INSTRUCTION MANUAL
AX14-45 FLANGE FACING MACHINE
Revision D
TEAM
®
Shap Road
Kendal
Cumbria
LA9 6RU
United Kingdom
Tel: +44 (0) 1539 729009
Fax: +44 (0) 1539 729359
TEAM
is an ISO9001:2008 registered company
®
© Copyright 2022 TEAM
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SILK AX14-45 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Team SILK AX14-45

Summary of Contents for Team SILK AX14-45

  • Page 1 INSTRUCTION MANUAL AX14-45 FLANGE FACING MACHINE Revision D TEAM ® Shap Road Kendal Cumbria LA9 6RU United Kingdom Tel: +44 (0) 1539 729009 Fax: +44 (0) 1539 729359 TEAM is an ISO9001:2008 registered company ® © Copyright 2022 TEAM ®...
  • Page 2 This Instruction Manual describes how to safely install, operate and maintain the AX14-45 Flange Facing Machine. It is an essential part of the equipment and it is important that you take the time to read it thoroughly. Additional copies are available for purchase from TEAM or from an authorised agent. ®...
  • Page 3 ® service life. Also offered is a Factory Service, in which the equipment can be returned to TEAM ® inspection. A quotation may then be given for the overhaul, repair or replacement of the equipment.

  • Page 4: Table Of Contents

    AX14-45 Flange Facing Machine CONTENTS SECTION 1 TECHNICAL DESCRIPTION ................7 1.1 Introduction ...................... 7 1.2 Equipment description ..................7 1.2.1 Drive hub assembly ................7 1.2.2 Surfacing arm assembly and toolpost ..........10 1.2.3 Mounting base assemblies ..............11 1.2.4 Optional accessories ................13 SECTION 2 SPECIFICATIONS ..................14 SECTION 3...
  • Page 5 AX14-45 Flange Facing Machine 7.4.6 Gearbox protection device in case of Toolpost overrun .....49 SECTION 8 PARTS LISTS ....................50 8.1 Main drive assembly ..................53 8.2 Surfacing arm assembly ................56 8.3 Gearbox assembly..................58 8.4 Base assembly ....................62 8.5 Toolpost assembly..................64 8.6 Base centraliser .....................66 8.7 Counter balance ....................68 APPENDIX A Cutting tools as applied to portable machines .........69 APPENDIX B Surface metrology ..................72...
  • Page 6 AX14-45 Flange Facing Machine Fig. 1 AX14-45 Flange Facing Machine – main assembly...
  • Page 7 AX14-45 Flange Facing Machine Surfacing arm assembly and toolpost Mounting base assembly Drive hub assembly Fig. 2 AX14-45 Flange Facing Machine – exploded view...

  • Page 8: Technical Description

    AX14-45 Flange Facing Machine SECTION 1 TECHNICAL DESCRIPTION INTRODUCTION The TEAM AX14-45 Flange Facing Machine is constructed from the highest quality ® materials and great care has been taken in its design and manufacture. Its design will give every satisfaction provided that it is properly installed, operated and maintained in accordance with the information contained within this manual.
  • Page 9 AX14-45 Flange Facing Machine 1. Drive hub The drive hub is the rotating part of the machine providing a rigid support for the gearbox, motor and surfacing arm assembly. The drive hub is driven by a 3kW (4.02hp) pneumatic motor which is an integral part of the assembly.
  • Page 10 AX14-45 Flange Facing Machine 2. Base plate The base plate is the non-rotating part of the drive hub. The base plate is fixed to the mounting base assembly for most normal machining operations. 3. Feed gearbox The feed gearbox is mounted on the drive hub and provides a variety of cutting feeds for different machine applications.

  • Page 11: Surfacing Arm Assembly And Toolpost

    AX14-45 Flange Facing Machine Traverse direction selector Cutting feed rate selector Fig. 5 Feed gearbox selectors 1.2.2 Surfacing arm assembly and toolpost The surfacing arm assembly is mounted on the drive hub assembly and provides a rigid support to which the toolpost is secured. The arm can be positioned at any diameter within the recommended facing range Toolpost feed in and out is provided by a lead screw which is driven by the gearbox output gear.

