U S E R M A N U A L
Compact Fanless Computer
HT B22Gx STC-yzz-Mzzz
where "x" is CPU type, "y" = Operating System (OS) type, "z" = hardware configuration dependent
User Manual
Updated: 12 Apr 2018
Doc Id: INB100610-2 (Rev 11)
Created: 363
Approved: 6987
Please visit www.hatteland-display.com for the latest electronic version of this manual.
Hatteland Display AS, Eikeskogvegen 52, N-5570 Aksdal, Norway
Tel: (+47) 4814 2200 - mail@hatteland-display.com - www.hatteland-display.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hatteland Display HT B22G Series and is the answer not in the manual?

Questions and answers

Related Manuals for EMBRON Hatteland Display HT B22G Series

Summary of Contents for EMBRON Hatteland Display HT B22G Series

  • Page 1 U S E R M A N U A L Compact Fanless Computer HT B22Gx STC-yzz-Mzzz where “x” is CPU type, “y” = Operating System (OS) type, “z” = hardware configuration dependent User Manual Updated: 12 Apr 2018 Doc Id: INB100610-2 (Rev 11) Created: 363 Approved: 6987 Please visit www.hatteland-display.com for the latest electronic version of this manual.
  • Page 2 Copyright © 2018 Hatteland Display AS Eikeskogvegen 52, N-5570 Aksdal, Norway. All rights are reserved by Hatteland Display AS. This information may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine- readable form without the prior written consent of Hatteland Display AS.

  • Page 3: Table Of Contents

    Contents Contents ..................3 Contents of package ...................5 General ..................7 About this manual ..................8 About Hatteland Display ................8 www.hatteland-display.com .................8 Contact Information ..................8 Computers introduction ................9 Product Labelling ..................10 Installation ................11 Installation and mounting of computers .............12 Cables .......................12 Housing / Terminal Block Connector Overview .........13 Accessible Storage Device (HDD/SSD) removal / replacement HT B22 ..15 Mounting Bracket Kit (Wall / Desktop) HT B22 ..........16...
  • Page 4 Contents Technical Drawings ..............37 Technical Drawings - HT B22Gx STC-yzz-Mzzz ........38 Technical Drawings - Accessories ........39 Technical Drawings - Mounting Bracket Kit - HT B22 ........40 HT 00270 OPT-A1 ................. 40 Technical Drawings - Mounting Plate/Cable Tension Relievers ....42 for HT B22, HT B17, B18, B07, B08 ............

  • Page 5: Contents Of Package

    Contents of package Note: Entries listed below are for Standard factory shipments. Customized factory shipments may deviate from this list. Item Description Illustration EUR TYPE F 1 pcs of power cable European Type F “Schuko” to IEC. Length 1.8m TP52/TC01-1,8M 1 pcs of power cable US Type B plug to IEC.
  • Page 6 This page left intentionally blank...

  • Page 7: General

    General...

  • Page 8: About This Manual

    Hatteland Display AS About this manual The manual contains electrical, mechanical and input/output signal specifications. All specifications in this manual, due to manufacturing, new revisions and approvals, are subject to change without notice. However, the last update and revision of this manual are shown both on the frontpage and also in the “Revision History” chapter at the end of the manual.

  • Page 9: Computers Introduction

    Computers Computers introduction Hatteland Display’s range of type-approved computers is designed to perform in harsh environments while providing the performance and flexibility you expect. We offer rack mount and black box/standalone computer solutions for every need. Our computers are used by system integrators, boat builders and end- users and can be found on all vessel types, all over the world.

  • Page 10: Product Labelling

    Product Labelling Serial Number Label Placement (external) Rear Side of unit Quality Control (QC) OS S/N Serial Number Serial Number Label Layout Product Type Manufacturer & Country Input Voltages & Power Rating Compass Safe Distance info Manufactured Date yyyymmdd Barcode “128” (TYP+SNO) Label Size: 6cm x 2cm.

  • Page 11: Installation

    Installation...

  • Page 12: Installation And Mounting Of Computers

    General Installation Recommendations Installation and mounting of computers Units may be intended for various methods of installation or mounting (rack mounting, panel mounting, bracket mounting, ceiling/wall mounting); for details, please see the relevant mechanical drawings. Adequate ventilation is a necessary prerequisite for the life of the unit. The air inlet and outlet openings must definitely be kept clear;...

