INSTRUCTION MANUAL
AX08 FLANGE FACING
AND GROOVING MACHINE
Revision A
TEAM
®
Shap Road
Kendal
Cumbria
LA9 6RU
United Kingdom
Tel: +44 (0) 1539 729009
Fax: +44 (0) 1539 729359
TEAM
is an ISO9001 registered company
®
© Copyright 2022 TEAM
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SILK AX08 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Team SILK AX08

Summary of Contents for Team SILK AX08

  • Page 1 AX08 FLANGE FACING AND GROOVING MACHINE Revision A TEAM ® Shap Road Kendal Cumbria LA9 6RU United Kingdom Tel: +44 (0) 1539 729009 Fax: +44 (0) 1539 729359 TEAM is an ISO9001 registered company ® © Copyright 2022 TEAM ®...
  • Page 2 Flange Facing and Grooving Machine. It is an essential part of the equipment and it is important that you take the time to read it thoroughly. Additional copies are available for purchase from TEAM or from an authorised agent. ®...
  • Page 3 Team Industrial Services, Inc. is in continuous product development and reserves the right to amend this manual and specifications without notice. For the latest operation and manual please contact your representative.

  • Page 4: Table Of Contents

    AX08 Flange Facing and Grooving Machine CONTENTS SECTION 1 TECHNICAL DESCRIPTION ................8 1.1 Introduction ...................... 8 1.2 Equipment description ..................8 1.2.1 Drive ring and bearing assembly............8 1.2.2 Saddle ....................9 1.2.3 Toolpost ....................11 1.2.4 Mounting Plate ..................11 1.2.5 Motor unit ....................12 SECTION 2 SPECIFICATIONS ..................13...
  • Page 5 AX08 Flange Facing and Grooving Machine 8.4 Base Clamping Assembly ................50 8.5 Machine Tool Kit ....................51 8.6 Mounting Plate Assembly ................52 8.7 Toolpost Assembly ..................54 APPENDIX A Cutting tools as applied to portable machines ........56 APPENDIX B Surface metrology ..................59 APPENDIX C V-Groove measurement ................62 APPENDIX D Air motor manufacturers information ............64 APPENDIX E DECLARATION OF CONFORMITY .............65...
  • Page 6 AX08 Flange Facing and Grooving Machine MOTOR UNIT FEED ENGAGE / DISENGAGE HANDLE SADDLE TOOLPOST DRIVE RING AND BEARING ASSEMBLY BASE CLAMP BLOCKS Figure 1 - AX08 Flange Facing and Grooving Machine RF Machining Only – Without Mount plate (Above) RTJ Machining with Mounting plate (Optional extra –...
  • Page 7 AX08 Flange Facing and Grooving Machine MOTOR UNIT TOOLPOST SADDLE DRIVE RING AND BEARING ASSEMBLY TOOL BASE CLAMP BLOCKS Figure 2 - AX08 Flange Facing and Grooving Machine - Exploded View...
  • Page 8 AX08 Flange Facing and Grooving Machine MOTOR UNIT TOOLPOST SADDLE DRIVE RING AND BEARING ASSEMBLY TOOL MOUNTING PLATE BASE CLAMP BLOCKS Figure 3 - AX08 Flange Facing and Grooving Machine - Exploded View (Shown with optional extra - Mounting plate)

  • Page 9: Technical Description

    Take care of this manual; it is an essential source of information. 1.2 EQUIPMENT DESCRIPTION The purpose of the TEAM AX08 flange facing and grooving machine is designed to ® machine full faced, raised faces up to Ø134mm using standard tooling (Supplied), though greater diameters are achievable by using cranked tooling (Not Supplied) at any location having a minimum pneumatic air supply 1.6 m...