  • Page 12: Mounting Base Assemblies

    AX14-45 Flange Facing Machine Toolpost Leadscrew Pickup gear (PTO) Tool holder Fig. 6 Surfacing arm assembly and toolpost 1.2.3 Mounting base assemblies Two separate mounting base assemblies are provided to enable the machine to be installed in the centre of any flange from 356mm (14") to 1143mm (45") in diameter.
  • Page 13 AX14-45 Flange Facing Machine Setting strap plate Maximum extension Non-adjustable head jaw assembly Threaded Ram bolt extension Adjustable jaw block assembly Minimum extension Fig. 7a 14” mounting base assembly Setting strap plate Maximum extension Non-adjustable head jaw assembly Threaded Ram bolt extension Adjustable jaw block assembly...

  • Page 14: Optional Accessories

    AX14-45 Flange Facing Machine 1.2.4 Optional accessories The following optional accessories are available upon request: V-Groove toolpost and plunge tools V-Groove measuring kit Lens polishing kit Vernier measuring kit Ball trammel measuring kit Tube sheet machining kit Fall-stop kit...

  • Page 15: Specifications

    AX14-45 Flange Facing Machine SECTION 2 SPECIFICATIONS Maximum Minimum rotational rotational diameter diameter 1220 mm 830 mm (48.0”) (32.7”) Overall machine height above flange face 280 mm (11”) Fig. 8 Principal dimensions PRINCIPAL DIMENSIONS: Overall machine height 443 mm 17.44" 63.5 mm 2.5”...
  • Page 16 AX14-45 Flange Facing Machine TRANSPORTATION DIMENSIONS: Net weight (without transport case) 85 kg 187 lbs Gross weight (including transport case) 265 kg 584 lbs Length 1020 mm 40.2" Height 830 mm 32.7" Width 670 mm 26.4" OPERATIONAL DIMENSIONS: Facing range: Minimum rotational diameter (without cranked tooling) 381 mm 15.0”...
  • Page 17 AX14-45 Flange Facing Machine NOISE EMISSION: Emission sound pressure level 92 dB(A) Instantaneous sound pressure level < 130 dB Sound power level 101 dB(A) MOTOR INFORMATION: Type: MODEC MT30LT0095BCL2F Maximum power output at 95 rpm 3 kW 4 hp Maximum speed free running 168 rpm Minimum recommended air supply 2.9 m...

  • Page 18: Safety Information

    AX14-45 Flange Facing Machine SECTION 3 SAFETY INFORMATION WARNINGS AND CAUTIONS GENERAL: ALL SAFETY PROCEDURES MUST BE OBSERVED AND STRICTLY ADHERED TO WHEN INSTALLING, USING, MAINTAINING SERVICING THIS EQUIPMENT. ONLY TRAINED AND COMPETENT PERSONNEL SHOULD INSTALL, USE, MAINTAIN AND SERVICE THIS EQUIPMENT. ENSURE AN EMERGENCY STOP IS ALWAYS WITHIN REACH OF THE OPERATOR.
  • Page 19 AX14-45 Flange Facing Machine PERSONAL PROTECTIVE EQUIPMENT: PERSONAL PROTECTIVE EQUIPMENT RECOMMENDED WHEN WORKING WITH THIS EQUIPMENT. SUGGESTIONS INCLUDE SAFETY HAT, GAUNTLET GLOVES, SAFETY GOGGLES, SAFETY SHOES, AND FLAME RETARDANT COVERALLS. BREATHING APPARATUS MAY BE NECESSARY WHEN A TOXIC ATMOSPHERE EXISTS. OTHER PROTECTIVE EQUIPMENT MAY BE REQUIRED AS PER THE PLANT OPERATOR’S REQUIREMENTS.
  • Page 20 AX14-45 Flange Facing Machine PNEUMATICS: ENSURE THE CORRECT HOSES, VALVES AND FITTINGS ARE USED. DO NOT PRESSURISE THIS EQUIPMENT IF ANY OF THE HOSES, VALVES OR FITTINGS ARE LEAKING OR DAMAGED. DO NOT PRESSURISE THIS EQUIPMENT UNTIL YOU ARE SURE THE EQUIPMENT HAS BEEN CORRECTLY INSTALLED AND THE CONTROL VALVES ARE CLOSED.

