Team SILK FXB630 Instruction Manual

Flange facing and grooving machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
FXB630 FLANGE FACING
AND GROOVING MACHINE
Revision E
TEAM
®
Shap Road
Kendal
Cumbria
LA9 6RU
United Kingdom
Tel: +44 (0) 1539 729009
Fax: +44 (0) 1539 729359
TEAM
is an ISO9001 registered company
®
© Copyright 2022 TEAM
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SILK FXB630 and is the answer not in the manual?

Questions and answers

Related Manuals for Team SILK FXB630

Summary of Contents for Team SILK FXB630

  • Page 1 FXB630 FLANGE FACING AND GROOVING MACHINE Revision E TEAM ® Shap Road Kendal Cumbria LA9 6RU United Kingdom Tel: +44 (0) 1539 729009 Fax: +44 (0) 1539 729359 TEAM is an ISO9001 registered company ® © Copyright 2022 TEAM ®...
  • Page 2 Flange Facing and Grooving Machine. It is an essential part of the equipment and it is important that you take the time to read it thoroughly. Additional copies are available for purchase from TEAM or from an authorised agent. ®...
  • Page 3 ® service life. Also offered is a Factory Service, in which the equipment can be returned to TEAM ® inspection. A quotation may then be given for the overhaul, repair or replacement of the equipment.

  • Page 4: Table Of Contents

    FXB630 Flange Facing and Grooving Machine CONTENTS SECTION 1 TECHNICAL DESCRIPTION ................7 1.1 Introduction ...................... 7 1.2 Equipment description ..................7 1.2.1 Base assembly ..................8 1.2.2 Drive hub assembly ................9 1.2.3 Surfacing arm assembly and toolpost ..........10 1.2.4 Gearbox ....................11 1.2.5 Motor unit ....................11 1.2.6 Optional accessories ................11...
  • Page 5 FXB630 Flange Facing and Grooving Machine 8.2 Surfacing arm assembly ................48 8.3 Gearbox assembly..................50 8.4 Base assembly ....................53 8.5 Toolpost assembly..................55 APPENDIX A Cutting tools as applied to portable machines .........56 APPENDIX B Surface metrology ..................59 APPENDIX C V-Groove measurement ................62 APPENDIX D Air motor manufacturers information ............64 APPENDIX E Declaration of Conformity ................70 APPENDIX F Hydraulic Drive–...
  • Page 6 FXB630 Flange Facing and Grooving Machine Surfacing arm assembly and toolpost Motor unit Gearbox assembly Base assembly Drive hub assembly Fig. 1 FXB630 Flange Facing and Grooving Machine – main assemblies...
  • Page 7 FXB630 Flange Facing and Grooving Machine Surfacing arm assembly and toolpost Motor unit Gearbox assembly Drive hub assembly Base assembly Setting strap (3 off) Adjustable jaws (3 off) Fig. 2 FXB630 Flange Facing and Grooving Machine – exploded view...

  • Page 8: Technical Description

    FXB630 Flange Facing and Grooving Machine SECTION 1 TECHNICAL DESCRIPTION INTRODUCTION The TEAM FXB630 Flange Facing and Grooving Machine is constructed from the highest ® quality materials and great care has been taken in its design and manufacture. Its design will give every satisfaction provided that it is properly installed, operated and maintained in accordance with the information contained within this manual.

  • Page 9: Base Assembly

    FXB630 Flange Facing and Grooving Machine 1.2.1 Base assembly Base assembly Setting strap (3 off) Adjustable jaws (3 off) Fig. 3 Base assembly The base assembly consists of three separate base assemblies which are provided to enable the machine to be installed in the centre of any bore from 153mm (6") to 711mm (28”") in diameter.

  • Page 10: Drive Hub Assembly

    FXB630 Flange Facing and Grooving Machine Fig. 4 Base assemblies (3 sizes supplied) 1.2.2 Drive hub assembly Lifting eye Air motor Power cap Position of Slideway lifting eye for clamp vertical operation (on side of Gearbox body) assembly Fig. 5 Drive hub assembly The Drive Hub Assembly is driven by a 1.7Kw (2.2hp) pneumatic motor unit, which is mounted directly to the power cap.

  • Page 11: Surfacing Arm Assembly And Toolpost

    FXB630 Flange Facing and Grooving Machine 1.2.3 Surfacing arm assembly and toolpost Right angled Looking on the end of the handle: toolpost Anti-clockwise moves the toolpost down towards the workpiece Clockwise lifts the toolpost away from the workpiece Tool holder Pickup gear Leadscrew Fig.

