9.17 Pushing In the Scanner Unit

1Y
NOTES
• When pushing in the scanner unit, exercise care so that the disconnected connectors and
cables are not caught.
• Push the scanner unit all the way into the machine, while pressing the stoppers of the slide
rails.
Slide rail
By reversing the procedures described in "9.2 Pulling Out the Scanner Unit," push in the
scanner unit.
009-058-00
10.20.2000 FM2732 (2)
At intervals of one year, or when 60,000 IPs have been processed
Slide rail
Stopper
CR-IR347 Service Manual
DETAIL A
HHS label #2
A
Scanner unit
PM - 110
Push in.
Stopper
Slide rail
FR7H6924.EPS
PM - 110