  • Page 10: Saddle

    AX08 Flange Facing and Grooving Machine The drive assembly The drive assembly, which is the fixed part of the machine, has either three or four base clamp blocks depending on application. These base clamp blocks can either be bolted directly to the base plate on the underside of the machine when machining a raised Face flange or if machining a RTJ flange the base clamp blocks can be bolted directly to the mounting plate sub- assembly.
  • Page 11 AX08 Flange Facing and Grooving Machine MANUAL FEED CLOCKWISE – OUTWARDS FEED ENGAGE / TOOLPOST MOVEMENT ANTICLOCKWISE - INWARDS DISENGAGE HANDLE SADDLE ‘PULL’ AUTO FEED ENGAGED TOOLPOST ‘PUSH’ AUTO FEED DISENGAGED (MANUAL FEED ONLY) Figure 4 - Saddle Table 1 - Feed Rates FEED FEED (mm per revolution)

  • Page 12: Toolpost

    AX08 Flange Facing and Grooving Machine 1.2.3 Toolpost The Toolpost is mounted directly to the saddle assembly on linear rails and houses the special tools required to perform a variety of applications. TOOLPOST MOVEMENT CLOCKWISE – FEEDS TOOL ANTI-CLOCKWISE – FEEDS AWAY FROM WORKPIECE TOOL TOWARDS WORKPIECE PLATE NUT...

  • Page 13: Motor Unit

    AX08 Flange Facing and Grooving Machine 1.2.5 Motor unit The machine is driven by a 0.63 kW (0.84 hp) pneumatic motor with a free running output speed of 250 rpm and incorporating an exhaust manifold and muffler. The motor is attached to a drive ring and bearing assembly by 3 Off – M6 Socket head capscrews.

  • Page 14: Specifications

    AX08 Flange Facing and Grooving Machine SECTION 2 SPECIFICATIONS Figure 6 - AX08 Principle Dimensions PRINCIPAL DIMENSIONS: Overall machine height 310 mm 12.2" Inc. Mount Plate – Exc. Clamp assembly spacers Overall machine height 305 mm 12.0” Exc. Mount Plate and Exc. Clamp assembly spacers Maximum base diameter 462 mm 18.2”...
  • Page 15 AX08 Flange Facing and Grooving Machine OPERATIONAL DIMENSIONS: Facing range: Minimum diameter Zero Zero Maximum diameter with standard tooling 134 mm 5.27" Toolpost travel: Maximum toolpost vertical travel 30 mm 1.18" Base gripping range: Minimum recommended outside diameter 98 mm 3.85"...

  • Page 16: Safety Information

    AX08 Flange Facing and Grooving Machine SECTION 3 SAFETY INFORMATION 3.1 WARNINGS AND CAUTIONS GENERAL: ALL SAFETY PROCEDURES MUST BE OBSERVED AND STRICTLY ADHERED TO WHEN INSTALLING, USING, MAINTAINING SERVICING THIS EQUIPMENT. ONLY TRAINED AND COMPETENT PERSONNEL SHOULD INSTALL, USE, MAINTAIN AND SERVICE THIS EQUIPMENT. ENSURE AN EMERGENCY STOP IS ALWAYS WITHIN REACH OF THE OPERATOR.
  • Page 17 AX08 Flange Facing and Grooving Machine PERSONAL PROTECTIVE EQUIPMENT: PERSONAL PROTECTIVE EQUIPMENT RECOMMENDED WHEN WORKING WITH THIS EQUIPMENT. SUGGESTIONS INCLUDE SAFETY HAT, GAUNTLET GLOVES, SAFETY GOGGLES, SAFETY SHOES, AND FLAME RETARDANT COVERALLS. BREATHING APPARATUS MAY BE NECESSARY WHEN A TOXIC ATMOSPHERE EXISTS.
  • Page 18 AX08 Flange Facing and Grooving Machine PNEUMATICS: ENSURE THE CORRECT HOSES, VALVES AND FITTINGS ARE USED. DO NOT PRESSURISE THIS EQUIPMENT IF ANY OF THE HOSES, VALVES OR FITTINGS ARE LEAKING OR DAMAGED. DO NOT PRESSURISE THIS EQUIPMENT UNTIL YOU ARE SURE THE EQUIPMENT HAS BEEN CORRECTLY INSTALLED AND THE CONTROL VALVES ARE CLOSED.

