FLAV-R-SAVOR
Heated Air Curtain Cabinets
FSHAC & FSHACH Series
This manual contains important safety information
concerning the maintenance, use and operation of this
product. Failure to follow the instructions contained in this
manual may result in serious injury. If you're unable to
understand the contents of this manual, please bring it to
the attention of your supervisor. Do not operate this
equipment unless you have read and understood the
contents of this manual.
Installation &
Operating Manual
I&W #07.05.164.00
Este manual contiene importante información sobre
seguridad concerniente al mantenimiento, uso y
operación de este producto. Cualquier falla en el
seguimiento de las instrucciones contenidas en este
manual puede resultar en un serio daño. Si usted no
puede entender el contenido de este manual por
favor pregunte a su supervisor. No opere este
equipo al menos que haya leído y comprendido el
contenido de este manual.
®
Advertisement
Table of Contents
Related Manuals for Hatco FLAV-R-SAVOR FSHAC-2
Summary of Contents for Hatco FLAV-R-SAVOR FSHAC-2
- Page 1 FLAV-R-SAVOR Heated Air Curtain Cabinets FSHAC & FSHACH Series Operating Manual This manual contains important safety information concerning the maintenance, use and operation of this product. Failure to follow the instructions contained in this manual may result in serious injury. If you’re unable to understand the contents of this manual, please bring it to the attention of your supervisor.
-
Page 2: Table Of Contents
“just-made” quality. Hatco Heated Air Curtain Cabinets force warm air through ducts down the cabinet opening, creating and maintaining ideal holding temperatures without the use of doors. The heated air is slowly drawn to the back of the cabinet, warming the food as it flows to the perforations on the back cabinet wall. -
Page 3: Important Safety Information
Some aftermarket or generic replacement parts do not have the characteristics that will allow them to operate safely in Hatco equipment. It is essential to use Hatco Replacement Parts when repairing Hatco equipment. Failure to... -
Page 4: Model Description
MODELS FSHAC-2 AND FSHAC-3 The FSHAC non-humidified Heated Air Curtain Cabinet is available in two-pan or three-pan models, holding half-sized sheet pans. The FSHAC-2 (two- pan model) comes equipped with four rubber feet. The FSHAC-3 (three-pan model) comes equipped with 4" (102 mm) legs, which require assembly to the unit before operation. -
Page 5: Specifications
If the plug and receptacle do not match, contact a qualified electrician to determine the proper voltage and size and install the proper electrical outlet. Model Voltage FSHAC-2 120/208 FSHAC-3 120/208 FSHACH-2 120/208 FSHACH-3... -
Page 6: Dimensions
(613 mm) Add 1" (25 mm) to height when mounting back-to-back. Cabinet Openings: FSHAC-2: 18-1/4"W x 9-1/8"H (464 x 232 mm) FSHACH-2: 18-1/4"W x 9-1/8"H (464 x 232 mm) FSHAC-2PT: 18-1/4"W x 9-1/4"H (464 x 235 mm) FSHACH-2PT: 18-1/4"W x 9-1/4"H (464 x 235 mm) Form No. - Page 7 DIMENSIONS Width Depth Model FSHAC-3 20-1/8" 18-3/4" (511 mm) (476 mm) FSHACH-3 20-1/8" 18-3/4" (511 mm) (476 mm) Add 4" (102 mm) to height for units with legs. Add 1" (25 mm) to height when mounting back-to-back. Cabinet Openings: FSHAC-3: 18-1/4"W x 18-1/8"H (464 x 460 mm) FSHACH-3: 18-1/4"W x 18-1/8"H (464 x 460 mm) Depth Height...
-
Page 8: Installation
INSTALLATION UNPACKING The Flav-R-Savor ® Heated Air Curtain Cabinets are shipped with most components installed and ready for operation. The following installation instructions must be performed before plugging in and operating the cabinet. WARNING Do not lay unit on the side with the control panel or damage to the unit could occur. -
Page 9: Plumbing
1. Assemble fittings to filter cartridge using plumbing tape or pipe sealant. (Filter supplied by Hatco, Part No. 03.05.079.00.) 2. Turn off water supply. INSTALLATION Water Supply Outlet Water Flow Arrow Figure 7. -
Page 10: Operation
INSTALLATION See MAINTENANCE section for Filter Cartridge Replacement. A drain connection is located inside the cabinet cavity for manually draining the water reservoir. (See Figure 9.) A male hose connector is included. See MAINTENANCE for draining information. OPERATION WARNING Some exterior surfaces on the unit will get hot. Use caution when touching these areas to avoid injury. - Page 11 -3 models have the capacity to hold 2-1/4 gallons (9 liters) and FSHACH-2PT models have the capacity to hold 3 gallons (11 liters) of water. Hatco recommends using softened or distilled water. NOTE: To assure proper operation when using distilled water, add one teaspoon of salt to the water reservoir during the initial manual fill only.
-
Page 12: Maintenance
Follow these instructions when replacement is necessary: 1. Assemble fittings to new filter cartridge using plumbing tape or pipe sealant. (Filter supplied by Hatco, Part No. 03.05.079.00.) 2. Turn off water supply. 3. Remove old cartridge. NOTE: Install filter cartridge flow with arrow towards the equipment. -
Page 13: Draining The Reservoir
DRAINING THE RESERVOIR WARNING To avoid any injury, turn the power OFF to the unit and allow to cool before draining. It is recommended that the Flav-R-Savor reservoir be drained prior to moving the cabinet and after removing lime or mineral deposits from the water reservoir. -
Page 14: Accessories
Some aftermarket or generic replacement characteristics that will allow them to operate safely in Hatco equipment. It is essential to use Hatco Replacement Parts when repairing Hatco equipment. Failure to use Hatco Replacement Parts may subject operators of the equipment to hazardous electrical voltage, resulting in electrical shock or burn. -
Page 15: Hatco Limited Warranty
Hatco reserves the right to accept or reject any such claim in whole or in part. Hatco will not accept the return of any Product without prior written approval from Hatco, and all such approved returns shall be made at Buyer’s sole expense. -
Page 16: Authorized Parts Distributors
Cone’s Repair Service Flanders Moline 309-797-5323 P.O. Box 340500, Milwaukee, WI 53234-0500 U.S.A. Parts & Service Fax (800) 690-2966 Printed in U.S.A. January 2006 HATCO AUTHORIZED PARTS DISTRIBUTORS NEW YORK Acme American Repairs, Inc. 317-545-9655 Brooklyn Alpro Service Co. Brooklyn...
