PROFESSIONAL QUALITY COOKING EQUIPMENT
INSTALLATION MANUAL FOR
LEGEND RANGETOPS
MODEL NUMBERS:
ARSCT-244, ARSCT-304, ARSCT-366, ARSCT-364GD, ARSCT-364GR, ARSCT-486GD,
ARSCT-486GR, ARSCT-4842GD, ARSCT-484X2GR, ARSCT-6062GD,
ARSCT-6062GR, ARSCT-606GDGR
DESIGN
CLASS
FUNCTION
© 2016 American Range
All Rights Reserved
13592 Desmond St., Pacoima, CA 91331 818.897.0808 888.753.9898 tel www.americanrange.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for American Range ARSCT-244
Summary of Contents for American Range ARSCT-244
- Page 1 PROFESSIONAL QUALITY COOKING EQUIPMENT INSTALLATION MANUAL FOR LEGEND RANGETOPS MODEL NUMBERS: ARSCT-244, ARSCT-304, ARSCT-366, ARSCT-364GD, ARSCT-364GR, ARSCT-486GD, ARSCT-486GR, ARSCT-4842GD, ARSCT-484X2GR, ARSCT-6062GD, ARSCT-6062GR, ARSCT-606GDGR DESIGN CLASS FUNCTION © 2016 American Range All Rights Reserved 13592 Desmond St., Pacoima, CA 91331 818.897.0808 888.753.9898 tel www.americanrange.com...
-
Page 2: Table Of Contents
Installation Manual RANGETOP Table of Contents Warnings & Important Safety Instructions ..................1-4 Dimensions................................5 Specifications & Requirements .......................6-7 Clearance Dimensions ..........................8-11 Electrical & Gas Locations ...........................12 Electrical & Gas Requirements........................13 Gas Requirements ............................14 General Instructions ............................15 Installation Instructions ..........................15 Installation Steps ............................16-19 Performance Check List ..........................20 Final Preparation ...............................20 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com... -
Page 3: Warnings & Important Safety Instructions
Installation, Operation and RANGETOP Maintenance Instructions Installation Manual FOR YOUR SAFETY! Do not store or use gasoline or other flammable vapors or liquids YOUR YOUR in the vicinity of this or any other appliance. SAFETY SAFETY WARNING! Improper installation, adjustment, alteration, service WARNING WARNING or maintenance can cause property damage, injury... - Page 4 Installation Manual RANGETOP IMPORTANT - PLEASE READ AND FOLLOW! • Before beginning, please read all the instructions carefully. • DO NOT remove permanently affixed labels, warnings, or plates from product. This may void the warranty. • All local and national codes and ordinances must be observed, installation must conform with local codes. •...
- Page 5 • The required use of a GFI is normally related to the location of a receptacle to any significant sources of water or moisture. • American Range will not warranty any problems resulting from GFI outlets which are not installed properly or do not meet the requirements below.
- Page 6 Installation Manual RANGETOP IMPORTANT - PLEASE READ AND FOLLOW! WARNING This appliance should not be used for space heating. This information is based on safety considerations. Moving Hazard WARNING To avoid risk of severe personal injury, this appliance requires two or more personnel while handling or moving.
-
Page 7: Dimensions
Installation Manual RANGETOP DIMENSIONS - RANGETOP 2 9 " 9 " 8 " Model “A” In. 24 Stand & 24 SU 23.875 30 Stand & 24 SU 29.875 30 Stand & 24 SU 35.875 48 Stand & 24 SU 47.875 60 Stand &... -
Page 8: Specifications & Requirements
Installation Manual RANGETOP SPECIFICATIONS & ELECTRICAL REQUIREMENTS RANGETOPS 24”, 30” & 36” Description 24” Wide Models 30” Wide Models 36” Wide Models Overall Width 24” 30” 36” To top of grate 9-5/16” Overall Height Step up models to the top of back island 13-1/8” Overall Depth 29-3/4”... - Page 9 Installation Manual RANGETOP SPECIFICATIONS & ELECTRICAL REQUIREMENTS RANGETOPS 48” & 60” Description 48” Wide Models 60” Wide Models Overall Width 48” 60” To top of grate 9-5/16” Overall Height Step up models to the top of back island 13-1/8” Overall Depth 29-3/4”...