  • Page 12: Gearbox

    FXB630 Flange Facing and Grooving Machine 1.2.4 Gearbox Output gear Traverse direction selector Cutting speed selector Fig. 7 Gearbox assembly The Gearbox assembly is mounted on the drive hub assembly and provides a variety of cutting feeds for different machine applications. Drive input to the gearbox is derived from the drive hub take off gear.

  • Page 13: Specifications

    FXB630 Flange Facing and Grooving Machine SECTION 2 SPECIFICATIONS Maximum Machine height rotational above flange face diameter 352 mm (13.85”) 813 mm (over eye bolt) (32.0”) Overall machine height 435 mm (17.125”) Fig. 8 Principle dimensions PRINCIPAL DIMENSIONS: Overall machine height 435 mm 17.13"...
  • Page 14 FXB630 Flange Facing and Grooving Machine TRANSPORTATION DIMENSIONS: Net weight (Machine Only) 62 kg 136.7 lbs Gross weight 143 kg 315 lbs Length 950 mm 37.4" Height 545 mm 21.5" Width 530 mm 20.9" OPERATIONAL DIMENSIONS: Facing range: Minimum diameter 153 mm 6.0”...
  • Page 15 FXB630 Flange Facing and Grooving Machine NOISE EMISSION: Emission sound pressure level 94 dB(A) Instantaneous sound pressure value. Indicate either <130 dB less than 63 Pa (130 dB) or actual value if above. Emission sound power level. Indicate either less than 80 107 dB(A) dB (A) or actual value if above.

  • Page 16: Safety Information

    FXB630 Flange Facing and Grooving Machine SECTION 3 SAFETY INFORMATION WARNINGS AND CAUTIONS GENERAL: ALL SAFETY PROCEDURES MUST BE OBSERVED AND STRICTLY ADHERED TO WHEN INSTALLING, USING, MAINTAINING SERVICING THIS EQUIPMENT. ONLY TRAINED AND COMPETENT PERSONNEL SHOULD INSTALL, USE, MAINTAIN AND SERVICE THIS EQUIPMENT. ENSURE AN EMERGENCY STOP IS ALWAYS WITHIN REACH OF THE OPERATOR.
  • Page 17 TAKING PLACE OVER AN OPEN HOLE, A FLANGE BORE FOR EXAMPLE, AND THERE IS A RISK OF THE EQUIPMENT FALLING INTO THE OPENING. A SUITABLE RESTRAINT MUST BE FITTED TO THE EQUIPMENT TO HELP PREVENT INJURY OR DAMAGE. A FALL-STOP ACCESSORY KIT IS AVAILABLE FROM TEAM ®...
  • Page 18 FXB630 Flange Facing and Grooving Machine PNEUMATICS: ENSURE THE CORRECT HOSES, VALVES AND FITTINGS ARE USED. DO NOT PRESSURISE THIS EQUIPMENT IF ANY OF THE HOSES, VALVES OR FITTINGS ARE LEAKING OR DAMAGED. DO NOT PRESSURISE THIS EQUIPMENT UNTIL YOU ARE SURE THE EQUIPMENT HAS BEEN CORRECTLY INSTALLED AND THE CONTROL VALVES ARE CLOSED.

  • Page 19: Controls And Basic Operation

    FXB630 Flange Facing and Grooving Machine SECTION 4 CONTROLS AND BASIC OPERATION LOCATION AND FUNCTION OF THE CONTROLS The following controls are incorporated into the machine: 4.1.1 Machine controls FEED FEED NEUTRAL Traverse direction selector Cutting feed NEUTRAL rate selector Fig.
  • Page 20 Cutting feed rate selector Selects the rate at which the toolpost traverses across the work piece per machine revolution. The fully pushed in position ‘N’ disengages the traverse feed. The feed rate depends on which leadscrew is fitted. Standard TEAM machines ®...

  • Page 21: Filter/Lubricator Pack Controls

    FXB630 Flange Facing and Grooving Machine 4.1.2 Filter/lubricator pack controls A gate valve on the pack is used to set the machine speed at the desired RPM when the control valve is fully open. To set the speed proceed follow the instructions in section 5.3.1.

  • Page 22: Basic Operation Of The Equipment

    FXB630 Flange Facing and Grooving Machine BASIC OPERATION OF THE EQUIPMENT The basic operation of the machine follows the routine: 1. Lifting the machine from its packing case. 2. Checking the machine for completeness and condition. 3. Fit the appropriate base assembly to the work piece to be machined and centralise. 4.