  • Page 19: Controls And Basic Operation

    AX08 Flange Facing and Grooving Machine SECTION 4 CONTROLS AND BASIC OPERATION 4.1 LOCATION AND FUNCTION OF THE CONTROLS The following controls are incorporated into the machine: 4.1.1 Machine controls Figure 7 - Machine Controls Auto feed selector The auto feed selector determines whether the machine rotation is engaged or not. AUTO FEED MACHINE ROTATION SELECTOR POSTION...
  • Page 20 AX08 Flange Facing and Grooving Machine Clockwise rotation of the handle will traverse the toolpost outwards away from the centre of the machine. Anticlockwise rotation of the handle will traverse the toolpost inwards towards the centre of the machine. MANUAL FEED CLOCKWISE –...

  • Page 21: Toolpost Adjustment

    AX08 Flange Facing and Grooving Machine Figure 9 - Toolpost Travel 4.1.2 Toolpost Adjustment The toolpost can be adjusted to suit a number of pre-set angles dependant on application; Figure 10 – Toolpost Adjustment To adjust the toolpost loosen the 2 Off – Tool holder locking screws and rotate the tool holder until the spring detent pins engage with the appropriate recess in the plate nut.

  • Page 22: Filter/Lubricator Pack Controls

    AX08 Flange Facing and Grooving Machine If additional free movement of the toolpost is required, loosen the 2 Off – Tool holder locking screws to allow rotational movement of the tool holder. Retract the spring detent pins approx. 4 turns to disengage the ball detent from the plate nut recess - Figure 11, once disengaged the tool holder is free to rotate.

  • Page 23: Basic Operation Of The Equipment - Inc. Mounting Plate Assembly

    AX08 Flange Facing and Grooving Machine 4.2 BASIC OPERATION OF THE EQUIPMENT – INC. MOUNTING PLATE ASSEMBLY The basic operation of the machine follows the routine: 1. Lifting the machine from its packing case. 2. Checking the machine for completeness and condition. 3.

  • Page 24: Lifting And Slinging Arrangements

    AX08 Flange Facing and Grooving Machine 4.4 LIFTING AND SLINGING ARRANGEMENTS The AX08 machine when complete and in its packing box weighs 33 kg. DO NOT ATTEMPT TO MANUALLY MOVE THE MACHINE IN ITS PACKING BOX. ALWAYS USE A MECHANICAL LIFTING DEVICE. The AX08 assembled machine weighs 23 kg.

  • Page 25: Site Operation

    AX08 Flange Facing and Grooving Machine SECTION 5 SITE OPERATION 5.1 WARNINGS AND CAUTIONS When operating this equipment observe all warning and cautions detailed below and in Section 3. IN ADDITION TO THE CONTENT OF THIS PUBLICATION, JOB SPECIFIC AND SITE SPECIFIC SAFETY PROCEDURES MUST BE ADHERED TO AT ALL TIMES.

  • Page 26: Setting Up The Equipment

    AX08 Flange Facing and Grooving Machine 5.2 SETTING UP THE EQUIPMENT The following instructions are for installing the flange facing and grooving machine in position prior to operating the equipment. It is assumed that an appropriate air supply is available for connection to the machine (1.6m3/min, 6 bar, 60cfm, 87 psi). 5.2.1 Unpacking the machine 5 &...

  • Page 27: Drive Ring And Bearing Assembly Installation

    AX08 Flange Facing and Grooving Machine Toolkit comprising of: 1 set of Allen keys • • 16 mm AF combination spanner Turning tool and inserts; 10mm SQ. Straight tool – Left Hand • • 10mm SQ. Straight tool – Right Hand 10mm SQ.
  • Page 28 AX08 Flange Facing and Grooving Machine between the jaw assemblies and the base of the machine or mounting plate depending on application. THIS MACHINE SHOULD BE LIFTED USING SUITABLE MECHANICAL EQUIPMENT. WHEN SETTING UP THE MACHINE ON A VERTICAL FLANGE CARE SHOULD BE TAKEN TO ENSURE THE MACHINE IS FULLY SECURED.
  • Page 29 AX08 Flange Facing and Grooving Machine 11. Using the grub screws located in each of the fast mount plates, adjust accordingly. Re-clock the flange and continue until the desired accuracy has been achieved. Now clock the groove, etc., to set the drive unit central. Tighten one jaw first then loosen the opposite jaw.
  • Page 30 AX08 Flange Facing and Grooving Machine FAST MOUNT PLATES ADJUSTMENT SCREWS MOUNTING PLATE ASSEMBLY BASE CLAMP BLOCKS MAX. TORQUE 50Nm (36 ft lbs) Figure 14 - Fitting fast mount plates...