  • Page 13: Housing / Terminal Block Connector Overview

    General Installation Recommendations Housing / Terminal Block Connector Overview Housing / Terminal Block connectors are available in different sizes (example 2-pin, 4-pin, 5-pin) which plugs into the connector area of the unit. They are mounted by factory default and delivered with the unit. The housing / terminal block connectors have steering rails, which ensures that it can not be mounted wrong.
  • Page 14 General Installation Recommendations If your installation require additional cable fasteners support, please visit and purchase directly from manufacturer: Illustrations below are approximate, actual Housing and Hood may deviate slightly, but function remains the same. Cable Housing - Illustration Cover Hood - Illustration BCZ 3.81 AH04 BK BX (4-pin) KGG-MSTB 2,5/ 2 (2-pin) BCZ 3.81 AH05 BK BX (5-pin)

  • Page 15: Accessible Storage Device (Hdd/Ssd) Removal / Replacement Ht B22

    General Installation Recommendations Accessible Storage Device (HDD/SSD) removal / replacement HT B22 Note: Areas of interest are marked in this section with symbols in color. Although the trays are Hot-Swappable, it is considered to be a good practice to power off the unit and disconnect power cable before proceeding! ▼...

  • Page 16: Mounting Bracket Kit (Wall / Desktop) Ht B22

    General Installation Recommendations Mounting Bracket Kit (Wall / Desktop) HT B22 Mounting Bracket Kit (HT 00270 OPT-A1) is included with delivery. Note: Areas of interest are marked in this section with symbols in color. Note: In order to secure the unit properly, please use only the screws delivered with the unit. Choosing own screws and longer than M4x8 (brackets onto unit) may cause permanent damage inside the unit and Warranty will be void ! ▼...

  • Page 17: Mounting Guidelines And Tips

    General Installation Recommendations Mounting Guidelines and tips Even though the HT B22 is fanless with no cooling apertures in the chassis, the unit will produce a certain amount of heat through the aluminium chassis. The top of the chassis as been designed with heat dissipation groves which allow heat to be properly expelled.

  • Page 18: Physical Overview - Ht B22Gx Stc-Yzz-Mzzz

    Physical Overview - HT B22Gx STC-yzz-Mzzz Front area of unit Device #0 (Boot/Main) Power LED Activity LED Power LED Activity LED Device #1 (Optional) 2 x USB2.0 2.5” Removable SATA HDD/SSD Trays Power ON/OFF Reset Button Power LED Power ON/OFF Button: To turn ON the computer, press down button and release it immediately.

  • Page 19: Connector Area Of Unit

    Physical Overview - HT B22Gx STC-yzz-Mzzz Connector area of unit DVI-I/RGB Out RS-422/RS-485 (COM2) 1 x USB1.1 2 x RJ45 Network Mic-in, Line-out 3 x USB2.0 Grounding Screw PS/2 Keyboard In Power Input DC PS/2 Mouse In RGB/VGA Out Power Input AC Expansion area for optional modules RS-232 (COM1) 4 x RS-422/RS-485 NMEA / ECDIS (Default from Factory)
  • Page 20 Physical Overview - HT B22Gx STC-yzz-Mzzz COM2 Serial Port INPUT / OUTPUT: 1 x D-SUB 9P Male connector with RS-422/RS-485 support. Fasten the cable to the connector using the provided screws on the cable housing itself. Baud Rate Min: 50b/s, Max: 1497600b/s (1.5Mb/s), Non-isolated port. Enhanced internal ESD Specifications: +/-15kV Human Body Model, +/-15kV IEC1000-4-2 Air Discharge, +/-8kV I EC 1 000-4-2 Contact Discharge.
  • Page 21 Physical Overview - HT B22Gx STC-yzz-Mzzz NMEA RS-422 / RS-485 (ECDIS) module (PCA100293-1): Suitable for communication with serial protocol based equipment. Connect and secure your cables to the Terminal Block 3.81 connector. For more information please review the Data Sheet in the Appendix chapter as well as the “Housing Connector Overview”...
  • Page 22 Physical Overview - HT B22Gx STC-yzz-Mzzz Audio INPUT/OUTPUT: All connectors are 3.5” Jack Stereo, non-amplified. AC’97 audio support. 5.1 channel. HD Audio. It can be configured via the operating system to act as 2-channel, 4-channel, 6-channel or 8-channel. Please review 3rd party driver software/manual to configure the channel setup.
  • Page 23 Physical Overview - HT B22Gx STC-yzz-Mzzz EXPANSION AREA for Optional modules: In this expansions area of the unit, optional factory mounted modules may be available. Connect and secure your cables to the Terminal Blocks or connectors, depending on module installed. The table below lists all modules currently available for factory mounting.
  • Page 24 This page left intentionally blank...