  • Page 23: Site Operation

    FXB630 Flange Facing and Grooving Machine SECTION 5 SITE OPERATION WARNINGS AND CAUTIONS When operating this equipment observe all warning and cautions detailed below and in Section 3. IN ADDITION TO THE CONTENT OF THIS PUBLICATION, JOB SPECIFIC AND SITE SPECIFIC SAFETY PROCEDURES MUST BE ADHERED TO AT ALL TIMES.

  • Page 24: Setting Up The Equipment

    FXB630 Flange Facing and Grooving Machine SETTING UP THE EQUIPMENT The following instructions are for installing the flange facing and grooving machine in position prior to operating the equipment. It is assumed that an appropriate air supply is available for connection to the machine (1.8m3/min, 6 bar, 64 cfm, 87 psi).
  • Page 25 FXB630 Flange Facing and Grooving Machine 8. Extensions (3 off) 9. Setting straps and screws (3 off) 10. M10 shouldered bolts (machine securing screws 3 off) 11. Balancing kit connecting bar 12. Main balancing weight 13. Auxiliary balancing weight 14. Balancing weight fixing screws (4 off) 15.

  • Page 26: Fitting The Base Assembly

    FXB630 Flange Facing and Grooving Machine The installation procedure detailed sets up the FXB630 in a horizontal position. If the machine is to set up in the vertical or inverted position follow the set up procedure but extreme care must be taken due to the greater risk of the machine falling off the flange during the setting and adjusting procedure.

  • Page 27: Installing The Fxb630 Assembly

    FXB630 Flange Facing and Grooving Machine 5.2.3 Installing the FXB630 assembly WARNING: THE MACHINE WEIGHS 62KG. MECHANICAL LIFTING IS REQUIRED TO LIFT THE MACHINE. WHEN SETTING UP THE MACHINE ON A VERTICAL FLANGE THE LIFTING CHAIN SHOULD BE LEFT ON UNTIL THE MACHINE IS FULLY SECURED. CARE MUST BE TAKEN TO ENSURE THAT THE LIFTING CHAIN DOES NOT OBSTRUCT THE ROTATION OF THE MACHINE DURING THE INSTALLATION There are two positions for mounting the eye bolt when lifting the machine.

  • Page 28: Balancing The Machine (Vertical Use)

    FXB630 Flange Facing and Grooving Machine WHEN USING THE DTI TO SET THE MACHINE PARALLEL ALWAYS FIT THE SETTING STRAPS TO THE BASE ASSEMBLY. IF THIS IS NOT POSSIBLE CARE SHOULD BE TAKEN TO SUPPORT THE MACHINE ADEQUATELY DURING THIS PROCESS If a greater degree of accuracy is required, for example when re-machining a 'V' groove.
  • Page 29 FXB630 Flange Facing and Grooving Machine If the machine is to be used in a vertical mode the machine must be balanced. Observe the following points when balancing the machine: FAILURE TO BALANCE THE MACHINE CORRECTLY WILL RESULT IN POOR SURFACE FINISHES, DAMAGED TOOL BITS, OR WEAR ON THE POWER DRIVE.

  • Page 30: Changing The Leadscrew

    FXB630 Flange Facing and Grooving Machine 5.2.5 Changing the leadscrew Surfacing arm clamping plate Fig. 15 Position of surfacing arm clamping plate Feed drive shaft Carriage plate M4 button Leadscrew head screw Toolpost centre screw Leadscrew 4 cap head screws End plate Toolpost Star washers...
  • Page 31 FXB630 Flange Facing and Grooving Machine 1. Slacken the two hex nuts and socket head cap screws on the surfacing arm clamping plate and remove the surfacing arm by rolling it out of the dovetails. 2. Unscrew the end plate mounting studs with the star washers and remove the end plate from the surfacing arm.

  • Page 32: Setting Up The Tool - Facing And Grooving

    FXB630 Flange Facing and Grooving Machine 5.2.6 Setting up the tool - facing and grooving As the TEAM flange facing machine is portable and thus lighter and less rigid than ® its workshop counterpart, the choice of tooling and the rate at which metal can be removed will differ.

  • Page 33: Using The Equipment

    FXB630 Flange Facing and Grooving Machine USING THE EQUIPMENT The following instructions are for operating the flange facing machine correctly once installed on a flange (see Section 5.2 Setting up the Equipment). 5.3.1 Connection to Air Supply The air supply must always be connected to the machine using the Filter Lubricator Pack supplied (Fig.

