Installation Instructions
Original Instructions
GuardLogix 5570 Controllers
Catalog Numbers 1756-L71S, 1756-L71SK, 1756-L72S, 1756-L72SK, 1756-L73S, 1756-L73SK, 1756-L7SP, 1756-L7SPK, 1756-L7SPXT, 1756-L73SXT,
1756-SPESMNRM, 1756-SPESMNRMXT, 1756-SPESMNSE, 1756-SPESMNSEK, 1756-SPESMNSEXT
Topic
Summary of Changes
This manual contains new and updated information as indicated in the following table.
Topic
Added Plug Attention Statement
Specifications
Page
3
5
5
5
5
5
6
6
7
8
Page
5
7
Advertisement
Table of Contents
Related Manuals for Rockwell Automation Allen-Bradley GuardLogix 5570
Summary of Contents for Rockwell Automation Allen-Bradley GuardLogix 5570
-
Page 1: Table Of Contents
Installation Instructions Original Instructions GuardLogix 5570 Controllers Catalog Numbers 1756-L71S, 1756-L71SK, 1756-L72S, 1756-L72SK, 1756-L73S, 1756-L73SK, 1756-L7SP, 1756-L7SPK, 1756-L7SPXT, 1756-L73SXT, 1756-SPESMNRM, 1756-SPESMNRMXT, 1756-SPESMNSE, 1756-SPESMNSEK, 1756-SPESMNSEXT Topic Page Product Advisories Energy Storage Module Functional Safety Machinery Directive Insert the Controller into the Chassis Insert the Key Install the SD Card Install the ESM... - Page 2 Indien de apparatuur wordt gebruikt op een wijze die niet is gespecificeerd door de fabrikant, dan bestaat het gevaar dat de beveiliging van de apparatuur niet goed werkt. Rockwell Automation Publication 1756-IN089A-EN-P - May 2021...
-
Page 3: Product Advisories
• Substitution of components may impair suitability for Class I, Division 2. • If this product contains batteries, they must be changed only in an area known to be nonhazardous. Rockwell Automation Publication 1756-IN089A-EN-P - May 2021... - Page 4 • Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1, for additional installation requirements. • NEMA Standard 250 and EN/IEC 60529, as applicable, for explanations of the degrees of protection provided by different types of enclosure. Rockwell Automation Publication 1756-IN089A-EN-P - May 2021...
-
Page 5: Energy Storage Module
Safety of machinery - Safety-related parts of EN ISO 13849-1:2008/ control systems - AC:2009 Part 1: General principles for design Safety of machinery - Functional Safety of safety- EN 62061:2005 related electrical, electronic, and programmable electronic control systems Rockwell Automation Publication 1756-IN089A-EN-P - May 2021... -
Page 6: Install The Sd Card
40 major fault is logged on power up. To verify that the ESM is fully charged, check the status display to confirm that messages CHRG or ESM charging are no longer indicated. Close the SD card door. Rockwell Automation Publication 1756-IN089A-EN-P - May 2021... -
Page 7: Specifications
(2) Port Plugs must remain installed in unused ports at all times during storage and operation for the product to meet it’s corrosive atmosphere rating. (3) Up to 9.6 microns per year, corrosion rate of copper. Rockwell Automation Publication 1756-IN089A-EN-P - May 2021... -
Page 8: Additional Resources
GuardLogix 5570 Controllers Installation Instructions Additional Resources These documents contain additional information concerning related products from Rockwell Automation. Resource Description Provides information on how to install, configure, program, and use GuardLogix 5570 Controllers User Manual, publication 1756-UM022 GuardLogix 5570 controllers in Studio 5000™ Logix Designer projects. - Page 9 GuardLogix 5570 Controllers Installation Instructions Notes: Rockwell Automation Publication 1756-IN089A-EN-P - May 2021...
- Page 10 GuardLogix 5570 Controllers Installation Instructions Notes: Rockwell Automation Publication 1756-IN089A-EN-P - May 2021...
- Page 11 GuardLogix 5570 Controllers Installation Instructions Notes: Rockwell Automation Publication 1756-IN089A-EN-P - May 2021...
- Page 12 Rockwell Otomasyon Ticaret A.Ş. Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, İstanbul, Tel: +90 (216) 5698400 EEE Yönetmeliğine Uygundur Allen-Bradley, expanding human possibility, GuardLogix, Rockwell Automation, RSLogix 5000, and Studio 5000 Logix Designer are trademarks of Rockwell Automation, Inc.
