- Page 1 Model # YG098-NM USE AND CARE GUIDE LODGE 52 IN. CEILING FAN Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............Operation ..............Remote Control Operating Instructions ........Safety Information ............Installing the Remote Control Holder ........Reverse Operating Instructions ..........Warranty ................. Care and Cleaning ............Pre-installation .............. Specifications ................Troubleshooting ............Tools Required ................. Service Parts ............... -
Page 3: Safety Information
Safety Information To reduce the risk of electric shock, ensure electricity has However, there is no guarantee that interference will not occur been turned off at the circuit breaker or fuse box before in a particular installation. If this equipment does cause harmful beginning. -
Page 4: Warranty
Warranty We warrant the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser. We also warrant that all other fan parts, excluding any glass or acrylic blades, to be free from defects in workmanship and material at the time of shipment from the factory for a period of two years after the date of purchase by the original purchaser. -
Page 5: Hardware Included
Pre-Installation (continued) HARDWARE INCLUDED HARDWARE INCLUDED NOTE: Hardware shown to actual size unless noted otherwise in the table below. Part Part Description Description Quantity Quantity Plastic wire nut Mounting bracket screw (preassembled) Blade attachment screw and fiber washer Blade arm screw and lock washer (preassembled) Remote control holder mounting screw (not to scale) Clevis pin (preassembled) Cotter pin (preassembled) -
Page 6: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS PACKAGE CONTENTS Part Part Description Description Quantity Quantity Part Part Description Description Quantity Quantity Mounting bracket (preassembled) Blade arm Canopy Light kit mounting plate Canopy bottom cover (preassembled) Switch housing Hanger ball/downrod assembly (4”) Light shade Extra downrod (6”) Light kit Coupling cover... -
Page 7: Installation
Installation MOUNTING OPTIONS MOUNTING OPTIONS NOTE: WARNING: You may need a longer downrod to maintain proper To reduce the risk of fire, electric shock, or blade clearance when installing on a steep, sloped ceiling. personal injury, mount the fan to an outlet box marked The maximum angle allowable is 18°... -
Page 8: Assembly
Assembly Preparing the canopy Changing the downrod (Optional) □ Remove the canopy bottom cover (C) from the canopy NOTE: Your fan comes with a 4" downrod (VV) attached to (B) by turning the canopy bottom cover (C) counter- the hanger ball (UU). In addition you have been provided with clockwise. - Page 9 Assembly Preparing the motor Assembling the fan □ Remove the cotter pin (GG) and clevis pin (FF), and WARNING: Failure to properly install the cotter pin ( loosen the two collar setscrews (HH) from the motor collar. could result in the fan becoming loose and possibly falling. □...
-
Page 10: Hanging The Fan
Assembly — Hanging the Fan Hanging the fan from the Attaching the mounting bracket mounting bracket to the electrical box WARNING: To reduce the risk of fire, electric shock or WARNING: The tab in the ring must rest in the groove of other personal injury, mount the fan only to an outlet box or the hanger ball/downrod assembly (D). - Page 11 Assembly — Hanging the Fan (continued) Preparing the receiver and remote control WARNING: To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring. CAUTION: Do not use with a wall light dimmer switch. If you feel you do not have enough electrical wiring knowledge or experience, have your fan installed by a licensed electrician.
- Page 12 Assembly — Hanging the Fan (continued) □ If your outlet box (SS) has a ground wire (green Making the electrical connections or bare copper) connect it to the fan ground wires; otherwise connect the hanger ball/downrod assembly (D) ground wire to the mounting bracket (A). WARNING: Check to see that all connections are tight, □...
- Page 13 Assembly — Hanging the Fan (continued) Attaching the canopy Installing the canopy bottom cover WARNING: Make sure the tab on the mounting bracket (A) NOTE: Adjust the mounting bracket screws (BB) as properly sits in the groove in the hanger ball/downrod necessary until the canopy (B) and canopy bottom cover (C) assembly (D) before attaching the canopy (B) to the mounting are snug.
-
Page 14: Attaching The Fan Blades
Assembly — Attaching the Fan Blades Removing the rubber Attaching the blades to packing mounts the blade arms □ □ The fan motor assembly (G) is shipped with rubber Attach the blades (H) to the blade arms (I) using the packing mounts (WW) to prevent movement during three blade attachment screws and fiber washers transportation. - Page 15 Assembly — Installing the Light Kit Attaching the light kit mounting Attaching the light kit to plate to the mounting ring the switch housing □ Remove one of the three light kit mounting plate NOTE: Retain the plug (LL) to reinsert when not using the screws (II) from the mounting ring (ZZ) and loosen the light kit (M).
- Page 16 Assembly — Installing the Light Kit (continued) Attaching the light kit to Installing the the light shade the light kit mounting plate □ While holding the light kit assembly (M) under the fan CAUTION: Before starting installation, disconnect the motor assembly (G), snap together the wire power by turning off the circuit breaker or removing the fuse connection plugs (AAA).
-
Page 17: Operation
Operation REMOTE CONTROL OPERATING INSTRUCTIONS REMOTE CONTROL OPERATING INSTRUCTIONS □ Install the 9 volt battery (RR) into the remote control (O). To prevent damage to the remote control (O), remove the battery if not used for long periods. □ Restore power to the ceiling fan and test for proper operation. HI, MED, LOW buttons: set the fan speed. -
Page 18: Reverse Operating Instructions
Operation (continued) REVERSE OPERATING INSTRUCTIONS REVERSE OPERATING INSTRUCTIONS Speed settings for warm or cool weather depend on factors such as the room size, ceiling height, number of fans, and so on. NOTE: To operate the reverse function on this fan, press the for/rev button while the fan is running. -
Page 19: Troubleshooting
Troubleshooting WARNING: Make sure the power is off at the electrical panel box before you attempt any repairs. Refer to step 8 “Making the electrical connections” on page 12. Problem Problem Solution Solution □ Check the main and branch circuit fuses or breakers. □... -
Page 20: Service Parts
Service Parts Part Part Description Description Part Part Description Description Mounting bracket (preassembled) Mounting bracket screw (preassembled) Canopy Blade attachment screw and fiber washer Canopy bottom cover (preassembled) Blade arm screw and lock washer (preassembled) Hanger ball/downrod assembly (4”) Remote control holder mounting screw Extra downrod (6”) Clevis pin (preassembled) Coupling cover... - Page 21 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. YG098NM0001-A...
