  • Page 1 Product Manual ® RadiSense Electric Field Probe Models: RSS2010E www.raditeq.com...
  • Page 2 This product manual refers to the RadiSense® series. RadiSense® Models: RSS2010E - By Raditeq RadiSense® LASER card: LPS2001B - By Raditeq Carefully read the content of this manual before operating the product and make sure all the safety instructions are strictly followed.

  • Page 3: Table Of Contents

    Program the correction file into the probe Enabling the user correction file RadiSense® specifications RadiSense® general specifications Warranty Conditions Page 3 of This product manual is subject to change without notice Page 3 of 29 Copyright © 2008 - 2022 Raditeq B.V.

  • Page 4: Warnings & Precautions

    Using this product with any other mainframe can cause harm and will void warranty. Only Raditeq qualified maintenance personnel is allowed to perform maintenance and/or repair service on the equipment. This product contains materials that can be recycled and reused to minimize material waste. At the ‘end-of-life’, specialized companies can dismantle the discarded system to collect the reusable and recyclable materials.
  • Page 5 The RadiCentre Slim requires a laser start procedure where the user has to hold the start button for at least 5 seconds until five warning beeps are heard, before the laser is activated. This product manual is subject to change without notice Page 5 of 29 Copyright © 2008 - 2022 Raditeq B.V.
  • Page 6 Long term field monitoring RadiMation® Software RadiMation® is the brand independent EMC automation software from Raditeq. RadiMation® places the EUT in the center The software is designed to perform all EMC tests required to certify an EUT. This instead of focusing on separate EMC tests.

  • Page 7: The Radisense® Series

    E-field readings without the need to apply additional corrections. In this case corrections will be applied inside the probe for each individual axis. This product manual is subject to change without notice Page 7 of 29 Copyright © 2008 - 2022 Raditeq B.V.

  • Page 8: Radisense® Essential System Deliverables

    Optional - The calibration certificate for the field sensor (if an ISO/IEC 17025 accredited calibration certification was ordered). • Lint free cleaning wipes This product manual is subject to change without notice Page 8 of 29 Copyright © 2008 - 2022 Raditeq B.V.

  • Page 9: Fibre Optic Cables

    To ensure the safe and correct operation of the sensor, only use the RadiSense® with the original supplied or ordered fibres optic cables. Do not use fibres optic cables other than those supplied by Raditeq, The use of fiber optic cables from another supplier can lead to permanent damage.

  • Page 10: Laser - Safety Measures

    Do not disconnect fibber optic cables as long as these LED’s are ON. This product manual is subject to change without notice Page 10 of 29 Copyright © 2008 - 2022 Raditeq B.V.
  • Page 11 Releasing the start button before the fifth beep will abort the laser activation process and the laser will not be activated. This product manual is subject to change without notice Page 11 of 29 Copyright © 2008 - 2022 Raditeq B.V.

  • Page 12: Fibre Handling And Maintenance

    RadiSense) and the bidi link (on the LPS2001B plug-in Card) are cleaned when (dis)connected. As long as the connectors remain in place, no maintenance is required. This product manual is subject to change without notice Page 12 of 29 Copyright © 2008 - 2022 Raditeq B.V.

  • Page 13: Fibre Conditions

    Use the examples below as a guideline for further fibre maintenance. If you have doubts about the condition of the fibre optic cables, please contact your local reseller or Raditeq for assistance and/or advise. Note: to be able to inspect the fibre optic cable connector, specialized equipment and training is required.

  • Page 14: Probe Stand

    RadiSense® Product Manual RSS2010E Probe Stand The RadiSense® 10E is assembled as follows: 150mm 100mm This product manual is subject to change without notice Page 14 of 29 Copyright © 2008 - 2022 Raditeq B.V.
  • Page 15 (like additional mounting material or antenna masts) in close proximity to the field sensor will influence the electric field and will cause additional measurement errors. This product manual is subject to change without notice Page 15 of 29 Copyright © 2008 - 2022 Raditeq B.V.