  • Page 21: Controls And Basic Operation

    AX14-45 Flange Facing Machine SECTION 4 CONTROLS AND BASIC OPERATION LOCATION AND FUNCTION OF THE CONTROLS The following controls are incorporated into the machine: 4.1.1 Machine controls FEED FEED NEUTRAL Traverse direction selector Cutting feed NEUTRAL rate selector Fig. 9 Machine controls Traverse direction selector Selects the direction of the toolpost as it traverses across the work piece.
  • Page 22 Cutting feed rate selector Selects the rate at which the toolpost traverses across the work piece per machine revolution. The fully pushed in position ‘N’ disengages the traverse feed. The feed rate depends on which leadscrew is fitted. Standard TEAM machines ®...

  • Page 23: Filter/Lubricator Pack Controls

    AX14-45 Flange Facing Machine 4.1.2 Filter/lubricator pack controls A gate valve on the pack is used to set the machine speed at the desired RPM when the control valve is fully open. To set the speed, proceed to follow the instructions in section 5.3.1.

  • Page 24: Basic Operation Of The Equipment

    AX14-45 Flange Facing Machine BASIC OPERATION OF THE EQUIPMENT The basic operation of the machine follows the routine: 1. Lifting the machine from its packing case. 2. Checking the machine for completeness and condition. 3. Fitting the appropriate base assembly to the work piece. 4.

  • Page 25: Site Operation

    AX14-45 Flange Facing Machine SECTION 5 SITE OPERATION WARNINGS AND CAUTIONS When operating this equipment observe all warning and cautions detailed below and in Section 3. IN ADDITION TO THE CONTENT OF THIS PUBLICATION, JOB SPECIFIC AND SITE SPECIFIC SAFETY PROCEDURES MUST BE ADHERED TO AT ALL TIMES.

  • Page 26: Setting Up The Equipment

    AX14-45 Flange Facing Machine SETTING UP THE EQUIPMENT The following instructions are for installing the flange facing and grooving machine in position prior to operating the equipment. It is assumed that an appropriate air supply is available for connection to the machine (2.9m /min, 6.0 bar, 102 cfm, 87 psi).
  • Page 27 AX14-45 Flange Facing Machine PACKING CASE CONTENTS AX14-45 Flange Facing Machine Small base assembly (1 off) Large base assembly (1 off) Adjustable jaw blocks (4 off) Non-adjustable jaw blocks (4 off) Small ram extensions (8 off) & small ram bolts (4 off) Large ram extensions (8 off) Small ram bolts (8 off) Large ram bolts (8 off)

  • Page 28: Mounting Base Installation

    AX14-45 Flange Facing Machine DO NOT ATTEMPT TO LIFT THE UPPER TRAY OUT OF THE PACKING CASE MANUALLY, USE A MECHANICAL LIFTING DEVICE. IF MECHANICAL LIFTING IS NOT POSSIBLE TWO PEOPLE ARE REQUIRED TO LIFT THE TRAY. This installation procedure provides detail on setting up the AX14-45 in a horizontal position.
  • Page 29 AX14-45 Flange Facing Machine 1. Observe all Warnings and Cautions, refer to Sections 3 and 5.1. 2. Measure the bore of the flange to be machined. Select the base assembly and the 4 off adjustable jaw rambolts and 4 off fixed jaw rambolts to suit the appropriate size of flange (see table in Section 1.2.3).

  • Page 30: Centralising The Base Within The Bore

    AX14-45 Flange Facing Machine WHEN LOCATING THE BASE IN A FABRICATED PIPING SYSTEM CHECK FOR ANY OBSTRUCTIONS, WELDS AND FLANGE-TO-PIPE MISALIGNMENTS THAT COULD PREVENT THE BASE FROM LOCATING SECURELY. 5.2.3 Centralising the base within the bore 1. Locate the central mast onto the mounting base assembly. Secure with the cap screws and use the dowels for location.

  • Page 31: Levelling The Base Within The Bore

    AX14-45 Flange Facing Machine During centralising ensure that the setting straps are fitted. When centralised, the base should be tight enough within the bore to support its own weight and that of the turntable assembly. 6. When the base assembly is correctly positioned within the bore, evenly tighten the remaining 4 non-adjustable ram bolts.
  • Page 32 AX14-45 Flange Facing Machine 2. Fit the central location spigot to the bottom of the turntable base; secure using 2 Off M6 CSK socket head screws. 3. Carefully position the machine onto the base and if fitted locate the centre location spigot into the centring hole.

