EMBRON Hatteland HT20 70 Series User Manual

Compact fanless marine computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
2-Bay Model
HT20x70 - Compact Fanless Marine Computer
where ww=CPU type (i3,i5,i7), xx=Power Input (AC, DC), y=manufacturing site, zz=configuration
Updated: 10 May 2022
Created: 7495/363
Please visit www.hattelandtechnology.com for the latest electronic version of this manual.
HT20370-ww-xx yzzzzzz
HT20470-ww-xx yzzzzzz
User Manual HT20x70
Doc Id: INB101717-1 (Rev 04)
Approved: 6987
4-Bay Model

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hatteland HT20 70 Series and is the answer not in the manual?

Questions and answers

Related Manuals for EMBRON Hatteland HT20 70 Series

Summary of Contents for EMBRON Hatteland HT20 70 Series

  • Page 1 USER MANUAL 4-Bay Model 2-Bay Model HT20x70 - Compact Fanless Marine Computer HT20370-ww-xx yzzzzzz HT20470-ww-xx yzzzzzz where ww=CPU type (i3,i5,i7), xx=Power Input (AC, DC), y=manufacturing site, zz=configuration User Manual HT20x70 Updated: 10 May 2022 Doc Id: INB101717-1 (Rev 04) Created: 7495/363 Approved: 6987 Please visit www.hattelandtechnology.com for the latest electronic version of this manual.