  • Page 34: Starting The Machine - Facing And Grooving

    FXB630 Flange Facing and Grooving Machine 5.3.2 Starting the machine - Facing and Grooving 1. Set up the tool, refer to section 5.2.6. 2. Select the cutting feed on the cutting feed rate selector . 3. Make sure the traverse directional selector is set to neutral 'N' 4.

  • Page 35: Removing The Equipment

    FXB630 Flange Facing and Grooving Machine REMOVING THE EQUIPMENT 1. Observe all warnings and cautions, refer to Sections 3 and 5.1. 2. Isolate the machine from the air supply and disconnect. 3. Ensure that the cutting tool has been removed from the toolpost. 4.

  • Page 36: Fault Diagnosis

    FXB630 Flange Facing and Grooving Machine SECTION 6 FAULT DIAGNOSIS INTRODUCTION A fault diagnosis chart is provided to assist the user to identify basic faults. The chart is not exhaustive and the recommended action may not be the only solution to a fault. In order to prevent possible injury to personnel or damage to equipment it is recommended that faults are corrected as soon as they arise.
  • Page 37 FXB630 Flange Facing and Grooving Machine Fault diagnosis chart continued… Symptom Possible cause Action Excessive vibration and/or 1. Machine out of balance Balance machine chatter 2. Base clamp assembly Check and tighten all bolts loose 3. Depth of cut too deep Reduce cut Check motor speed (see 4.

  • Page 38: Maintenance Instructions

    FXB630 Flange Facing and Grooving Machine SECTION 7 MAINTENANCE INSTRUCTIONS INTRODUCTION The following information sets out recommendations for the maintenance of this equipment. Periodic maintenance, when carried out as specified, will help to prevent premature failure of the equipment. Should a component fail or its operation become suspect the equipment should not be used until the fault has been rectified.

  • Page 39: Recommended Lubricants

    FXB630 Flange Facing and Grooving Machine Periodic maintenance chart continued… PERIOD TASK Monthly Grease to power cap (2 points) using 5 shots Moly- based general purpose grease. Caution: do not over grease Returning to storage Complete the daily and weekly tasks. Protect all the exposed areas of the machine from corrosion.

  • Page 40: Removal And Refit Procedures

    FXB630 Flange Facing and Grooving Machine REMOVAL AND REFIT PROCEDURES TO PREVENT DAMAGE TO THE MACHINE ALWAYS USE GENUINE SPARES AVAILABLE FROM TEAM OR ONE OF ITS AGENTS. ® The following procedures are given for the removal and refitting of the main assemblies so that repair work can be carried out.

  • Page 41: Replacement Of Gearbox

    FXB630 Flange Facing and Grooving Machine It is not absolutely necessary for the removal of the surfacing arm to take the gearbox off the hub; however removal will make the task in hand much simpler to Removal of gearbox 1. Push both the selectors on the gearbox fully in i.e. the traverse direction selector to the 'OUT' position and the feed rate selector to the N position.

  • Page 42: Replacement Of Shearpins

    FXB630 Flange Facing and Grooving Machine 7.4.3 Replacement of shearpins Gearbox Bearing cap Shearpins Fig. 21 Gearbox shear pins To replace either shearpin follow the procedure: 1. Remove the gearbox as described in section 7.4.1. The shear pins will be found in the wormshaft and in the output shaft.

  • Page 43: Toolpost Overrun/Gearbox Protection Device

    FXB630 Flange Facing and Grooving Machine Toolpost overrun/gearbox protection device 7.4.4 End plate Star washer Mounting stud Fig. 22 The toolpost overrun and gearbox protection device is designed to stop the toolpost leadscrew nut jamming against a fixed surfacing arm end plate and thus damaging the feed gearbox.

  • Page 44: Parts Lists

    FXB630 Flange Facing and Grooving Machine SECTION 8 PARTS LISTS Title Page FXB630 mast and power cap assembly Surfacing arm assembly Gearbox assembly Base assembly Toolpost assembly Surfacing arm assembly Gearbox assembly Base assembly Toolpost Mast and assembly power cap assembly Fig.
  • Page 45 FXB630 Flange Facing and Grooving Machine Fig. 24 FXB630 mast and power cap assembly...