  • Page 33: Fitting The Surfacing Arm

    AX14-45 Flange Facing Machine If mounting the drive assembly onto a flat surface that could obstruct the motor exhaust slots the exhaust slot blanking plugs must be removed. Place the plugs in a secure location for re-fitting on completion of the job. Fig 15. 5.2.6 Fitting the surfacing arm Heel clamp...
  • Page 34 AX14-45 Flange Facing Machine 3 off 19mm AF nuts and 2 off 6mm AF socket head cap screws 4 off 10mm AF socket head cap screws and slide way heel clamps Fig. 18 Fitting the surfacing arm to the machine 6.

  • Page 35: Balancing The Machine (Vertical Use)

    AX14-45 Flange Facing Machine 5.2.7 Balancing the machine (vertical use) Counter balance weight Fig. 19 Fitting the counter balance to the machine If the machine is to be used in a vertical mode the machine must be balanced. Observe the following points when balancing the machine: FAILURE TO BALANCE THE MACHINE CORRECTLY WILL RESULT IN POOR SURFACE FINISHES, DAMAGED TOOL BITS, AND PREMATURE WEAR ON THE DRIVE SYSTEM.
  • Page 36 AX14-45 Flange Facing Machine using the three screws supplied and feed the counterbalance weight bar through the plate. 3. Add the required counter balance weights to the bar. Position the weights to counter balance the arm and toolpost. Tighten the 4 off M30 hex nuts to secure the counter balance weight to the machine.

  • Page 37: Setting Up The Tool

    BORE TO SUPPORT THE MACHINE DURING OPERATION. 5.2.8 Setting up the tool As the TEAM flange facing machine is portable and thus lighter and less rigid than ® its workshop counterpart, the choice of tooling and the rate at which metal can be removed will differ from that used in a workshop.
  • Page 38 AX14-45 Flange Facing Machine DOWN Toolpost Fig. 23 Tool post movement...

  • Page 39: Using The Equipment

    AX14-45 Flange Facing Machine USING THE EQUIPMENT The following instructions are for operating the flange facing machine correctly once installed on a flange (see Section 5.2 Setting up the Equipment). 5.3.1 Connection to Air Supply The air supply must always be connected to the machine using the Filter Lubricator Pack supplied (Fig.

  • Page 40: Starting The Machine - Facing And Grooving

    AX14-45 Flange Facing Machine The optimum speed may vary with different applications. Check the filter is venting by unscrewing the water drain. Leave a small amount of air escaping at all times, this will keep the filter clear of water. 5.3.2 Starting the machine - Facing and Grooving 1.

  • Page 41: Removing The Equipment

    AX14-45 Flange Facing Machine REMOVING THE EQUIPMENT 1. Observe all warnings and cautions, refer to Sections 3 and 5.1. 2. Isolate the machine from the air supply and disconnect. 3. Ensure that the cutting tool has been removed from the toolpost. 4.

  • Page 42: Fault Diagnosis

    AX14-45 Flange Facing Machine SECTION 6 FAULT DIAGNOSIS INTRODUCTION A fault diagnosis chart is provided to assist the user to identify basic faults. The chart is not exhaustive and the recommended action may not be the only solution to a fault. In order to prevent possible injury to personnel or damage to equipment it is recommended that faults are corrected as soon as they arise.
  • Page 43 9. Surface arm clamp Check and tighten, if screws loose required 10. Badly maintained Overhaul and replace worn machine or damaged parts 11. Worn dovetail slides Replace dovetail slides 12. Faulty main bearing Refer to TEAM ®...

  • Page 44: Maintenance Instructions

    AX14-45 Flange Facing Machine SECTION 7 MAINTENANCE INSTRUCTIONS INTRODUCTION The following information sets out recommendations for the maintenance of this equipment. Periodic maintenance, when carried out as specified, will help to prevent premature failure of the equipment. Should a component fail or its operation become suspect the equipment should not be used until the fault has been rectified.

  • Page 45: Recommended Lubricants

    AX14-45 Flange Facing Machine Periodic maintenance chart continued… PERIOD TASK Returning to storage Complete the daily and weekly tasks. Protect all the exposed areas of the machine from corrosion. Annually when in storage Un-pack the equipment and check for signs of corrosion or other deterioration.