  • Page 16: Software Configuration

    To control the RadiSense probe from a computer, one can use either custom made software or EMC automation software like the RadiMation® EMC software package from Raditeq. RadiMation can be downloaded from the Raditeq website: (https://www.raditeq.com/download). If the RadiSense® is operated manually, this chapter can be skipped.

  • Page 17: How To Connect The Radisense® To The Radicentre

    When the correct slot number is chosen, continue to set the communication of the RadiSense® by clicking ‘Communication tab’ (next page). This product manual is subject to change without notice Page 17 of 29 Copyright © 2008 - 2022 Raditeq B.V.

  • Page 18: How To Setup The Communication Of The Radisense® To The Radicentre

    • • RS232 When these steps are performed continue to the next steps for checking the communication of the RadiSense®. This product manual is subject to change without notice Page 18 of 29 Copyright © 2008 - 2022 Raditeq B.V.

  • Page 19: How To Check Whether The Radisense® Is Properly Connected To Radimation

    It is also advised to visit the RadiMation® Wiki page and the FAQ section, which can be found at: https://wiki.radimation.com RadiMation® software can be downloaded at: https://www.raditeq.com/emc-test-software/radimation-download This product manual is subject to change without notice Page 19 of 29 Copyright © 2008 - 2022 Raditeq B.V.
  • Page 20 12 = 8192 times average User correction data Every RadiSense® 10 probe is factory adjusted and verified at Raditeq. All required correction data (among linearity data for each axis) is stored inside the field probe. Additionally, “user correction factors” (for example ISO/IEC 17025 calibration correction values) can be stored into the RadiSense®...

  • Page 21: Radisense® 10 User Correction Calibration Data

    The RadiSense® 10 probe can store up to 200 “user correction factor” points. For manual uploading of the user correction data please refer to the white paper available on www.raditeq.com This product manual is subject to change without notice Page 21 of 29 Copyright © 2008 - 2022 Raditeq B.V.

  • Page 22: Create And Upload User Correction Data With Radimation

    After selecting the new correction file the following screen shall be presented. To add the required X, Y and Z correction column press the ‘Columns/Units’ button shown on this screen. This product manual is subject to change without notice Page 22 of 29 Copyright © 2008 - 2022 Raditeq B.V.
  • Page 23 After filling in this data into the correction file, this could for example look like the following (typical RadiSense® 10 frequency response correction data). This product manual is subject to change without notice Page 23 of 29 Copyright © 2008 - 2022 Raditeq B.V.

  • Page 24: Program The Correction File Into The Probe

    This will enable the usage of the user calibration table during initialisation of the RadiSense® 10 when starting a test. This product manual is subject to change without notice Page 24 of 29 Copyright © 2008 - 2022 Raditeq B.V.

  • Page 25: Radisense® Specifications

    Conditions & Warranty Temperature range 0 °C to 40 °C Relative humidity 10 – 90% (non-condensing) Warranty 3 years (see warranty condtions) This product manual is subject to change without notice Page 25 of 29 Copyright © 2008 - 2022 Raditeq B.V.
  • Page 26 ST/PC - fibre Fiber length (4) 100 m maximum (Optional) Safety Interlock External Interlock & closed loop safety system Warranty 3 Years This product manual is subject to change without notice Page 26 of 29 Copyright © 2008 - 2022 Raditeq B.V.

  • Page 27: Warranty Conditions

    Warranty Conditions Raditeq B.V. offers a warranty term of three (3) years on their products, calculated from the shipping date, under the condition that the product is registered on www.raditeq.com. For registration of the product, the customer should provide the product model, serial number and the responsible reseller (if applicable).
  • Page 28 Date of issue: Publish Date: 15/08/2022 Place of issue: Woerden, The Netherlands Authorized by: P.W.J. Dijkstra Title of authority: Director This product manual is subject to change without notice Page 28 of 29 Copyright © 2008 - 2022 Raditeq B.V.
  • Page 29 Raditeq B.V. | Vijzelmolenlaan 3 | 3447GX Woerden | The Netherlands Raditeq B.V. | Vijzelmolenlaan 3 | 3447GX Woerden | The Netherlands www.raditeq.com | T:+31 348 200 100 www.raditeq.com | T:+31 348 200 100...
