- Page 1 EX-91121 Display Monitor User Manual Release Date Revision November 2005 V0.1 May 2007 V0.2 ®2005 All Rights Reserved. Published in Taiwan EX-91121 User Manual...
-
Page 2: Warning
Electric Shock Hazard – Do not operate the workstation with its back cover removed. There are dangerous high voltages inside. Disclaimer This information in this document is subject to change without notice. EX-91121 User Manual... -
Page 3: Table Of Contents
2.1 Front Panel Controls………….………………………………….…..……9 2.2 OSD Controls………………………………………………………………9 2.3 Main Menu…..……………………………………………………………..10 2.4 AD Board (TB-6020) OSD Functions……………………………………12 Figures Figure 1.1: Dimensions of EX-91121….……………………………………..6 Figure 1.2: Front View………………………………………………………….8 Figure 1.3: Rear View…………………..……………………………………...8 Figure A: Panel-mounting…………………………………………………..13 Figure B: Rack-mounting (optional)……………………………………….13 Figure C: VESA 75-mounting………………………………………………14 Appendix Panelmounting…..…………………………………………………………….13... -
Page 4: Features
VGA, DVI (optional), Composite Video and S-Video (optional) Resolutions: Wide-ranging resolutions from 640x480 to up to 1600x1200 with auto phase and auto position 1.2 Specifications Display TFT LCD: 12.1” SVGA Luminance: 300 cd/m2 Viewing Angle: 120(H) x 95(V) degrees EX-91121 User Manual... - Page 5 0~50°C (32°~122°F) Storage Temperature: -20~60°C (-4°~140°F) Relative Humidity: 10~90% @40°C non-condensing, without touch screen Vibration: 1g peak, 5~500Hz (at random) Shock: 15G peak acceleration (11msec. duration)/operation Front Panel Compliance: NEMA 4/12, IP65 rated Certifications: CE, FCC Class A EX-91121 User Manual...
-
Page 6: Figure 1.1: Dimensions Of Ex-91121
12V AC or 12~24V AC (optional) Power Supply: 90V~240V, 50~60Hz, 1.5A (max.) Dimensions 317(W) x 52.8(D) x 243(H) mm Weight: 2.62kg Mounting Type: Panel/VESA 75 Ordering Information EX-91121 12.1” SVGA industrial display monitor (plastic front bezel) Option resistive touch screen EX-91121 User Manual... -
Page 7: Dimensions
1.3 Dimensions Figure 1.1: Dimensions of the EX-91121 EX-91121 User Manual... -
Page 8: Brief Description
1.4 Brief Description of the EX-91121 The EX-91121 display monitor is compact and thus, it is ideal for monitoring and control applications. It comes with an optional touch screen, making operation more convenient and faster. The front panel of the display monitor is sealed with gasket for the NEMA 4/IP 65 compliance when it is panel-mounted in a NEMA rated cabinet or enclosure. -
Page 9: Front Panel Controls
2. Select the icon that you wish to adjust with the ( or +/-) key in the menu. 3. Press (Menu) and then choose the item with the ( or +/-) key. 4. Press (Menu) and then adjust the quality with the ( or +/-) key. EX-91121 User Manual... -
Page 10: Main Menu
In the Main menu, there are the following items: Color Image Setting Position OSD Menu Language Misc Exit For Color, check out the following: Contrast Brightness Color Adjust Color Temp Back For Image setting, check out the following: Clock Phase Gamma Sharpness Back EX-91121 User Manual... - Page 11 Germany Spanish Traditional Chinese Simplified Chinese Japanese In the Misc menu, there are: Signal Source Select VGA: Analogue VGA Input Select DVI: Digital DVI-D Input Select AV: Composite Video Input Select SV: S-Video Video Input Reset Back EX-91121 User Manual...
-
Page 12: Ad Board (Tb-6020) Osd Functions
(don’t let them go) until the AC power cord is connected, and wait for 2 to 3 seconds. When “RGB” appears, repeat the above steps. 3.) Functions of OSD Keys Auto Adjust Up/Left Down/Right Power Menu/Entry Power Indicator EX-91121 User Manual... -
Page 13: Figure A: Panel-Mounting
Figure A: Panelmounting of the EX91121 Rack Mounting (optional) The EX-91121 display monitor can be rack-mounted as an option. Just carefully slide it into the rack and tighten the given 8 screws from the front to secure the mounting as shown in Figure B. -
Page 14: Figure C: Vesa 75-Mounting
VESA 75 (optional) The EX-91121 display monitor can be VESA 75-mounted as an option. Just accurately put a monitoring arm right behind the unit where the four holes are and tighten the four given screws as shown in Figure C.