  • Page 46: Removal And Refit Procedures

    AX14-45 Flange Facing Machine REMOVAL AND REFIT PROCEDURES TO PREVENT DAMAGE TO THE MACHINE ALWAYS USE GENUINE SPARES AVAILABLE FROM TEAM ® OR ONE OF ITS AGENTS. The following procedures are given for the removal and refitting of the main assemblies so that repair work can be carried out.

  • Page 47: Removal Of Gearbox

    AX14-45 Flange Facing Machine 7.4.3 Removal of gearbox Removing the gearbox can be made easier with the surfacing arm removed (see section 7.4.2) but it is not essential to the operation To remove: 1. Observe all Warnings and Cautions; refer to sections 3.1 and 7.4. 2.
  • Page 48 AX14-45 Flange Facing Machine 4. Align the pin in the worm shaft with the slot in the input gear collar and refit the worm shaft. Ensure the worm shaft is correctly seated and refit the bearing cap. 5. To replace the shear pin in the output shaft remove the 'Feed Direction' black anodised handle by removing the hex locking nuts.

  • Page 49: Toolpost

    AX14-45 Flange Facing Machine 7.4.5 Toolpost To remove: 1. Observe all Warnings and Cautions; refer to sections 3.1 and 7.4. 2. Support the tool post and remove the toolpost stop screw. Toolpost stop Toolpost screw carriage Fig. 26 Toolpost 3. Carefully remove the toolpost assembly from the surfacing arm and place in a safe location.

  • Page 50: Gearbox Protection Device In Case Of Toolpost Overrun

    AX14-45 Flange Facing Machine Gearbox protection device in case of Toolpost overrun 7.4.6 End plate Star washer Mounting stud Fig. 27 The toolpost overrun device is designed to stop the toolpost leadscrew nut jamming against a fixed surfacing arm end plate and thus damaging the feed gearbox.

  • Page 51: Parts Lists

    AX14-45 Flange Facing Machine SECTION 8 PARTS LISTS Title Page Drive hub assembly Surfacing arm assembly Gearbox assembly Mounting base assembly Toolpost assembly Base centraliser assembly Counter balance assembly Drive hub assembly Surfacing arm assembly and toolpost Mounting base assembly Fig.
  • Page 52 AX14-45 Flange Facing Machine Fig. 29 Main drive assembly – sheet 1...
  • Page 53 AX14-45 Flange Facing Machine Fig. 30 Main drive assembly – sheet 2...

  • Page 54: Main Drive Assembly

    AX14-45 Flange Facing Machine MAIN DRIVE ASSEMBLY Refer to Figs. 29 and 30. ITEM PART No. DESCRIPTION FP 0101 DRIVE HUB FP 0102 BASE PLATE FP 0103 80T GEAR SLEEVE FP 0104 97T PICK UP GEAR FP 0105 39T PICK UP GEAR FP 0106 19T DRIVE GEAR FP 0107...
  • Page 55 AX14-45 Flange Facing Machine NO 37 SPRING COLLAR NUT 404-204 6 x 12.7 LONG HEX SOC HEAD CAP SCR M4 x 12 LG HEX SOC HEAD CAP SCR M6 x 20 LG HEX SOC HEAD CAP SCR M8 x 25 LG HEX SOC HEAD CAP SCR M8 x 35 LG HEX SOC HEAD CAP SCR M10 x 30 LG HEX SOC HEAD CAP SCR M12 x 50 LG...
  • Page 56 AX14-45 Flange Facing Machine Fig. 31 Surfacing arm assembly...

  • Page 57: Surfacing Arm Assembly

    SKT SET SCREW M6 x 20 LG - PLAIN CUP POINT WASHER 0.75" OD x 0.25" ID HEX SOC CSK HEAD SCR M4 x 25 LG CP 6000 COMMON TOOLPOST COLLAR EYEBOLT M16 DELETED CP 0819 TEAM BADGE ® HEX NUT - M6...
  • Page 58 AX14-45 Flange Facing Machine Fig. 32 Gearbox assembly...

