TIS VENERA VEN-3S-3R-HC Installation Manual

INSTALLATION MANUAL
VENERA TOUCH PANEL
TIS VENERA 1-3 GANG PANEL
Model: VEN-3S-3R-HC, VEN-2S-2R-HC, VEN-1S-1R-HC
Power Supply
Output
Output switching current
Output service life
Output switching times
TIS AIR
Operating and display
elements
Dimensions
Housing
The Venera Switch is a wall-mounted touch switch
with multiple management options. It can be set
up in three easy steps: remove your old switch
and install the new one, connect it to the Internet,
and start controlling it. Regardless of whether
your residence is an apartment or a house with a
big yard, once you replace the old switches, the
Venera Switch is ready to go.
P R O D U C T S P E C I F I C AT I O N S
Input Voltage
Output Power
Protection
Current consumption
Number of channels
Nominal voltage
Nominal current per channel
Max switching current
Output service life
Output switching times
Mechanical Endurance
Operating time
Releasing time
Max. operating frequency
WIFI Signal
Protocol Standard
touch buttons
Infrared Receiver
Backlight
TIS AIR
Upgrading
Length × Width × Height
Materials
Internal Parts color
IP rating
PRODUCT INFORMATION
110-230 VAC 50/60 Hz
3W / 12V
Built in Protection fuse
10-30 mA / 12 V DC
2 / 3 (refer to Model number)
110 / 230 V AC 50/60 Hz
8 A / 230 VAC
10A/230 VAC Resistive
6A/230 VAC florescent
8A/230 VAC
277VAC / 30VDC
> 10,000,000 OPS
8mS (at nomi. Volt)
5 mS (at nomi. Volt)
25 cycle/min
2.4 GHz
802.11 b/g/n
4 touch Capacitive buttons for control ...
Control it by TIS Remote control
RGB Backlight indicators
TIS Protocol messages and commands
By WIFI Connection
85mm × 42mm × 109mm
PC fire-proof/ Glass in front
Black or White
IP 50