  • Page 25: Specifications

    Specifications...

  • Page 26: Specifications - Ht B22Gx Stc-Yzz-Mzzz

    Specifications - HT B22Gx STC-yzz-Mzzz SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hatteland-display.com for the latest electronic version. T E C H N I C A L D E S C R I P T I O N T E C H N I C A L D E S C R I P T I O N Computer Specifications: (Standard model) External Connector Type:...

  • Page 27: Specifications - Can Module With Co-Processor

    Specifications - CAN Module with CO-Processor All specifications are subject to change without prior notice! This information may not, in whole or in part, be copied, photocopied, DATA SHEET reproduced, translated or reduced to any electronic medium or machine- readable form without the prior written consent of Hatteland Display AS. The products may not be copied or duplicated in any way.

  • Page 28: Specifications - Nmea / Iec Com Module Rs-422 / Rs-485

    Specifications - NMEA / IEC COM Module RS-422 / RS-485 This information may not, in whole or in part, be copied, photocopied, DATA SHEET reproduced, translated or reduced to any electronic medium or machine- readable form without the prior written consent of Hatteland Display AS. The products may not be copied or duplicated in any way.

  • Page 29: Pca100293-1

    Specifications - NMEA / IEC COM Module RS-422 / RS-485 SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hatteland-display.com for the latest electronic version. CAUTION This unit contains electrostatic sensitive devices. Observe precautions for handling. Users who needs to open the unit set jumper settings will VOID THE WARRANTY! Before opening, proper ESD measurements must be taken! 1.
  • Page 30 Specifications - NMEA / IEC COM Module RS-422 / RS-485 NMEA RS-422 / RS-485 (ECDIS) module (PCA100293-1): Suitable for communication with serial protocol based equipment. Connect and secure your cables to the Terminal Block 3.81 connector. For more information please review the Data Sheet in the Appendix chapter as well as the “Housing Connector Overview”...

  • Page 31: Specifications - Isolated Digital Input/Output Module

    Specifications - Isolated Digital Input/Output Module All specifications are subject to change without prior notice! This information may not, in whole or in part, be copied, photocopied, DATA SHEET reproduced, translated or reduced to any electronic medium or machine- readable form without the prior written consent of Hatteland Display AS. The products may not be copied or duplicated in any way.
  • Page 32 Specifications - Isolated Digital Input/Output Module All specifications are subject to change without prior notice! SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hatteland-display.com for the latest electronic version. Additional • Cable connector (MC 1,5/ 5-STF-3,81) Terminal Block 3.81 (see illustration below) •...

  • Page 33: Specifications - Lan Module

    Specifications - LAN Module All specifications are subject to change without prior notice! This information may not, in whole or in part, be copied, photocopied, DATA SHEET reproduced, translated or reduced to any electronic medium or machine- readable form without the prior written consent of Hatteland Display AS. The products may not be copied or duplicated in any way.

  • Page 34: Specifications - Isolated Com Module Rs-232

    Specifications - Isolated COM Module RS-232 All specifications are subject to change without prior notice! This information may not, in whole or in part, be copied, photocopied, DATA SHEET reproduced, translated or reduced to any electronic medium or machine- readable form without the prior written consent of Hatteland Display AS. The products may not be copied or duplicated in any way.

  • Page 35: Specifications - External Modules (Usb)

    Specifications - External Modules (USB) Specifications - External Modules (USB) All specifications are subject to change without prior notice! This information may not, in whole or in part, be copied, photocopied, DATA SHEET reproduced, translated or reduced to any electronic medium or machine- readable form without the prior written consent of Hatteland Display AS.
  • Page 36 Specifications - External Modules (USB) All specifications are subject to change without prior notice! SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hatteland-display.com for the latest electronic version. Ordering Details: TypeNumber Description Internal Speci cations (link to separate datasheets) HT 00262 OPT-A1 NMEA COM (Based on PCA100293-1)

  • Page 37: Technical Drawings

    Technical Drawings...