  • Page 59: Gearbox Assembly

    AX14-45 Flange Facing Machine GEARBOX ASSEMBLY Refer to Fig. 32. ITEM PART No. DESCRIPTION CP 0200 GEARBOX CASING CP 0202 WORMWHEEL CP 0204N INPUT SELECTOR SHAFT (1,2,3,4,N) CP 0206 OUTPUT SHAFT CP 0207 SELECTOR SHAFT OUTPUT SHAFT IN, OUT,N CP 0209 REVERSE GEAR 16T CP 0210 REVERSE GEAR 28T...
  • Page 60 AX14-45 Flange Facing Machine KEY 1/8" SQ. x 7/8" LONG KEY 3/32" x 1/8" x 1.687" LONG CP 0278 BUSH 7/8" OD x 5/8" ID x 1/2" LG WORMSHAFT BEARING HOUSING - HEX SOC HEAD CAP SCREW M5 x 10 CP 0252 SPINDLE - 16T REVERSE GEAR HEX SOC HEAD CAP SCREW M6 x 35...
  • Page 61 AX14-45 Flange Facing Machine Fig. 33 Base assembly – sheet 1...
  • Page 62 AX14-45 Flange Facing Machine Fig. 34 Base assembly – sheet 2...

  • Page 63: Base Assembly

    AX14-45 Flange Facing Machine BASE ASSEMBLY Refer to Figs. 33 and 34. ITEM PART No. DESCRIPTION FP 0401 14" BASE FP 0402 20" BASE FP 0403 THRUST WASHER RAM ADJUSTMENT FP 0411 RAMBOLT EXTENSION - SHORT FP 0414 SETTING BRACKETS FP 0416 RAMBOLT EXTENSION - LONG FP 0417...
  • Page 64 AX14-45 Flange Facing Machine Fig. 35 Toolpost assembly...

  • Page 65: Toolpost Assembly

    AX14-45 Flange Facing Machine TOOLPOST ASSEMBLY Refer to Fig. 35. ITEM PART No. DESCRIPTION FXB 0313 PACKING PLATE CP 0307 SWIVEL PLATE CP 0315 TOOLPOST STOP CP 0308 TOOLPOST FXB 0309 TOOLPOST END PLATE FXB 0302 TOOLPOST LEADSCREW FXB 0300 TOOLPOST GRADUATION FXB 0301 TOOLPOST KNOB...
  • Page 66 AX14-45 Flange Facing Machine Fig. 36 Base centraliser...

  • Page 67: Base Centraliser

    AX14-45 Flange Facing Machine BASE CENTRALISER Refer to Fig. 36. ITEM PART No. DESCRIPTION CP 0136 CLOCKING TOWER - BEARING DUST COVER FP 0604 CLOCKING ARM **** TAPER ROLLER BEARING HEX NUT - 1" UNF **** CP 0140 BEARING BLOCK FY 0436 CLOCKING MAST 1/4"...
  • Page 68 AX14-45 Flange Facing Machine Fig. 37 Counter balance...

  • Page 69: Counter Balance

    AX14-45 Flange Facing Machine COUNTER BALANCE Refer to Fig. 37. ITEM PART No. DESCRIPTION FW 0532A 25mm BALANCE WEIGHT FW 0532 B 50mm BALANCE WEIGHT FW 0532 C 100mm BALANCE WEIGHT FP 0419 COUNTER BALANCE BAR FP 0501 COUNTER BALANCE MOUNTING BLOCK HEX NUT M30 WASHER M30 HEX SOC HEAD CAP SCREW M10 x 50 LG...

  • Page 70: Appendix Acutting Tools As Applied To Portable Machines

    AX14-45 Flange Facing Machine APPENDIX A CUTTING TOOLS AS APPLIED TO PORTABLE MACHINES As the flange facing machine is portable and thus lighter and less rigid than its workshop counterpart, the choice of tooling and the rate at which metal can be removed will differ from that used in the workshop.
  • Page 71 AX14-45 Flange Facing Machine TYPES OF TOOL BIT FOR GENERAL PURPOSE AND FINE FINISH...
  • Page 72 AX14-45 Flange Facing Machine TOOLS FOR V GROOVE PLUNGE MACHINING...