  • Page 31: Setting Up The Tool - Facing And Grooving

    AX08 Flange Facing and Grooving Machine 5.2.3 Setting up the tool - facing and grooving As the TEAM flange facing machine is portable and thus lighter and less rigid than ® its workshop counterpart, the choice of tooling and the rate at which metal can be removed will differ from that used in a workshop.

  • Page 32: Using The Equipment

    AX08 Flange Facing and Grooving Machine 5.3 USING THE EQUIPMENT The following instructions are for operating the flange facing machine once correctly installed on a flange (see Section 5.2). 5.3.1 Connection to Air Supply The air supply must always be connected to the machine using the Filter Lubricator Pack supplied (Figure 16 - Filter Lubricator Pack).

  • Page 33: Starting The Machine - Facing And Grooving

    AX08 Flange Facing and Grooving Machine 5.3.2 Starting the machine - Facing and Grooving Set up the tool, refer to Section 5.2.3. Select the Automatic feed, refer to Section 5.2.4. Position the tool over the cutting area. Set depth of cut on the toolpost feed knob.. WARNING: THE MACHINE HAS DANGEROUS MOVING PARTS WHEN OPERATED, THEREFORE KEEP WELL CLEAR.

  • Page 34: Removing The Equipment

    AX08 Flange Facing and Grooving Machine 5.4 REMOVING THE EQUIPMENT 1. Observe all warnings and cautions, refer to Sections 3 and 5.1 2. Isolate the machine from the air supply and disconnect. 3. Ensure that the cutting tool has been removed from the tool post. 4.

  • Page 35: Fault Diagnosis

    AX08 Flange Facing and Grooving Machine SECTION 6 FAULT DIAGNOSIS 6.1 INTRODUCTION A fault diagnosis chart is provided to assist the user to identify basic faults. The chart is not exhaustive and the recommended action may not be the only solution to a fault. In order to prevent possible injury to personnel or damage to equipment it is recommended that faults are corrected as soon as they arise.
  • Page 36 AX08 Flange Facing and Grooving Machine Fault diagnosis chart continued… Symptom Possible cause Action Excessive vibration and/or 1. Base clamp blocks loose Check and tighten all chatter clamp blocks 2. Depth of cut too deep Reduce cut 3. Poor tool profile or worn Check tool and replace tips tool if necessary...

  • Page 37: Maintenance Instructions

    AX08 Flange Facing and Grooving Machine SECTION 7 MAINTENANCE INSTRUCTIONS 7.1 INTRODUCTION The following information sets out recommendations for the maintenance of this equipment. Periodic maintenance, when carried out as specified, will help to prevent premature failure of the equipment. Should a component fail or its operation become suspect the equipment should not be used until the fault has been rectified.
  • Page 38 AX08 Flange Facing and Grooving Machine Periodic maintenance chart continued… PERIOD TASK Returning to storage Complete the daily, weekly and monthly tasks. Protect all the exposed areas of the machine from corrosion. Annually when in storage Un-pack the equipment and check for signs of corrosion or other deterioration.

  • Page 39: Recommended Lubricants

    AX08 Flange Facing and Grooving Machine 7.3 RECOMMENDED LUBRICANTS These are the recommended lubricants for the AX08 Flange Facing and Grooving Machine. Saddle Grease point Toolpost – Grease point Motor Gearbox Grease point Figure 17 - Lubrication points Component Lubricant type Product name or specification Air motor Light machine oil...

  • Page 40: Removal And Refit Procedures

    AX08 Flange Facing and Grooving Machine 7.4 REMOVAL AND REFIT PROCEDURES The following procedures are given for the removal and refitting of the main assemblies so that repair work can be carried out. Figure 18 - Drive motor removal (shown with mount plate assembly) WARNING: ENSURE ALL AIR SUPPLIES ARE REMOVED / ISOLATED PRIOR TO WORK COMMENCING.

