ASSEMBLY INSTRUCTIONS:
Item No: SAR15110LED
1. Place the base (A) on a level surface.
2. Screw the lower column (B) into base (A).
3. Screw the center column (C) into lower column (B).
4. Screw the upper column (D) into the center column (C).
5. Screw the decorative column (E) into the upper column (D).
6. Place the glass shade (G) over the socket (F) and tighten with
the socket ring (H), securing the shade in place.
7. Insert the bulb into bulb socket.
Recommended (1) maximum 460LM LED Bulb.
(Bulb Included)

Cleaning of your lamp.

Unplug lamp, wipe with a damp cloth. Do not use abrasives
*SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
Made in China
FOR RETURN SHIPPING PURPOSES:
PLEASE RETAIN ORIGINAL PACKAGING
TO MINIMIZE DAMAGE.
Revision – 10/06//16
