Repair Manual
Hose Reel Swivel
Kit
For swivel replacement on SDX
professional use only.
Important Safety Instructions
Read all warnings and instructions in this
manual and in SDX and XDX 10/20
Series Hose Reels Instruction manual
before using the equipment. Save all
instructions.
Kit Selection:
See Kits table on page 2 to determine the correct
replacement kit(s) for your specific hose reel.
Related Manuals
Manual in
Description
English
3A8626
SDX and XDX 10/20 Series Hose Reels
™
™
and XDX
10/20 Series Hose Reels only. For
3A8689C
EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Graco SDX
Summary of Contents for Graco SDX
- Page 1 10/20 Series Hose Reels only. For professional use only. Important Safety Instructions Read all warnings and instructions in this manual and in SDX and XDX 10/20 Series Hose Reels Instruction manual before using the equipment. Save all instructions. Kit Selection: See Kits table on page 2 to determine the correct replacement kit(s) for your specific hose reel.
- Page 2 133503 SDL23# SDX10 Air/Water 133502 SDL25# SDX10 Air/Water 133502 300 psi SDL56# SDX20 Air/Water 133502 (2.07 MPa, 20.7 bar) SDL5J# SDX Truck 20 Air/Water 133502 SDL33# SDX10 Air/Water 133503 SDL65# SDX20 Air/Water 133503 SDL6H# SDX Truck 20 Air/Water 133503 SDM3B#...
- Page 3 Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.
-
Page 4: Operation
13. Pressurize the reel and hose. After doing this, the obstruction can be cleared. 14. Retract the hose. SDX Models - Single Pedestal NOTE: This relieves tension on the swivel due to hose expansion on the spool. 3A8689C... - Page 5 Operation XDX Models - Dual Pedestal SPRING TENSION HAZARD The hose reel spring is always under great tension, which if released in an uncontrolled manner could 1. Perform Pressure Relief Procedure, page 4. cause serious injury. 2. Remove the inlet hose and remove the hose reel •...
- Page 6 Operation e. While holding the breaker bar securely, completely remove the two screws (A) (F . 2). While firmly grasping the breaker bar with both hands, turn it counter-clockwise one turn at a time until the spring tension is reduced to zero .
- Page 7 Operation 10. Install washer (12) onto the swivel assembly and install the replacement swivel assembly (6) in the hose reel. NOTE: F . 4 shows the correct shape (a) of the swivel assembly end, and the correct alignment of the swivel to the keyhole in the pedestal.
- Page 8 Operation 11. Install the swivel-side pedestal (G) onto the reel. 12. Replace the nut (10) and screws (1). 13. Reinstall screw (2) and washer (3). 14. Connect the hose (not shown) to the elbow (11). 15. Tighten the spring tension. a.
-
Page 9: Recycling And Disposal
Recycling and Disposal Recycling and Disposal End of Product Life At the end of the product’s useful life, dismantle and recycle it in a responsible manner. • Perform the Pressure Relief Procedure. • Drain and dispose of fluids according to applicable regulations. -
Page 10: Graco Information
For the latest information about Graco products, visit www.graco.com. For patent information, see www.graco.com/patents. TO PLACE AN ORDER, contact your Graco distributor or call to identify the nearest distributor. Phone: 612-623-6928 or Toll Free: 1-800-533-9655, Fax: 612-378-3590 All written and visual data contained in this document reflects the latest product information available at the time of publication.