  • Page 46: Fxb630 Mast And Power Cap Assembly

    FXB630 Flange Facing and Grooving Machine FXB630 MAST AND POWER CAP ASSEMBLY Refer to Fig. 24. ITEM PART No. DESCRIPTION FXB 0106 DRIVE HUB FXB 0101 CENTRE MAST FP 0120 LOCATION SPIGOT HANDWHEEL FX 0151 HANDWHEEL SHAFT DOWEL PIN ø3/16" x 1" HEX SOC HEAD CAP SCREW M12 x 12 HEX SOC HEAD CAP SCREW M12 x 40 LOW...
  • Page 47 FXB630 Flange Facing and Grooving Machine HEX SOC HEAD CSK SCREWS 5/16" x 3/4" UNF INTERNAL CIRCLIP 82mm CP 0141 MATALASTIC BUSH FXB 0115 BUSH SINGLE ROW ANGULAR CONTACT BALL BEARING SINGLE ROW ANGULAR CONTACT BALL BEARING HEX SOC HEAD CAP SCREW M8 x 35 CP 0135 WORM SHAFT HEX SOC HEAD CAP SCREW M8 x 30...
  • Page 48 FXB630 Flange Facing and Grooving Machine Fig. 25 Surfacing arm assembly...

  • Page 49: Surfacing Arm Assembly

    BRIGHT WASHER M6 UNHARDENED GROUND DOWEL PIN 0.25" x 1.5" WASHER 0.25" x 0.75" CP 0840 THIS PART WEIGHS BADGE CP 0832 EYE PROTECTION WARNING BADGE CP 0831 EAR DEFENDER WARNING PLATE CP 0819 TEAM BADGE ® DELETED CP 0416 CLOCK MOUNT...
  • Page 50 FXB630 Flange Facing and Grooving Machine Fig. 26 Gearbox assembly...

  • Page 51: Gearbox Assembly

    FXB630 Flange Facing and Grooving Machine GEARBOX ASSEMBLY Refer to Fig. 26. ITEM PART No. DESCRIPTION CP 0200 GEARBOX CASING CP 0202 WORMWHEEL CP 0204N INPUT SELECTOR SHAFT (1,2,3,4,N) CP 0206 OUTPUT SHAFT CP 0207 SELECTOR SHAFT OUTPUT SHAFT IN, OUT,N CP 0209 REVERSE GEAR 16T CP 0210...
  • Page 52 FXB630 Flange Facing and Grooving Machine KEY 3/32" x 1/8" x 1.687" LONG CP 0278 BUSH 7/8" OD x 5/8" ID x 1/2" LG WORMSHAFT BEARING HOUSING - HEX SOC HEAD CAP SCREW M5 x 10 CP 0252 SPINDLE - 16T REVERSE GEAR HEX SOC HEAD CAP SCREW M6 x 35 CP 0255 RETAINING SLEEVE...
  • Page 53 FXB630 Flange Facing and Grooving Machine Fig. 27 Base assembly...

  • Page 54: Base Assembly

    FXB630 Flange Facing and Grooving Machine BASE ASSEMBLY Refer to Fig. 27. ITEM PART No. DESCRIPTION FXB 0406 RAM BOLT FX 0401 18" BASE FX 0402 10" BASE FX 0403 6" BASE FX 0404 CENTRALISING BUSH FXB 0407 ADJUSTABLE FOOT BODY FXB 0409 ADJUSTABLE SCREW HEX SKT SET SCREWS - CONE POINT - M4 x 10...
  • Page 55 FXB630 Flange Facing and Grooving Machine Fig. 28 Toolpost assembly...

  • Page 56: Toolpost Assembly

    FXB630 Flange Facing and Grooving Machine TOOLPOST ASSEMBLY Refer to Fig. 28. ITEM PART No. DESCRIPTION FXB 0501 RIGHT ANGLED DRIVE UNIT FXB 0502 SWIVEL PLATE FXB 0503 TOOLPOST FXB 0504 TOOLPOST FEED NUT FXB 0505 LEADSCREW FXB 0506 TOOLPOST KNOB FXB 0507 DRIVE SHAFT FXB 0508...

  • Page 57: Appendix Acutting Tools As Applied To Portable Machines

    FXB630 Flange Facing and Grooving Machine APPENDIX A CUTTING TOOLS AS APPLIED TO PORTABLE MACHINES As the flange facing machine is portable and thus lighter and less rigid than its workshop counterpart, the choice of tooling and the rate at which metal can be removed will differ from that used in the workshop.
  • Page 58 FXB630 Flange Facing and Grooving Machine...
  • Page 59 FXB630 Flange Facing and Grooving Machine TOOLS FOR V GROOVE PLUNGE MACHINING...

