TIS TITAN 4GANG TIT-4G-BUS-K Diagrams

Download this manual

Product Diagrams V 1.2

Connect To N

Figure 1: TIT-4G-BUS-K & Lights Connection Diagram

TIS TITAN 4GANG

Model: TIT-4G-BUS-K

S3 S2 S1 C

TIT 4G-BUS-K

www.tiscontrol.com

24V D+ D- GND Z1 Z2

Cat5e

GND(white-orange)&(white-brown)

D-(white-green)&(white-blue)

Cat5ee connection

D+(blue-green)

+24V(brown-orange)

Touch Panel

Connect To L

MCB

O-OFF

I-ON

2.5 mm Electric Cable

1.5 mm Electric Cable
