- Page 1 INSTALLATION INSTRUCTIONS OPERATION MANUAL SGHN4-100 Series (Dual Operator) NEMA 4/12 UL325-2010 Compliant Commercial and Industrial Door Operator Logic Control Continuous Duty...
-
Page 2: Important Installation Instructions
IMPORTANT INSTALLATION INSTRUCTIONS WARNING – To reduce the risk of severe injury or death to persons: READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS. 2. Install only on a properly operating and balanced door. A door that is operating improperly could cause severe injury. Have qualified service personnel make repairs to cables, spring assemblies, and other hardware before installing the operator. -
Page 3: Specifications
SPECIFICATIONS MOTOR Duty Cycle: Continuous duty Horsepower: 1 hp (Two operators) Speed: 1700 RPM Voltage: 460 – 3 phase Current: See motor nameplate ELECTRICAL Transformer: 24VAC Wiring Type: Momentary pressure open, stop, constant pressure close (provided standard), with provision for momentary pressure close* Limit Adjustment: Linear driven, fully adjustable screw type cams. -
Page 4: Installation Instructions
TYPES AND SIZES OF DOORS Consult factory for details. INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS Consult factory for door installation position details. LIMIT SWITCH ADJUSTMENT Make sure the limit cams are positioned between the limit switch actuators before proceeding with adjustments. 1. Open / Remove the control panel cover. 2. -
Page 5: Wiring Instructions
WIRING INSTRUCTIONS Disconnect power at the fuse box before proceeding with any wiring. WARNING 1. Do not install any wiring or attempt to run this operator without checking the wiring diagram located on the inside of the control box cover. 2. -
Page 6: Control Wiring
CONTROL WIRING If the door is not visible from the control station, or if any device other than the control station is used to activate the door, an entrapment protection device must be installed on the door. Failure to install an entrapment WARNING protection device may result in serious injury or death to person(s) trapped beneath the door. - Page 7 Disconnect power at the fuse box before proceeding with any wiring. WARNING 2. Locate the control station where the user can clearly see the operation of the door. Mount the enclosed placard adjacent or near the door. Controls shall be far enough from the door, or positioned such that the user WARNING is prevented from coming in contact with door while operating the controls.
-
Page 8: Control Overview
A. Control Overview: Three-phase power source See operator plate for correct A-3. voltage. CN26 : Optional extra open and close limits connector A-2. TIMER E.OP M.CL M.OP Timer M o m e n t a r y P r e s s u r e O p e n C o n s t a n t P r e s s u r e M o m e n t a r y P r e s s u r e... -
Page 9: Auxiliary Function
B. Auxiliary Function: B-3. Radio control 24VAC Push button 24VAC B-1. B-1. CN12 CN13 CN14 1. 1&2 Open limit dry contact 2. 3&4 Close limit dry contact Non-Monitored Sensing Devices (N.O. Dry Contact) 24VDC MAX 0.5A 24VDC MAX 0.5A B-2. B-2. -
Page 10: Timer Instruction
C. Timer Instruction: Note: To enable timer(s) – 1) Must switch Timer Switch S10 to ON. (See figure A-2 on Page 7 for location.) 2) Must remove jumper on Terminal PCB-CN2 (23,24). (See figure A-1 on Page 7 for location.) C-2. - Page 11 (2) To Set Timer 1 (Mid-open Timer): Remove jumper from terminal (23,24) to enable Timers. Turn timer switch S10 to ON. Press and hold for 5 seconds. Display will flash. to increase or to decrease time. ...
- Page 12 (4) To Set Timer 3 (Buzzer Timer): Remove jumper from terminal (23,24) to enable Timers. Turn timer switch S10 to ON. Press and hold for 5 seconds. Display will flash. to increase or to decrease time. ...
-
Page 13: Lcd Display Instruction
D. LCD Display Instruction: Display Status Display Status T1 or T2 or T3 T1 setting setting completed T2 setting Door closing T3 setting Door opening E. Light Indication: LED17 Open button ON: Activated OFF: Not activated LED3 Door open limit ON: Door at open limit. - Page 14 Dual SGHN4 Series REVISION # 0000 DATE: 05/29/2018...
- Page 15 – Dual SGHN4 Series REVISION # 0000 DATE: 05/29/2018...
- Page 16 Reference SGH series terminal connections Control Station External Interlock Timer Defeat Photo eyes ELR sensing Push Button or IR sensing edge edge Close Jump when no external interlock warning Stop Open Close is connected. signal 24VDC Control panel is wired with momentary pressure open and constant pressure close. ...
- Page 17 TB6 (BOX A) TB7 (BOX A) To Box B TB12 terminal To Box C TB22 terminal TB8 (BOX A) To Box C TB23 terminal TB11 (BOX B) TB12 (BOX B) To Box A TB2 terminal To Box A TB6 terminal TB13 (BOX B) To Box A TB5 (1~5) terminal Spare...
-
Page 18: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING –To reduce the risk of severe injury or death: READ AND FOLLOW ALL INSTRUCTIONS. 2. Never let children operate or play with door controls. Keep the remote control (where provided) away from children. 3. Personnel should keep away from a door in motion and keep the moving door in sight until it is completely closed or opened. -
Page 19: Emergency Manual Operation
OPERATING INSTRUCTIONS 1. If a 3-button control station is used to operate the door, push the “OPEN” button to open the door, push the “CLOSE” button to close the door, push the “STOP” button to stop movement of the door while opening or closing. -
Page 20: Maintenance Instructions
MAINTENANCE INSTRUCTIONS The brake is a self-adjusting brake. It is maintenance free. The brake assembly requires no additional adjustments for its lifetime. If an entrapment protection device is used, i.e. sensing edge or photoelectric sensors, please consult the manufacturer for maintenance instruction. Disconnect power supply to the operator before servicing. - Page 21 APPENDIX 1 Multiple Sensing Devices Connection I nstruction Dual Photo eyes Connection Module Warning: Power OFF When Connecting. QST-SGD-SB-ADAPTER-3 Plug back the jumper Unplug the jumper connector connector if no additional to add modules. module is used. Dual photo eyes connection module connects on CN3 Primary Sensing Device Connection Part No:...
- Page 22 APPENDIX 2 Control Connections Diagrams CCD-PCB-A01 Control Wiring for 3 Button Stations Control Wiring for Key Switch with Stop Button 1 Set of 3 Button Stations Key Switch with Stop Button 3-1 BUTTON KEY SWITCH Key switch OPEN OPEN OPEN CLOSE OPEN OPEN...
- Page 23 APPENDIX 3 Control Connections Diagrams CCD-PCB-B02 Wiring 3 Button Stations With Key Lockout 1 Set KEY LOCKOUT 3 BUTTON OPEN OPEN OPEN CLOSE CLOSE CLOSE STOP STOP Key switch STOP With and without key lockout KEY LOCKOUT 3-2 BUTTON STOP STOP OPEN OPEN...