  • Page 38: Technical Drawings - Ht B22Gx Stc-Yzz-Mzzz

    Technical Drawings - HT B22Gx STC-yzz-Mzzz IND100132-243...

  • Page 39: Technical Drawings - Accessories

    Technical Drawings - Accessories...

  • Page 40: Technical Drawings - Mounting Bracket Kit - Ht B22

    Technical Drawings - Mounting Bracket Kit - HT B22 HT 00270 OPT-A1 IND100132-244...
  • Page 41 Technical Drawings - Mounting Bracket Kit HT 00270 OPT-A1 IND100132-244...

  • Page 42: Technical Drawings - Mounting Plate/Cable Tension Relievers

    Technical Drawings - Mounting Plate/Cable Tension Relievers for HT B22, HT B17, B18, B07, B08 IND100132-266...

  • Page 43: Technical Drawings - External Modules (Usb)

    Technical Drawings - External Modules (USB) IND100132-245...
  • Page 44 This page left intentionally blank...

  • Page 45: Appendixes

    Appendixes...

  • Page 46: Ssd Selection Guide

    SSD Selection Guide Solid State Disk (SSD) Devices Last revised : 26 March 2018 SSD's has many benefits over conventional hard drives, but when it comes to write endurance it is important to choose the technology to be used with care. It is of very high importance to consider several aspects when using an SSD for a particular application, below the most critical ones, such as: - Nature of the application, data written to disk during a defined time period (worst case).
  • Page 47 SSD Selection Guide Calculation of required size of SSD (Multi-Level Cell - MLC) device) The table below details the write endurance of the an enterprise environment. All values are verified by Hatteland Display during the qualification / selection process. Write Endurance Specifications Write Endurance Specifications Previous 2.5”...
  • Page 48 SSD Selection Guide Measure of number of write cycles (Intel® Solid-State Drive Toolbox software) https://downloadcenter.intel.com/Detail_Desc.aspx?agr=Y&DwnldID=18455 Download Software from: Preparation 1: Install "Intel® Solid-Sate Drive Toolbox" at target system. 2: Install the unit in valid configuration, i.e. the application shall running valid use case, if possible use worst case scenario (with respect to disk activity).

  • Page 49: Pinout Assignments

    Pinout Assignments Connectors illustrated here are either standard by factory default or may be available (through factory customization). Note that some combinations may not be possible due to space restrictions. List also valid for customized models. All pin out assignments are seen from users Point of View (POV) while looking straight at the connector. Please review the dedicated datasheet or technical drawings for your actual unit to identify and determine the presence of desired connector.
  • Page 50 Pinout Assignments Serial COM RS-485/RS-422, 9-pin DSUB Male Serial COM RS-485/RS-422, 9-pin DSUB Male “Half Duplex Mode* “Full Duplex Mode* 1 2 3 4 5 1 2 3 4 5 PIN 01 Res. Reserved, do not connect PIN 01 TxD- Transmit Data Negative PIN 02 Res.
  • Page 51 Pinout Assignments 4+4 pin CAN I/O Module, 2 channels 10+10 pin Isolated Digital Input/Output Module Type Number “ZIA0001310-B” Type Number “PCA100297-1” Module A Module B CAN1 CAN2 Pin 01 X8 - Can1: 081 In Low Module A Module B Pin 02 X8 - Can1: 082 Out Low A1 External Power + IN+[0] Pin 03 X8 - Can1: 083 In High...
  • Page 52 Pinout Assignments 9-pin Amplifi ed Mono/Stereo Audio Out, DSUB Female Module COM Module RS-232 - 2 x ports, 9-pin DSUB Male Type Number “HT 00271 OPT-A1” Type Number “PCA100309-1” 4 3 2 1 1 2 3 4 5 9 8 7 6 PIN 01 LAUDR Left Audio Return* PIN 01 DCD Data Carrier Detect PIN 02 LAUD...

  • Page 53: Trouble-Shooting

    Trouble-shooting GENERAL TROUBLE-SHOOTING CD-ROM FAILURE OR READ/DETECTION PROBLEMS? If the unit are operated/located in a area with extreme condensation, the CD/DVD-ROM drive may not work correctly due to condensation on the read head. Keep the product on for a while until it’s reached normal operating temperature, and retry accessing discs.

