Oak Desk Riser
Instruction Manual
SKU: DESK-V000VO
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-v000vo
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo DESK-V000VO
Summary of Contents for Vivo DESK-V000VO
- Page 1 Oak Desk Riser Instruction Manual SKU: DESK-V000VO Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-v000vo GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
- Page 3 ASSEMBLY STEPS STEP 1 Carefully remove the Desk Riser (A) from the packaging. WARNING: Impact Hazard! Moving Parts can Crush and Cut! STEP 2 Flip Desk Riser (A) upside down, then attach Feet Extensions (B) to the frame using M5x10mm Screws (S-A).
- Page 4 STEP 3 Press the handles on each side and lift Desk Riser (A). STEP 4 Mount Keyboard Brackets (C) to Keyboard Tray (D) using M5x10mm screws (S-A).
- Page 5 STEP 5 Hang assembled keyboard tray onto pre-installed knobs, and tighten knobs to secure. NOTE: Make sure the keyboard brackets are curving towards the user, not towards the inside of the desk. STEP 6 Place monitor, laptop and other items on desk surface.
- Page 6 STEP 7 Attach Cable Clip (S-B) to desk to manage keyboard and mouse cables. STEP 8 Manage cables using Zip Ties (S-C).
- Page 7 STEP 9 If locks are not releasing properly to change desk height, adjust the position of the black tube containing the steel release cable. Turn the nuts at the end of the tube just behind the handle as shown, moving the tube away from the handle until the cable once again has proper tension, then tighten the nuts.
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