  • Page 73: Appendix Bsurface Metrology

    AX14-45 Flange Facing Machine APPENDIX B SURFACE METROLOGY First profile graphs of roughness texture were produced over fifty years ago by a German Engineer, Gustav Schmalz. His graphs allowed differential magnification of vertical and horizontal axes so that a visual assessment of surface could be made. These profile graphs did not provide the direct indications of magnitude required by workshops.
  • Page 74 AX14-45 Flange Facing Machine R.M.A. (Rq) Root Mean Square roughness is defined as: Sampling Lengths (Usually 0.08mrn) The length over which the mean line is fitted, this allows calculation of some surface parameters. Assessment Length Assessment length is the total length of surface to be assessed and is the sum of several sampling lengths Surface Form Most surfaces are made up of three classes of irregularities.
  • Page 75 AX14-45 Flange Facing Machine Micro Roughness Micro roughness (primary surface) is caused by the cutting action which is a combination of cutting, tearing, and surface fatigue. Waviness Waviness (secondary texture) is caused by feed rate of tool, or chatter/vibration. Form Error Form error (tertiary texture inaccuracies of machine such as slideway of arm lift.

  • Page 76: Appendix C V-Groove Measurement

    AX14-45 Flange Facing Machine APPENDIX C V-GROOVE MEASUREMENT...
  • Page 77 AX14-45 Flange Facing Machine...

  • Page 78: Appendix Dair Motor Manufacturers Information

    AX14-45 Flange Facing Machine APPENDIX D AIR MOTOR MANUFACTURERS INFORMATION...
  • Page 79 AX14-45 Flange Facing Machine...
  • Page 80 AX14-45 Flange Facing Machine...
  • Page 81 AX14-45 Flange Facing Machine...
  • Page 82 AX14-45 Flange Facing Machine...
  • Page 83 AX14-45 Flange Facing Machine...

  • Page 84: Appendix Efall-Stop Kit

    This equipment is intended for use only as a safety device when machining flanges or similar components over unobstructed, internal openings. This equipment is intended for use on the following standard TEAM flange facing machines: ®...

  • Page 85: Specifications

    THIS EQUIPMENT IS FOR USE BY PROFESSIONAL, TRAINED PERSONNEL WORKING IN AN INDUSTRIAL ENVIRONMENT. THIS EQUIPMENT IS INTENDED FOR USE ONLY ON STANDARD VERSIONS OF THE TEAM FLANGE FACING MACHINES. ® THIS EQUIPMENT IS NOT INTENDED FOR USE ON ANY OTHER MACHINE OR FOR ANY PURPOSE OTHER THAN AS AN FALL-STOP SAFETY DEVICE.

  • Page 86: Installation Of The Equipment

    RESTRAINED DURING INSTALLATION REMOVAL PROCESS. 4. INSTALLATION OF THE EQUIPMENT INSTALLATION ONTO THE TEAM ® AX14-45 FLANGE FACING MACHINE Inspect the Fall-Stop Kit and confirm that it is complete and fit for purpose. FALL-STOP KIT Inspect the TEAM machine in the location where the fall-stop kit will be installed and ®...
  • Page 87 AX14-45 Flange Facing Machine Fig 1 Fix the fall-stop kit bracket to the TEAM machine making sure it engages fully with the ® keyway. Install the threaded rod and adjust its position so it will overhang the work piece sufficiently to prevent the machine from falling through the opening should the machine clamping system break loose.

  • Page 88: Using The Fall-Stop Kit

    AX14-45 Flange Facing Machine 5. USING THE FALL-STOP KIT Proceed to install the machine at the worksite following the information in the operator’s manual and any site-specific procedures. ONCE THE MACHINE HAS BEEN CORRECTLY SET DO NOT REMOVE THE MACHINE CLAMPING SYSTEM SETTING PLATES UNTIL THE FALL-STOP KIT HAS BEEN PROPERLY ADJUSTED.

  • Page 89: Maintenance Instructions

    AX14-45 Flange Facing Machine 7. MAINTENANCE INSTRUCTIONS 7.1 Introduction The following information sets out recommendations for the maintenance of this equipment. Periodic maintenance, when carried out as specified, will help to prevent premature failure of the equipment. Should a component fail or its operation become suspect the equipment should not be used until the fault has been rectified.

  • Page 90: Appendix Fbearing Lubrication Ru40035Uu

    AX14-45 Flange Facing Machine APPENDIX F BEARING LUBRICATION RU40035UU...

  • Page 91: Appendix Gdeclaration Of Conformity

    AX14-45 Flange Facing Machine APPENDIX G DECLARATION OF CONFORMITY TEAM ® Furman House, Shap Road, Kendal, Cumbria, LA9 6RU. England, Tel No. +44 (0)1539 729009.