  • Page 54: Declaration Of Conformity

    Declaration of Conformity We, manufacturer, Hatteland Display AS, Eikeskogvegen 52, N-5570 Aksdal, Norway declare under our sole responsibility that the JH MMD, JH MMC, JH STD, JH MIL, HM NMD, HM MIL, HM CMD, HT STD, HD MMD, HM MMD, HT MMC, HD MMC and HT/HM (computers) product ranges is in conformity with the following standards in accordance with the EMC Directive.

  • Page 55: Return Of Goods Information

    Return Of Goods Information Return of goods: (Applies not to warranty/normal service/repair of products) Hatteland Display referenced as “manufacturer” in this document. Before returning goods, please contact your system supplier before sending anything directly to manufacturer. When you return products after loan, test, evaulation or products subject for credit, you must ensure that all accessories received from our warehouse is returned.

  • Page 56: General Terms And Conditions

    General Terms and Conditions As of January 2015, Hatteland Display AS’ “Terms of Sales and Delivery” and “Warranty Terms” has been substituted by the updated ”General terms and conditions for sale of goods and performance of additional services” (the “General Terms and Conditions”).

  • Page 57: Api / Vcom Commands

    API / VCOM Commands Introduction VCOM = Internal Virtual COM (VCOM), where is OS/configuration dependent. Normally COM7, but could vary. = Application programming interface. Standard industry term for how software components should interact. Installing API / VCOM Drivers In order to access and communicate with the HT B22 computer unit, it may or may not already have pre-installed drivers depending on factory defaults.
  • Page 58 API / VCOM Commands Message Format The basic message format shall be as follows and sent to the Internal Virtual COM (VCOM) port: Byte # 7..etc End Byte ATTN ADDR IHCHK DATA IDCHK The minimum message size is 7 bytes (0x07). The maximum message size is 82 bytes (0x52), consistent with the EN61162-1 standard.
  • Page 59 API / VCOM Commands Available Messages to Send: Please review the last page of this section for a code example. “SWI” - Retrieve Internal Software Version Query: This query is sent to the unit in order to get the version. Any future revisions, such as CMD additions or changes to the software will increment the software version.
  • Page 60 API / VCOM Commands Basic Example for setting Half/Full Duplex Mode Example using Microsoft® Visual Studio 2012, C# style. Note, COM7 has been used as port ID. It may differ depending on your system installation. In any case, simply write COMx (where is the number defined by the Operating System automatically) for Virtual COM Port.
  • Page 61 API / VCOM Commands Basic Example for setting Half/Full Duplex Mode Example using Linux, C style. Note, ttyS7 has been used as port ID. It may differ depending on your system installation. In any case, simply write ttySx (where is the number defined by the Operating System automatically) for Virtual COM Port. #include <stdio.h>...

  • Page 62: Signal Detection Note

    Signal Detection Note Signal Detection Note Overview of known behaviours regarding signal outputs Table data and tests last revised 18 April 2013 Due to the design and nature of third-party graphics driver and industrial manufacturers on-board chip architecture there are certain issues regarding signal auto detection / connecting / re-connecting / disconnecting signal cables from DVI-I and RGB/VGA connectors on a Stand-Alone computer unit.
  • Page 63 Signal Detection Note Microsoft® Windows® XP Professional SP3, 32bit with latest graphics/motherboard drivers from MEDIA STD DVD or our website. ▼ Cable connected upon boot ▼ ▼ Graphics Driver Configuration / Settings ▼ ▼ Behaviour ▼ Detected Enabled Clone VGA Connected DVI Connected Single Output Mode Cloned Output Mode...

  • Page 64: Notes

    Notes General Notes: - License Terms for the installed OEM Operating System (OS) can be found in the following default factory paths: Note: This is a general listing for a varity of OS’s Hatteland Display can factory install depending on unit. Please check specification for your unit to verify type of OS installed in order to retrieve the license terms.
  • Page 65 User Notes Appendix IND100077-24...

  • Page 66: Revision History

    Revision History Rev. Date Notes 00_1 18 Mar 2013 Internal review release. Preliminary version 00_2 10 Apr 2013 Revised after internal review. Preliminary version 00_3 19 Apr 2013 Revised after internal review. Preliminary version 04_4 10 May 2013 Revised after internal review. Preliminary version 02 Jul 2013 Revised and created release version for internet/dvd.
  • Page 67 Revision History IND100077-128...
