob clockwise to the MAX position. provide a smooth cooking surface. A griddle drip Preheat griddle for two to three minutes and turn knob to a medium pan is included. -
Page 18: Troubleshooting
CARE AND CLEANING RECOMMENDATIONS PART / MATERIAL CLEANING SUGGESTIONS BEING CAREFUL Soft Scrub may be used here. With a cool or slightly warm Since the surface is glass (it can be scratched by certain Main Top/ surface, use a damp sponge or cloth as recommended by the materials) try to rub gently in small circles to allow time and Porcelain Enamel manufacturer. -
Page 19: Warranty
WARRANTY American Range (hereafter AMR) hereby provides the following warranty reasons beyond the control of AMR, failures due to improper installation, to the original residential user (“Owner”) for its new RESIDENTIAL insufficient gas or electrical supply, problems due to improper ventilation, Product(s) to be free from defects in material and workmanship in normal or removed/altered serial numbers. - Page 20 In the event the equipment requires service during the standard warranty period, the receipt proving certified installation must be made available to American Range for verification. If installation was not performed by a certified/licensed contractor, be prepared to submit a major credit card for payment for proper installation prior to service.