-
Page 10: Clearance Dimensions
Installation Manual RANGETOP CLEARANCE DIMENSIONS • This cook top may be installed directly adjacent to existing 36” high base cabinets. • Important: The top of the side trim must be 3/8” above the adjacent base cabinet countertop. • The cook top cannot be installed directly adjacent to sidewalls, tall cabinets, tall appliances, or other vertical surfaces above 36” high. - Page 11 Installation Manual RANGETOP CLEARANCE DIMENSIONS The bottom of a standard hood should be 30" min to 36" max above the countertop. This would typically result in the bottom of the hood being 66" to 72" above the floor. Refer to the Cook Top Hood Installation Instructions for additional information. These dimensions provide for safe and efficient operation of the hood.
- Page 12 Installation Manual RANGETOP CLEARANCE DIMENSIONS Important: This cook top comes standard with island trim. There must be a minimum of 6" clearance from rear of cook top to a combustible wall or 0" clearance to an non-combustible wall. This is a vented appliance. The appliance should not be installed with a ventilation system that blows air downward towards the rangetop.
- Page 13 Installation Manual RANGETOP CLEARANCE DIMENSIONS Cook Top Width "A" Dimension "B" Dimension 24" 24" 30" 30" 30" 36" The gas and electrical supplies should be 36" 36" 42" located in cabinet below the cook top. 48" 48" 54" 60" 60" 66"...
-
Page 14: Electrical & Gas Locations
Installation Manual RANGETOP ELECTRICAL AND GAS LOCATIONS Electric and Gas supplies should be located inside the cabinet under the countertop. 12" by 3-1/2" platform cut out at right far corner shall be provided for connections. 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com... -
Page 15: Electrical & Gas Requirements
Installation Manual RANGETOP ELECTRICAL AND GAS REQUIREMENTS ELECTRICAL REQUIREMENTS There is no connection necessary beyond plugging the unit into a polarized, grounded, 120 VOLT, 60Hz, 15 Amp circuit. The minimum of 102 VAC is required for proper operation of gas ignitions. This circuit must be grounded and properly polarized. The unit is equipped with a 16-STP2 Power Cord. -
Page 16: Gas Requirements
Installation Manual RANGETOP GAS REQUIREMENTS PRESSURE REGULATOR All heavy duty commercial type cooking equipment must have a pressure regulator on the incoming service line for safe and efficient operation, since service pressure may fluctuate with local demand. External regulators are not required on this cook top since a regulator is built into each unit at the factory. -
Page 17: General Instructions
Installation Manual RANGETOP GENERAL INSTRUCTIONS • Do not remove protective packaging until you are ready to perform the installation. • Do not remove the protective wrapping from the product control panel until the product is installed. • Use proper equipment to move products. •... -
Page 18: Installation Steps
Installation Manual RANGETOP INSTALLATION STEPS STEP 1 Slide cook top into the cabinet opening. Run power cord from the cook top through the access cut out hole. 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com... - Page 19 Installation Manual RANGETOP INSTALLATION STEPS STEP 2 Connect gas and electrical. Before placing appliance in operation, always check for gas leaks. This must be performed by your dealer, a qualified licensed plumber, or gas service company. A. Gas pressure regulator B.
- Page 20 Installation Manual RANGETOP INSTALLATION STEPS STEP 3 Check that unit is level side to side and front to back. Side trim of the high corner must be 3/8" above the countertop. 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
-
Page 21: Installation Steps
Installation Manual RANGETOP INSTALLATION STEPS STEP 4 Burner caps are packed in a separate box with the grates. Place burner and caps on top of rangetop. Place burner grate on top of burner cap and grate support. 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com... -
Page 22: Performance Checklist
Installation Manual RANGETOP PERFORMANCE CHECKLIST A qualified installer should carry out the following checks: Refer to User Manual to perform the following check points. 0 Check operation of Grill (if applicable). 0 Check operation of Griddle (if applicable). 0 Check operation of Top Burners. 0 Check operation of all indicator lights on control panel. - Page 23 Notes 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
- Page 24 Failure to comply will void any written or implied warranty. Should the equipment require service during the standard warranty period, the receipt proving certified installation must be made available to American Range for verification. If installation was not performed by a certified/licensed contractor be prepared to submit a major credit card for payment for proper installation prior to service.
