PROFESSIONAL QUALITY COOKING EQUIPMENT
USE AND CARE MANUAL FOR
LEGEND SLIDE-IN COOK TOPS
MODEL NUMBERS:
ARSCT-244, ARSCT-304, ARSCT-366, ARSCT-364GD, ARSCT-364GR, ARSCT-486GD,
ARSCT-486GR, ARSCT-4842GD, ARSCT-4842GR, ARSCT-6062GD, ASRSCT-6062GR,
ARSCT-606GDGR, ARSCT-244S, ARSCT-304S, ARSCT-366S
DESIGN
CLASS
FUNCTION
RETAIN THIS MANUAL FOR FUTURE REFERENCE
R70003 012512
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARSCT-244 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for American Range ARSCT-244

  • Page 1 PROFESSIONAL QUALITY COOKING EQUIPMENT USE AND CARE MANUAL FOR LEGEND SLIDE-IN COOK TOPS MODEL NUMBERS: ARSCT-244, ARSCT-304, ARSCT-366, ARSCT-364GD, ARSCT-364GR, ARSCT-486GD, ARSCT-486GR, ARSCT-4842GD, ARSCT-4842GR, ARSCT-6062GD, ASRSCT-6062GR, ARSCT-606GDGR, ARSCT-244S, ARSCT-304S, ARSCT-366S DESIGN CLASS FUNCTION RETAIN THIS MANUAL FOR FUTURE REFERENCE R70003 012512...
  • Page 2: For Your Safety

    INSTALLATION thoroughly before installing or servicing this equipment. IMPORTANT SERVICE NOTICE! Using any part other than genuine American Range factory supplied parts relieves the manufacturer of all liability. American Range reserves the right to change specifications and product design without notice. Such revisons do not entitle the buyer to corresponding changes, improvements, additions or replacements for the previously purchased equipment.
  • Page 3 “Troubleshooting” – for a quick solution or guidance regarding the next step required to get back to tip-top condition. Thank you for choosing an American Range product for your home. As you can expect, this appliance is designed for years of reliable service. If you have any questions or comments, please contact the dealer from whom you purchased the unit, or contact American Range Customer Service at www.americanrange.com or 818.897.0808.
  • Page 4: Table Of Contents

    Use & Care Manual Slide-In Cook Tops Table of Contents GENERAL ....................1-5 General Information................... 1 About This Manual ..................... 2 Shipping Damage Information ..............3 Precautions ......................3-5 INSTALLATION ..................6-16 Cabinet Preparation ..................6 Electrical Connection ..................6 Gas Connection ....................6 Pressure Regulator .....................
  • Page 5 Use & Care Manual Slide-In Cook Tops WARNING If the information in this manual is not followed exactly, a fire or explosion may result causing damage, personal injury or death. • INSTALLATION AND SERVICE MUST BE PERFORMED BY A CERTIFIED / LICENSED INSTALLER, SERVICE AGENCY OR THE GAS SUPPLIER • Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance. • WHAT TO DO IF YOU SMELL GAS º...
  • Page 6: About This Manual

    Use & Care Manual Slide-In Cook Tops ABOUT THIS MANUAL The Use and Care Manual is divided into several sections: A. The Safety Section informs you about significant safety precautions when installing and operating your new appliance. This is a must read section of the manual. B. Quick Start and Installation Section describes how to unpack the unit, what to save and what to discard, installation dimensions, gas and electrical connections and how to identify the primary parts of the product so you can better understand what’s going on “under the hood”.
  • Page 7: Precautions

    Use & Care Manual Slide-In Cook Tops PRECAUTIONS SHIPPING DAMAGE CLAIM PROCEDURE The equipment is crafted and inspected carefully by skilled personnel before leaving the factory. The transportation company assumes full responsibility for the safe delivery upon acceptance of the equipment. If you receive a damaged product, immediately contact your delivery company, your dealer, your builder or installer.
  • Page 8: Important Safety Notice And Warning

    • This range can tip causing personal injury • See Installation Instructions supplied with the range and install the anti-tip device packaged with the range • If the anti-tip device cannot be located, contact American Range Customer Service by calling 818.897.0808 or by contacting us at www.americanrange.com 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
  • Page 9 Use & Care Manual Slide-In Cook Tops CAUTION Purchase a kitchen fire extinguisher for your home and store it in close proximity to your appliance. Should an uncontrolled fire occur, never use water on grease fires. Never pick up a flaming pan.The oven door interior and exterior, especially the oven door glass can get hot during operation.
  • Page 10: Installation Instructions

    Use & Care Manual Slide-In Cook Tops INSTALLATION INSTRUCTIONS The location selected for the range must meet the following criteria. If any of these criteria are not met, select another location. CABINET PREPARATION • This cook top is a free standing unit. • The cook top can be placed in various positions with respect to the cabinet front, with the front either flush or projecting, depending on the countertop width.
  • Page 11: Pressure Regulator

    Use & Care Manual Slide-In Cook Tops INSTALLATION INSTRUCTIONS PRESSURE REGULATOR The regulator installed in the cook top is adjusted at the factory for 5” WC (natural gas) or 10” WC (L.P.) depending on the customer’s request. Regulators must not be removed. The regulator can withstand a maximum pressure of 1/2 PSIG (14” WC). If the line pressure is beyond this limit, a step-down regulator will be required.
  • Page 12 Use & Care Manual Slide-In Cook Tops INSTALLATION INSTRUCTIONS • Do not remove protective packaging until you are ready to perform the installation. • Do not remove the protective wrapping from the product control panel until the product is installed. • Caution - the appliance is heavy.
  • Page 13: Overall Dimensions

