GPS Air
Start-up Checklist
Complete 1 Checklist Per Ionizer
EQUIPMENT + INSTALLER DATA

MODEL VERIFICATION

1. Record Manufacturer: GPS
2. Record Model Number: GPS-DM48-AC
3. Record Serial Number of Ionizer:

INSTALLATION DATA

5. Record Name of Install Company and Technician:
6. Record Date of Installation/Startup:
7. Record ID of nearest HVAC system component:
8. Record Incoming Power Level:
9. Record Voltage Output at GPS-DM48-AC Emitters:
INSTALLATION

MECHANICAL MOUNT | Standard Installation

1. Confirm the GPS-DM48-AC is installed downstream of all filters in the system
2. Confirm a 4" hole was cut into the wall where the product is installed
3. Confirm there was at least 8" clearance into the duct to allow clearance of the emitters
4. Confirm that the air in the duct flows directly between the emitters as indicated by the sticker on the
ionizer body. (Note, the level orientation of the unit face should not be used as an alignment method as it is
rotationally offset).
5. Confirm the minimum of 4 fasteners have been used to secure the unit using the tabs on the ionizer body
™