  • Page 60: Appendix Bsurface Metrology

    FXB630 Flange Facing and Grooving Machine APPENDIX B SURFACE METROLOGY First profile graphs of roughness texture were produced over fifty years ago by a German Engineer, Gustav Schmalz. His graphs allowed differential magnification of vertical and horizontal axes so that a visual assessment of surface could be made.
  • Page 61 FXB630 Flange Facing and Grooving Machine R.M.A. (Rq) Root Mean Square roughness is defined as: Sampling Lengths (Usually 0.08mrn) The length over which the mean line is fitted, this allows calculation of some surface parameters. Assessment Length Assessment length is the total length of surface to be assessed and is the sum of several sampling lengths Surface Form Most surfaces are made up of three classes of irregularities.
  • Page 62 FXB630 Flange Facing and Grooving Machine Micro Roughness Micro roughness (primary surface) is caused by the cutting action which is a combination of cutting, tearing, and surface fatigue. Waviness Waviness (secondary texture) is caused by feed rate of tool, or chatter/vibration. Form Error Form error (tertiary texture inaccuracies of machine such as slideway of arm lift.

  • Page 63: Appendix C V-Groove Measurement

    FXB630 Flange Facing and Grooving Machine APPENDIX C V-GROOVE MEASUREMENT...
  • Page 64 FXB630 Flange Facing and Grooving Machine...

  • Page 65: Appendix Dair Motor Manufacturers Information

    FXB630 Flange Facing and Grooving Machine APPENDIX D AIR MOTOR MANUFACTURERS INFORMATION...
  • Page 66 FXB630 Flange Facing and Grooving Machine...
  • Page 67 FXB630 Flange Facing and Grooving Machine...
  • Page 68 FXB630 Flange Facing and Grooving Machine...
  • Page 69 FXB630 Flange Facing and Grooving Machine...
  • Page 70 FXB630 Flange Facing and Grooving Machine...

  • Page 71: Appendix Edeclaration Of Conformity

    FXB630 Flange Facing and Grooving Machine APPENDIX E DECLARATION OF CONFORMITY TEAM ® Furman House, Shap Road, Kendal, Cumbria, LA9 6RU. England, Tel No. +44 (0)1539 729009.

  • Page 72: Appendix Fhydraulic Drive- Fx5000

    TECHNICAL DESCRIPTION Hydraulic Motor Figure A1 - FXB 630 Flange Facing Machine Assembly TEAM ® FXB630 Flange Facing and Grooving machine has been designed for a Standard Pneumatic Drive option. This appendix is for the Hydraulic Drive conversion kit which is designed to accommodate a Hydraulic Motor instead of the Pneumatic motor.

  • Page 73: Machine Specifications

    FXB630 Flange Facing and Grooving Machine Conversion Kit Power Cap FX5000 3/8” BSPP Ports Figure A2 - FX5000 Hydraulic Conversion Kit Note the Maximum Hydraulic Oil Flow rate and Pressure must not exceed the figures stated below MACHINE SPECIFICATIONS Drive Motor: Type Danfoss OMM 32 –...

  • Page 74: Safety Information

    FXB630 Flange Facing and Grooving Machine Figure A3 - OMM32 Performance Curves SAFETY INFORMATION WARNINGS AND CAUTIONS - HYDRAULICS HYDRAULIC OIL CAN BE A SKIN IRRITANT. WASH OFF IMMEDIATELY IF OIL COMES INTO CONTACT WITH SKIN OR CLOTHING. WEAR GLOVES AND GOGGLES FOR PROTECTION AGAINST OIL SPLASHES.

  • Page 75: Packing Case Contents

    FXB630 Flange Facing and Grooving Machine PACKING CASE CONTENTS The following amendments will relate to the packing case contents – Section 5.2 when a Hydraulic Drive option is required the subsequent items will not be supplied; Hydraulic Drive: Pneumatic Drive Motor with Key and Flange Filter Lubricator Air Pipe and Control Valve Air Motor Manufacturers Information...

  • Page 76: Hose Connections For Operation

    FXB630 Flange Facing and Grooving Machine HOSE CONNECTIONS FOR OPERATION If specified at the time of order - 2 Quick release couplings will be fitted to the Hydraulic motor, these are fitted with a conical face to aid connection/disconnection of the feed/return hoses by means of pulling back the sleeve.