    Use & Care Manual Slide-In Cook Tops Overall Dimensions Slide-In Cook Tops 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
  • Page 14 Use & Care Manual Slide-In Cook Tops Installations Specifications Slide-In Cook Tops 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
  • Page 15 Use & Care Manual Slide-In Cook Tops Overall Dimensions Slide-In Step Up Cook Tops 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
  • Page 16 Use & Care Manual Slide-In Cook Tops Installations Specifications Slide-In Step Up Cook Tops 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
  • Page 17 Use & Care Manual Slide-In Cook Tops OVERALL DIMENSIONS LEGEND SLIDE-IN COOK TOPS 1 3 " 3 0 " M I N 1 8 " M I N 3 / 8 " COOK TOP “A” DIMENSION WIDTH 23-7/8” 30” 29- 7/8” 36”...
  • Page 18 Use & Care Manual Slide-In Cook Tops VENT HOOD CLEARANCE DIMENSIONS 24" 27" 24" 66" min. 72" max. 30" min. 36" max. VENT HOOD REQUIREMENTS & RECOMMENDATIONS VENTILATION UNIT STANDARD COUNTER ISLAND INSTALLATION Hood Size 24” Deep x Unit Width 30”...
  • Page 19: Installation Checklist

    This checklist has been developed to assure proper installation of your oven. To validate warranty, you must mail, e-mail or fax this form and a copy of your receipt to: AMERICAN RANGE CUSTOMER SERVICE, 13592 DESMOND STREET, PACOIMA, CA 91331 service@americanrange.com 818.897.8839 FAX...
  • Page 20 Use & Care Manual Slide-In Cook Tops MODEL AND PARTS IDENTIFICATION LEGEND SERIES - SLIDE-IN COOKTOPS DESCRIPTION Total Control Knobs Sealed Burners Griddle Backyard Grill Burner Grates Center Plate Island back 4” Stub back Regis. Card U&C Manual 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
  • Page 21 Use & Care Manual Slide-In Cook Tops TYPICAL MODEL & PARTS IDENTIFICATION BURNER GRIDDLE GRILL BURNER INDICATOR LIGHT INDICATOR LIGHT INDICATOR LIGHT INDICATOR LIGHT BURNER BURNER INDICATOR LIGHT INDICATOR LIGHT BURNER GRIDDLE GRILL BURNER INDICATOR LIGHT INDICATOR LIGHT INDICATOR LIGHT INDICATOR LIGHT BURNER BURNER...
  • Page 22: Auto Re-Ignition

    Use & Care Manual Slide-In Cook Tops BEFORE USING THE NEW COOK TOP • Before using the cook top for the first time, wash the outside area with soap and water to remove any shipping & factory residue. • The burner grates are designed in sections and are easy to remove and clean. They are made of cast iron with a porcelain coating and will remain hot after the burner is turned-off creating a residual heat for continued cooking.
  • Page 23: Cookware

    Use & Care Manual Slide-In Cook Tops COOKWARE RECOMMENDATIONS To avoid the risk of serious injury, damage to the cook top or cookware, please observe the following guidelines. Bakeware, such as large casserole pans, cookie sheets, etc., should never be used on the cook top. Placement of large stock pots should be staggered when used on the cook top.
  • Page 24: Grill

    Use & Care Manual Slide-In Cook Tops GRILL OPERATION To turn on the grill, make sure there is nothing on the grilling rack, push in and turn the control counter now clockwise to the HIGH position. The power ON indicator light will glow indicating the grill valve is on. The grill is equipped with a flame-sensing ignition system – that automatically detects the presence of flame on the grill burner – and relights it in the event it should go out. Adjust the flame to the desired height. After cooking, allow the module to cool completely and remove the drip tray slowly, discarding grease and other food particles. The grill grate may be removed - exposing the radiants - which may be lifted out and placed in the dishwasher along with the drip tray for cleaning.
  • Page 25: Cleaning

    Use & Care Manual Slide-In Cook Tops USING THE GRIDDLE The built-in griddle is made of polished steel to provide a smooth cooking surface. A griddle drip pan is included. SEASON THE GRIDDLE The griddle has a factory applied coating that must be washed off before using for the first time. (See Cleaning the Griddle below). Pour one Tablespoon of vegetable oil or canola oil and rub on the entire surface of the griddle using a rough cloth.
  • Page 26 Use & Care Manual Slide-In Cook Tops TO CLEAN THE COOK TOP The cook top is constructed from brushed Stainless Steel with polished aluminum burner heads. The burner caps are steel coated porcelain. Wash all surfaces with hot water and dish detergent such as Ivory liquid or Joy. Rub stubborn spots with baking soda or liquid cleaner such as Windex All Surface Cleaner or 409.
  • Page 27: Troubleshooting

    Use & Care Manual Slide-In Cook Tops TROUBLESHOOTING GUIDE SLIDE-IN COOK TOPS PROBLEM POSSIBLE CAUSE WHAT TO DO • No electrical power to the cook top • Check circuit breakers in house Cook top will not • Gas service is turned off • Try to light a surface burner heat • Gas supply has been interrupted • Contact the gas company...
  • Page 28 Failure to comply will void any written or implied warranty. Should the equipment require service during the standard warranty period, the receipt proving certified installation must be made available to American Range for verification. If installation was not performed by a certified/licensed contractor be prepared to submit a major credit card for payment for proper installation prior to service.