  • Page 41: Parts Lists

    AX08 Flange Facing and Grooving Machine SECTION 8 PARTS LISTS Title Page Drive ring and bearing assembly 41-44 Saddle assembly 45-48 Base clamping assembly 49-50 Machine Tool Kit Rail and Slide Assembly Mounting plate assembly 53-54 Toolpost 55-56 Drive Motor Toolpost Drive ring and bearing assembly...

  • Page 42: Ax08 Main Assembly

    AX08 Flange Facing and Grooving Machine 8.1 AX08 MAIN ASSEMBLY ITEM PART No. DESCRIPTION KE6518-00-00-000 AX08 – MACHINE MAIN ASSEMBLY KE6518-00-01-000 SADDLE ASSEMBLY KE6518-00-05-000 TOOLS KIT KE6518-00-06-000 RAIL ASSEMBLY KE6518-00-07-000 MOUNT PLATE ASSEMBLY KE6518-00-08-000 TOOLPOST ASSEMBLY Drive Motor Saddle Assembly Rail Assembly Toolpost Assembly Mounting Plate...
  • Page 43 AX08 Flange Facing and Grooving Machine Figure 21 - AX08 Machine Main Assembly...
  • Page 44 GREASE NIPPLE M5 KE6518-00-07-000 MOUNT PLATE ASSY KE6518-00-08-000 TOOLPOST ASSY M5x25 HEXAG. SOCKET HEAD CAPSCREW NORD-LOCK WASHER NL8 CP 0819 TEAM® BADGE CP 0830 CE MARK NAMEPLATE – PNEUMATIC CP 0831 EAR DEFENDER BADGE CP 0832 SAFETY GLASSES BADGE CP 0833...
  • Page 45 AX08 Flange Facing and Grooving Machine Figure 22 - AX08 Machine Main Assembly...

  • Page 46: Saddle Assembly

    AX08 Flange Facing and Grooving Machine 8.2 SADDLE ASSEMBLY Figure 23 – AX08 Saddle Assembly...
  • Page 47 AX08 Flange Facing and Grooving Machine Refer to Figure 23 & Figure 24 ITEM PART No. DESCRIPTION KE6518-00-01-001 SUPPORT RING KE6518-00-01-002 RETAINING CAP KE6518-00-01-003 ROTATING HOUSING KE6518-00-01-004 GEAR PROTECTION CAP KE6518-00-01-005 FEED GEAR KE6518-00-01-006 FEED WORM KE6518-00-01-007 FEED WORM-WHEEL KE6518-00-01-008 SELECTOR SHAFT KE6518-00-01-009 SELECTOR KEY...
  • Page 48 AX08 Flange Facing and Grooving Machine Refer to Figure 23 & Figure 24 BEARING 61904 CIRCLIP INTERNAL CIRCLIP EXTERNAL CIRCLIP INTERNAL CIRCLIP EXTERNAL REASE NIPPLE KEY 4x4 x 10mm – FORM B BALL Ø4.5 SPRING SELECTOR KEY DISC SPRING WASHER BUSHING KE6518-00-01-017 INTERNAL SWARF GUARD...
  • Page 49 AX08 Flange Facing and Grooving Machine Figure 24 – AX08 Saddle Assembly – Exploded View...

  • Page 50: Base Clamping Assembly

    AX08 Flange Facing and Grooving Machine 8.3 BASE CLAMPING ASSEMBLY Figure 25 - Base clamping assembly...

  • Page 51: Base Clamping Assembly

    AX08 Flange Facing and Grooving Machine 8.4 BASE CLAMPING ASSEMBLY Refer to Figure 25 ITEM PART No. DESCRIPTION KE6518-00-04-001 BASE CLAMP BLOCK KE6518-00-04-002 BASE CLAMP SCREW KE6518-00-04-003 BASE CLAMP JAW M10 HEXAGON NUT – DIN 934 Ø3 x 16mm LG SLOTTED SPRING PIN – ISO 8752 KE6518-00-04-004 FAST MOUNTING PLATE –...

  • Page 52: Machine Tool Kit

    AX08 Flange Facing and Grooving Machine 8.5 MACHINE TOOL KIT ITEM PART No. DESCRIPTION KE6518-00-05-005 STRAIGHT TOOL – LEFT KE6518-00-05-006 STRAIGHT TOOL - RIGHT KE6518-00-05-007 STRAIGHT TOOL - NEUTRAL Figure 26 - AX08 Machine Tool Kit...

  • Page 53: Mounting Plate Assembly

    AX08 Flange Facing and Grooving Machine 8.6 MOUNTING PLATE ASSEMBLY Figure 27 – 3 Clamp Mount Plate Assembly NOTE: Maximum Torque Figure for base clamp blocks - Figure 28...
  • Page 54 AX08 Flange Facing and Grooving Machine Refer to Figure 27 & Figure 28 ITEM PART No. DESCRIPTION KE6518-00-07-001 TOOLPOST KNOB KE6518-00-04-000 3 or 4 CLAMP ASSEMBLY Figure 28 - 4 Clamp Mount Plate Assembly...

  • Page 55: Toolpost Assembly

    AX08 Flange Facing and Grooving Machine 8.7 TOOLPOST ASSEMBLY Refer to Figure 29 & Figure 30 ITEM PART No. DESCRIPTION KE6518-00-08-001 PLATE NUT KE6518-00-08-002 TOOL HOLDER KE6518-00-02-004 FEED SCREW KE6518-00-02-005 FEED SCREW CAP KE6518-00-02-006 SCALE RING KE6518-00-05-005 KE6518-00-05-006 STRAIGHT TOOLS (SEE KE6518-00-05-000) KE6518-00-05-007 SLIDE UNIT M3x8 HEXAG.
  • Page 56 AX08 Flange Facing and Grooving Machine Figure 30 - Toolpost Assembly...

  • Page 57: Appendix Acutting Tools As Applied To Portable Machines

    AX08 Flange Facing and Grooving Machine APPENDIX A CUTTING TOOLS AS APPLIED TO PORTABLE MACHINES As the flange facing machine is portable and thus lighter and less rigid than its workshop counterpart, the choice of tooling and the rate at which metal can be removed will differ from that used in the workshop.
  • Page 58 AX08 Flange Facing and Grooving Machine TYPES OF TOOL BIT FOR GENERAL PURPOSE AND FINE FINISH...
  • Page 59 AX08 Flange Facing and Grooving Machine TOOLS FOR V GROOVE PLUNGE MACHINING...

  • Page 60: Appendix Bsurface Metrology

    AX08 Flange Facing and Grooving Machine APPENDIX B SURFACE METROLOGY First profile graphs of roughness texture were produced over fifty years ago by a German Engineer, Gustav Schmalz. His graphs allowed differential magnification of vertical and horizontal axes so that a visual assessment of surface could be made.
  • Page 61 AX08 Flange Facing and Grooving Machine R.M.A. (Rq) Root Mean Square roughness is defined as: Sampling Lengths (Usually 0.08mrn) The length over which the mean line is fitted, this allows calculation of some surface parameters. Assessment Length Assessment length is the total length of surface to be assessed and is the sum of several sampling lengths Surface Form Most surfaces are made up of three classes of irregularities.
  • Page 62 AX08 Flange Facing and Grooving Machine Micro Roughness Micro roughness (primary surface) is caused by the cutting action which is a combination of cutting, tearing, and surface fatigue. Waviness Waviness (secondary texture) is caused by feed rate of tool, or chatter/vibration. Form Error Form error (tertiary texture inaccuracies of machine such as slideway of arm lift.

  • Page 63: Appendix C V-Groove Measurement

    AX08 Flange Facing and Grooving Machine APPENDIX C V-GROOVE MEASUREMENT...
  • Page 64 AX08 Flange Facing and Grooving Machine...

  • Page 65: Appendix Dair Motor Manufacturers Information

    AX08 Flange Facing and Grooving Machine APPENDIX D AIR MOTOR MANUFACTURERS INFORMATION...

  • Page 66: Appendix Edeclaration Of Conformity

    AX08 Flange Facing and Grooving Machine APPENDIX E DECLARATION OF CONFORMITY...
